J A M E S
M A R T I N
James Martin Vanities always recommends you hire or consult a professional contractor when installing our products
Note:
This mirror is not intended for outdoor use
IMPORTANT: Please read all instructions prior to beginning the installation of this mirror
• Make sure the installation area is free of clutter.
• Turn off electricity including wall switch's.
• Do not modify wires in anyway
• Always use two or more person when hanging mirrors
Parts included
Mirror
Version:202107
KLQA5E1S58989H1B1P1
V A N I T I E S
LED Mirror - Installation Instructions
A
Wire Nuts X 4pcs
Screws X 4pcs
( 5*５0 )
( 10*45)
B
Mounting Bracket X 1pc
Electrical Cord
(attached to back of mirror)
943-M36-BGD RADIANCE MIRROR
C
FEATURES
• 5mm copper free silver mirror
• High output LED light:3300-3400LM,4000K CCT
• Touch switch for surface LED
CODES / CERTIFICATIONS
• 5020102
Made in China
Page 1 of 6
Advertisement
Table of Contents
Related Manuals for JAMES MARTIN VANITIES RADIANCE 943-M36-BGD
Summary of Contents for JAMES MARTIN VANITIES RADIANCE 943-M36-BGD
- Page 1 V A N I T I E S 943-M36-BGD RADIANCE MIRROR LED Mirror - Installation Instructions James Martin Vanities always recommends you hire or consult a professional contractor when installing our products Note: This mirror is not intended for outdoor use IMPORTANT: Please read all instructions prior to beginning the installation of this mirror •...
- Page 2 Mirror Weight: 37.4 LBS (17 KGS) 943-M36-BGD RADIANCE MIRROR Pre-Installation Notes • 120 Vac 60Hz wall outlet location - Required for source power • Mirror hangs in Portrait orientation • Includes hardware with easy installation via Plug and Hang Systen 2 1/4”[57mm] 2”[50mm] magnification...
- Page 3 Mirror Weight: 37.4 LBS (17 KGS) 943-M36-BGD RADIANCE MIRROR Tools required Screw driver Drill with 3/8" bit Pencil Measuring Tape Screw driver level The hammer Measure the distance between the bottom Draw a horizontal line from the point a using a level Draw the points according to the hole of the mirror and point a.
- Page 4 943-M36-BGD RADIANCE MIRROR Care and Cleaning Instructions for Mirrors • CLEANER • The best and safest cleaner for a mirror is clean, warm water used with a soft cloth. Be careful not to allow the edges of the mirror to get or remain wet over a period of time. If using a commercial glass or mirror cleaner, be sure to use a standard brand of mirror cleaner that does not contain ammonia or vinegar.
- Page 5 943-M36-BGD RADIANCE MIRROR MANUAL INSTRUCTION： 1) Short Touch the switch button (＜1s) to turn the light and defogger ON/OFF. 2) Long Touch the switch button (＞1s) to activate the dimming function. Adjust the light to the appropriate brightness. ELECTRICAL SAFETY INSTRUCTIONS: All connections must be installed by a licensed electrician, in accordance with current building codes.
- Page 6 943-M36-BGD RADIANCE MIRROR IMPORTANT SAFETY INSTRUCTIONS: When using an electrical furnishing, basic precautions should always be followed, including the following. Read all instructions before using (this furnishing). DANGER - To reduce the risk of electric shock: Always disconnect this furnishing from the electrical outlet before cleaning. WARNING -To reduce the risk of burns, fire, electric shock, or injury to persons.
