- Page 1 Installation Manual FPP5800 / FPP5500 Protective Screen Important Please read the safety information and all information delivered with the product carefully to familiarize yourself with safe and effective usage.
-
Page 2: Legal Information
Use of EIZO products WARNING EIZO products may only be used for the applications described in the catalog and in the relevant tech- nical documentation. If products and components from other manufacturers are used, these must be recommended or approved by EIZO. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems. -
Page 3: Table Of Contents
General safety instructions .................. 5 Product specific safety notes .................. 5 3 Description........................ 6 Scope of delivery ...................... 6 Area of application .................... 7 3.2.1 Supported monitor models FPP5800 ............ 7 3.2.2 Supported monitor models FPP5500 ............ 7 Important features..................... 7 4 Setup and installation ...................... 8 Site.......................... 8 Mounting ........................ 9... -
Page 4: Introduction
1.1 Contents of this documentation This document explains the functionality and the approved application of the products Protective Screen FPP5800 and Protective Screen FPP5500. To ensure clarity, it does not contain all detailed information on these products. The contents of this document are neither part of a previous or existing agreement, commit- ment or legal relationship, nor does it modify such. -
Page 5: Safety Information
2 Safety information 2.1 General safety instructions Correct and safe operation of EIZO products assumes professional transport, storage, installation, and connection, as well as careful operation and service. Follow the general safety instructions in the instructions for use of the compatible monitor. -
Page 6: Description
Protective screen The protective screen is designed for mounting on the front frame of the supported monitor models. Product Order No. Protective Screen FPP5800 6GF62008AA010AA0 Protective Screen FPP5500 6GF62008BA010AA0 Various components The following components are included in the scope of delivery: •... -
Page 7: Area Of Application
• This value has to be taken into account if the monitor will be recalibrated. • Recalibration to higher brightness values decreases the life time of the monitor. 3.2.1 Supported monitor models FPP5800 The protective screen FPP5800 is compatible with following monitors. RadiForce LS560W RadiForce LS580W RadiForce LL580W Raptor RP5824 DSC 5608-DC 6GF62008AA01... -
Page 8: Setup And Installation
This may take several hours, depending on the conditions. Check if the additional weight is allowed The protective screen has a weight of 13.5 kg +/-1 kg (FPP5800) or 12.5 kg +/-1 kg (FPP5500). Ensure that the holder of the monitor is designed for this additional weight. -
Page 9: Mounting
The ceiling suspension must be applicable for the higher weight. FPP5800 has a weight of 13.5 kg +/-1 kg, FPP5500 of 12.5 kg +/-1 kg. • If a lifting tool is used, it must be designed for the overall weight of monitor plus protec- tive screen. - Page 10 Remove outer screw 1x Remove outer screw 1x 2. Apply the protective screen to the monitor. Notice: Secure the protective screen against dropping or tilting until the screws are applied. Move carefully to monitor FPP5800 / FPP5500 Installation Manual, 07/2019...
- Page 11 4. If the monitor is mounted in a ceiling suspension the warning label which is delivered with the protective screen has to be placed close to the VESA 400 mount. Remove “Frame With Protection Screen“ before dismounting the display Stick label here: FPP5800 / FPP5500 Installation Manual, 07/2019...
-
Page 12: Cleaning And Maintenance
Terralin, 0.5 Vol. % 120 min Ethylalcohol, 96% 180 min Standard household washing-up liquid: Tempo 120 min Distilled water 120 min Spray disinfection with Nocospray / Nocolyse 15 min spray duration 60 min residence time FPP5800 / FPP5500 Installation Manual, 07/2019... -
Page 13: Technical Specifications
IP20 in accordance with DIN 40050 Weight 13.5 kg +/-1 kg (FPP5800) 12.5 kg +/-1 kg (FPP5500) Dimensions (W x H x D) 1325 x 783 x 53 mm³ (FPP5800) 1272 x 742 x 53 mm³ (FPP5500) FPP5800 / FPP5500 Installation Manual, 07/2019... -
Page 14: Climatic Conditions
EN 60068-2-27 (single impact) EN 60721-3-3 Class 3M2 (single impact) EN 60068-2-29 (permanent impact) EN 60721-3-3 Class 3M2 (permanent impact) Packed unit Vibrations EN 60068-2-6 EN 60721-3-2 Class 2M2 Shock EN 60068-2-27 (single impact) 100 m/s², 16 ms (in storage packaging) EN 60068-2-29 (continuous shocks) FPP5800 / FPP5500 Installation Manual, 07/2019... -
Page 15: Dimension Drawings
Dimension drawings 7.1 Dimensions FPP5800 7 Dimension drawings All dimensions in mm 7.1 Dimensions FPP5800 7.2 Dimensions FPP5500 FPP5800 / FPP5500 Installation Manual, 07/2019... -
Page 16: Appendix
These warranty conditions are neither extended nor limited by the contents of this installation manual. 8.2 Repairs Please contact the sales partner from whom you purchased the product. 8.3 Environmental protection Comply with all local requirements and laws pertaining to the disposal of devices. FPP5800 / FPP5500 Installation Manual, 07/2019... -
Page 17: China Rohs (Restriction Of Hazardous Substances)
Applications of hazardous substances in this medical device are required to achieve its intended clinical uses, and/or to provide better protection to human beings and/or to environment, due to lack of reasonably (economically or technically) available substitutes. 产品中有毒有害物质或元素的名称及含量 Table of hazardous substances’ name and con- centration. FPP5800 / FPP5500 Installation Manual, 07/2019... -
Page 18: Contact
8.6 Trademarks The EIZO Logo is a registered trademark of EIZO Corporation in Japan and other countries. EIZO is a registered trademark of EIZO Corporation in Japan and other countries. RadiForce is a registered trademark of EIZO Corporation in Japan and other countries. -
Page 19: Index
Index Index Ambient temperature 14 Contact 18 Disposal 16 Mounting 9 Order No. 6 Product-specific safety notes 5 Scope of delivery 6 Service personnel 4 Warranty 16 Weight 13 FPP5800 / FPP5500 Installation Manual, 07/2019... - Page 20 Carl-Benz-Straße 3 76761 Rülzheim Germany Installation Manual, 07/2019 FPP5800 / FPP5500 A5E10002279A-010 Copyright © 2019 EIZO GmbH. All rights reserved.
