- Page 1 Instruction Manual FPP5800 Frontframe with Protection Screen Important Please read the Safety Information and the information delivered with the product carefully to familiarize yourself with safe and effective usage.
- Page 2 Note the following: WARNING EIZO products may only be used for the applications described in the catalog and in the relevant tech‐ nical documentation. If products and components from other manufacturers are used, these must be recommended or approved by EIZO. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
-
Page 3: Table Of Contents
Mechanical requirements ......................21 Dimensional drawings ........................... 22 Dimensions ..........................22 Appendix............................... 23 Warranty ............................23 Repairs ............................23 Environmental protection ......................23 Contact ............................23 China RoHS (Restriction of Hazardous Substances) ..............24 Index..............................26 Index ............................26 FPP5800 Instruction Manual, 05/2014... -
Page 4: Introduction
Contents of this documentation This document explains the functionality and the approved application of the: • Protection Screen FPP5800 for RadiForce LS560W and RadiForce LS580W To ensure clarity, it does not contain all detailed information on this product. The contents of this document are neither part of a previous or existing agreement, commitment or legal relationship, nor does it modify such. -
Page 5: Safety Notes
Flawless, safe and reliable operation of the equipment assumes that it has been professionally transported, stored, mounted and installed as well as careful operator control and service. The units may only be used for applications for which monitors are normally used. FPP5800 Instruction Manual, 05/2014... - Page 6 There must be no contact to a patient when handling the connection cables. Overload Do not connect too many devices to one socket or extension cable since this could result in a fire or electric shock. Observe the information provided by the manufacturer. FPP5800 Instruction Manual, 05/2014...
- Page 7 Please ensure that all steps are taken to avoid injuries or incorrect diagnoses. Regular maintenance and calibration must be carried out. Observe all regulations of the country in which the monitor is used FPP5800 Instruction Manual, 05/2014...
- Page 8 • The screen surface (front panel) is extremely sensitive to mechanical damage. Absolutely avoid scratches, shocks etc. • Remove water drops immediately; extended contact with water discolors the surface. • Clean the screen and the housing using only the cleaning agents referred to in the manual. FPP5800 Instruction Manual, 05/2014...
- Page 9 Molded power supply plugs must comply with the requirements for "hospital grade attachments" CSA Std. C22.2 No. 21 and UL 498. Note for installation in China Only use the the power cables approved for China. These power cables are identified by the labels "CCC" or "CQC". FPP5800 Instruction Manual, 05/2014...
-
Page 10: Product Specific Safety Notes
2. Only trained persons are allowed to mount the protection screen to the monitor. 3. Turn off power of the monitor before the panel protector is mounted. 4. Persons who are mounting the panel protector must wear adequate protection to prevent injuries in case the panel protector is dropped. FPP5800 Instruction Manual, 05/2014... -
Page 11: Description
1 Warning Sticker This manual Area of application This Protection Screen is used to prevent mechanical damage of the LCD-panel on the RadiForce LS560W and LS580W monitor models. Supported models: 6GF6200-8AA00 6GF6200-8AA01 6GF6200-8AA02 6GF6200-8AA03 6GF6200-8AB00 6GF6200-8AB01 6GF6200-8AB03 6GF6200-8AB04 FPP5800 Instruction Manuall, 05/2014... -
Page 12: Important Features
Specially for use on the 8 MegaPixel Monitor Family RadiForce LS560W and LS580W The panel protector is specially designed for use on the Radiforce LS560W / LS580W monitor family from EIZO. It protects the monitor from mechanical damage. FPP5800 Instruction Manual, 05/2014... -
Page 13: Application Planning
Clean surface of panel and inside of the protection screen To avoid foreign objects between monitor panel and glass of the protection screen clean the surface of the monitor panel and the glass of the protection screen. Only use cleaning agents which are allowed. FPP5800 Instruction Manual, 05/2014... -
Page 14: Assembly
If the monitor mounted in a ceiling suspension needs to be replaced, the frame with panel protection has to be dismounted before the monitor is removed from the ceiling suspension if the lifting tools have a maximum load of 50 kg. FPP5800 Instruction Manual, 05/2014... - Page 15 Insert the new screws which are coming with the panel protector and fasten the screws (picture 5.1.3). The torque for fastening the screws should not be stronger than 1.6 Nm! remove existing screws 2 x remove existing screws 2 x remove existing screws 2 x remove existing screws 2 x Picture 5.1.1 FPP5800 Instruction Manual, 05/2014...
- Page 16 The installation of the Protection Screen FP5800 will reduce the brightness of the monitor by approximately 7%. This value has to be taken into account if the monitor will be recalibrated. Recalibration to higher values will decrease life time of the monitor. FPP5800 Instruction Manual, 05/2014...
- Page 17 If the monitor is mounted in a ceiling suspension the warning label which is delivered with the panel protector has to be placed near the VESA 400 mount, see picture 5.1.4. Place label here: Picture 5.1.4 FPP5800 Instruction Manual, 05/2014...
-
Page 18: Service And Maintenance
10. Terralin, 0.5 Vol. % 120 min 11. Ethylalcohol, 96% 180 min 13. Standard household washing-up liquid: Tempo 120 min 15. Distilled water 120 min 15 min spray duration 16. Spray disinfection with Nocospray / Nocolyse 60 min residence time FPP5800 Instruction Manual, 05/2014... -
Page 19: Technical Specifications
Liquid-coated metal parts • Degree of protection IP20 in accordance with DIN 40050 • Weight 13.5 kg ± 1 kg • Dimensions (W x H x D) in mm 1325 x 783 x 53 mm • FPP5800 Instruction Manual, 05/2014... -
Page 20: Climatic Conditions
5 °C ... 40 °C ambient temperature Temperature gradient 5°C/h max., no condensation Air pressure 700 ... 1060 hPa Transport and storage (packed) Temperature range -20°C ... +60°C ambient temperature Temperature gradient 5°C/h max., no condensation Air pressure 500 ... 1060 hPa FPP5800 Instruction Manual, 05/2014... -
Page 21: Mechanical Requirements
To EN 60721-3-3 Class 3M2 (permanent impact) Packed unit Vibrations To EN 60068-2-6 To EN 60721-3-2 Class 2M2 Shock To EN 60068-2-27 (single impact) 100 m/s², 16 ms (in storage packaging) To EN 60068-2-29 (continuous shocks) FPP5800 Instruction Manual, 05/2014... -
Page 22: Dimensional Drawings
Dimensional drawings Dimensions All dimensions in mm FPP5800 Instruction Manual, 05/2014... -
Page 23: Appendix
Repairs Please contact the sales partner from whom you purchased the product. Environmental protection Please observe all local requirements and laws pertaining to the disposal of monitors. Contact Support during installation and for technical questions: http://www.eizo.com FPP5800 Instruction Manual, 05/2014... -
Page 24: China Rohs (Restriction Of Hazardous Substances)
Periodic replacement of those consumables or parts to maintain the declared EFUP shall be done in accordance with the Product Maintenance Procedures. This product must not be disposed of as unsorted municipal waste, and must be collected separately and handled properly after decommissioning. FPP5800 Instruction Manual, 05/2014... - Page 25 Applications of hazardous substances in this medical device are required to achieve its intended clinical uses, and/or to • provide better protection to human beings and/or to environment, due to lack of reasonably (economically or technically) available substitutes. 产品中有毒有害物质或元素的名称及含量 Table of hazardous substances’ name and concentration. FPP5800 Instruction Manual, 05/2014...
-
Page 26: Index
Check if the additional weight is allowed, 15 Contact, 29 Warranty, 29 Warranty conditions, 29 Dimensions, 27 Front frame with protection screen Weight, 23 General safety notes, 7 Order no.: Frame with Protection Screen, 13 Product disposal, 29 Product-specific safety notes, 12 FPP5800 Instruction Manual, 05/2014... - Page 27 Siemensallee 84 76187 Karlsruhe Germany Instruction Manual, 05/2014 FPP5800 A5E10002279A-005 Copyright © 2014 EIZO GmbH. All rights reserved.
