- Page 1 SINGLE-WAN GIGABIT VPN ROUTER USER INTERFACE MANUAL Models: AN-110-RT-2L1W AN-110-RT-2L1W-WIFI...
-
Page 2: Federal Communication Commission Interference Statement
Araknis Networks® X10 Series Router Federal Communication Commission Interference Statement User Interface Manual Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 3: Fcc Warning
Araknis Networks® X10 Series Router FCC Warning User Interface Manual Avertissement: (i) Les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux;... -
Page 4: Certifications
Araknis Networks® X10 Series Router Certifications User Interface Manual The frequency and the maximum transmitted power in EU are listed below: 2412-2472MHz: 19.90 dBm 5180-5240MHz: 22.90 dBm The device is restricted to indoor use only when operating in the 5150 to 5350 MHz frequency range.. -
Page 5: About This Manual
Araknis Networks® X10 Series Router About this Manual User Interface Manual About this Manual This manual provides installers and end users with current information regarding the installation, setup, use, and maintenance of the product. The symbols below identify important information: Pro Tip –... -
Page 6: Table Of Contents
Araknis Networks® X10 Series Router Table of Contents User Interface Manual Table of Contents Federal Communication Commission Interference Statement Industry Canada Statement FCC Warning CE Warning Certifications About this Manual Table of Contents Menu Overview Status > System Status > Clients & Services Status >... -
Page 7: Menu Overview
Araknis Networks® X10 Series Router Menu Overview User Interface Manual Menu Overview A - Main Navigation Panel Use the collapsible Status, Settings, Tools, Advanced, and System Log headings (and their submenus) to configure and maintain the router. The green bar and gray highlight shows which header is active. -
Page 8: Status > System
(shown when scanning the network). Use this to differentiate similar devices on your network. Model Number: This is the part number for the router (as shown on our website). Service Tag: The internal tracking number used to track every Araknis Networks product sold. This is required to claim the device on OvrC. - Page 9 Araknis Networks® X10 Series Router Status > System User Interface Manual Port Status Section This provides detailed information for each porton its own line. These can be configured under Settings > LAN > LAN Settings. Interface: Designates the physical port on the router.
- Page 10 Araknis Networks® X10 Series Router Status > System User Interface Manual At the very bottom, the WAN’s current speed is displayed. The color code is as follows: • Gray: Not connected to a device, or the connected device has not negotiated a speed.
-
Page 11: Status > Clients & Services
Araknis Networks® X10 Series Router Status > Clients & Services User Interface Manual Status > Clients & Services This section describes the router firewall services, VPN services, attached clients, and port forwarding settings that are currently in use. This is where you can locate devices are (via IP/DHCP reservation) and determine which services could be affecting system performance. - Page 12 Araknis Networks® X10 Series Router Status > Clients & Services User Interface Manual The router must be configured for each OpenVPN account to be used. Client applications are available for PC and Mac computers and iOS and Android mobile devices.
- Page 13 Araknis Networks® X10 Series Router Status > Clients & Services User Interface Manual Port Forwarding Section This lists all of the port forwarding rules in place. See Settings > Port Forwarding for information on setting these rules. -Return to Table of Contents- ©...
-
Page 14: Status > Ports
Araknis Networks® X10 Series Router Status > Ports User Interface Manual Status > Ports Port Overview Section This gives an at-a-glance status for each port on the router. Each port is color-coded based on its negotiated speed: • Gray: Not connected to a device, or the connected device has not negotiated a speed. -
Page 15: Settings > System
Araknis Networks® X10 Series Router Settings > System User Interface Manual Settings > System System Settings Section Here you can adjust the router’s name and IP address. Names can be up to 63 characters long, and can contain letters, numbers, hyphens, underscores, and periods. - Page 16 Araknis Networks® X10 Series Router Settings > System User Interface Manual integrated approach to setting system time. Using NTP as an option requires Internet access. If you do not wish to use this service, deselect the checkbox and see Manual settings, below.
-
Page 17: Settings > Wan
Araknis Networks® X10 Series Router Settings > WAN User Interface Manual Settings > WAN WAN Settings Section Here you set the WAN port’s name and connection speed. The top shows the WAN being edited. Select the WAN port’s speed and, if the speed is not set to Auto, their duplex setting. - Page 18 Araknis Networks® X10 Series Router Settings > WAN User Interface Manual … With Static IP Selected This sets an unchanging IP address for the WAN. Using this is depenent on your ISP and service plan. … With PPPoE Selected Use this for DSL and other peer-to-peer connections.
- Page 19 Araknis Networks® X10 Series Router Settings > WAN User Interface Manual … With Transparent Bridge Selected This disables all routing functions or your router. Use this if there is an ISP-provided router that must sit on the network. … And at the Bottom: At the bottom, you can set the MTU (maximum transmission unit) either automatically or manually.
- Page 20 Araknis Networks® X10 Series Router Settings > WAN User Interface Manual Multi-WAN Section Network Service Detection regularly checks to ensure that the network connection is active, using a ping test and/or a Domain Resolution test. If it detects that the network is inactive, it performs the action selected in the dropdown.
-
Page 21: Settings > Lan
Araknis Networks® X10 Series Router Settings > LAN User Interface Manual Settings > LAN LAN Settings Section Names can be up to 63 characters long, and can contain letters, numbers, hyphens, underscores, commas, periods, and the following special characters: ! @ # $ % ^ & * ? +. It cannot contain spaces. - Page 22 Araknis Networks® X10 Series Router Settings > LAN User Interface Manual Click on an existing subnet card, or adding a new DHCP Server, opens a dialog for you to set VLAN parameters. The options change (as shown above) based on whether you set the DHCP mode to None, Relay (which forwards DHCP requests to a separate device that serves as that network’s DHCP server), or...
- Page 23 Araknis Networks® X10 Series Router Settings > LAN User Interface Manual DHCP Reservation Table Section This shows a list of all DHCP addresses reserved by your system. Click the Add DHCP Reservation button to a device. The IP address must be in IPv4 format.
-
Page 24: Settings > Firewall
Araknis Networks® X10 Series Router Settings > Firewall User Interface Manual Settings > Firewall This covers the router’s built-in firewall capabilities. Each of these provides added security to your system. Firewall Settings Section When the firewall is enabled, you can activate any or all of: •... - Page 25 Araknis Networks® X10 Series Router Settings > Firewall User Interface Manual Misc. Settings Section UPnP: This enables Universal Plug and Play, a protocol that permits the network to discover and operate devices and applications seamlessly. Bonjour Client: Bonjour is Apple’s implementation of Zero Configuration networking, which allows users to search, locate and set up Apple Access Points.
-
Page 26: Settings > Ddns
Araknis Networks® X10 Series Router Settings > DDNS User Interface Manual Settings > DDNS WAN DDNS Section Dynamic DNS allows you to access the router web interface and other network devices from the Internet using a standard web URL instead of the WAN IP address. -
Page 27: Settings > Port Forwarding
Araknis Networks® X10 Series Router Settings > Port Forwarding User Interface Manual Settings > Port Forwarding The External Address field displays the WAN IP for the system. Network ports direct traffic between software applications running on network devices. Port numbers are always associated with a host IP address and a protocol type, usually TCP, UDP, or both (TCP/UDP). -
Page 28: Settings > Security
Araknis Networks® X10 Series Router Settings > Security User Interface Manual Settings > Security User Accounts Section Here you can create new accounts to access the router. We recommend that you do not give anyone access to the default account. - Page 29 Araknis Networks® X10 Series Router Settings > Security User Interface Manual Access management can work even if there is a port forward rule back to the router’s IP. As long as the access management port isn’t the same as the external port in the remote management section, both can work on the system concurrently.
- Page 30 Araknis Networks® X10 Series Router Settings > Security User Interface Manual Whitelist & Blacklist Section The whitelist and blacklist are tools that allow you to permit or block access of network devices to your router (gateway) and thus the internet. Specify the network devices that you wish to permit or block using either their IP or MAC addresses.
-
Page 31: Wireless > Status (Wi-Fi Model Only)
Araknis Networks® X10 Series Router Wireless > Status (WI-Fi model only) User Interface Manual Wireless > Status (WI-Fi model only) Provides a detailed look at wireless settings and performance for radio status and settings, wireless network configuration and connected client status. - Page 32 Araknis Networks® X10 Series Router Wireless > Status (WI-Fi model only) User Interface Manual Wireless Clients Section This lists all devices currently attached to one of your wireless networks. -Return to Table of Contents- © 2018 Araknis Networks ®...
-
Page 33: Wireless > Settings (Wi-Fi Model Only)
Araknis Networks® X10 Series Router Wireless > Settings (WI-Fi model only) User Interface Manual Wireless > Settings (WI-Fi model only) Global Settings Section The band steering feature encourages dual-band client devices to stay on the 5 GHz band. This frees up resources on the 2.4 GHz band for single-band clients. - Page 34 Araknis Networks® X10 Series Router Wireless > Settings (WI-Fi model only) User Interface Manual Devices on the network. On the 2.4GHz radio, there are only three non-overlapping channels: 1, 6 and 11. Select a channel as far away from close-numbered channels as possible.
- Page 35 Araknis Networks® X10 Series Router Wireless > Settings (WI-Fi model only) User Interface Manual WPS Section WPS (Wi-Fi Protected Setup) allows setup of WPS-equipped Wi-Fi devices. Instead of sharing the SSID and security credentials with a client, WPS connects clients using a push button or PIN entry method.
-
Page 36: Tools
Araknis Networks® X10 Series Router Tools User Interface Manual Tools Ping Section Enter an IP address here and click the Ping button to see if the target device responds. If it does, the system displays a measure of how long it took the device to respond. - Page 37 Araknis Networks® X10 Series Router Tools User Interface Manual Trace Route Section This displays all relays between your router and the target URL, as well as the delays encountered by the data packet sent. Enter the IP address of a device or web page. Click the Start button.
-
Page 38: Advanced > Static Route
Araknis Networks® X10 Series Router Advanced > Static Route User Interface Manual Advanced > Static Route Static routing is used to create routes to other subnets using a fixed routing table. Static routes are commonly used to allow traffic between subnets on different routers. For example, in a large office network, there is a subnet configured for the first floor inside of Router 1 with the IP address 192.168.1.0. -
Page 39: Advanced > Nat
Araknis Networks® X10 Series Router Advanced > NAT User Interface Manual Advanced > NAT This configures devices on the LAN so that they appear to have a specific public (WAN) IP address. You must enable this to use and edit NAT entries. -
Page 40: Advanced > Vlans
Araknis Networks® X10 Series Router Advanced > VLANs User Interface Manual Advanced > VLANs Virtual Local Area Networks (VLANs) are used to segment traffic on the LAN. Proper setup and use of VLANs can increase the reliability and security of the network. -
Page 41: Advanced > Vpn
Araknis Networks® X10 Series Router Advanced > VPN User Interface Manual Advanced > VPN A Virtual Private Network (VPN) provides a connection between different networks through a secure tunnel over the Internet. Data sent through the VPN tunnel is encrypted for privacy even when connected to a public or shared network that isn’t secure. - Page 42 Araknis Networks® X10 Series Router Advanced > VPN User Interface Manual key for the client application to communicate with the server and open a connection. The router must be configured for each OpenVPN account that will be used. Client applications are available for PC and Mac computers and iOS and Android mobile devices.
-
Page 43: Advanced > Ipv6
Araknis Networks® X10 Series Router Advanced > IPV6 User Interface Manual Advanced > IPV6 IP Mode Section This section defines how the router handles IPv6 addresses sent to the system. Dual-stack is fine (and recommended) for most applicactions. The router recognizes both address styles and parses out whichever address is unnecessary. - Page 44 Araknis Networks® X10 Series Router Advanced > IPV6 User Interface Manual LAN Settings Section IPv6 Address: Enter the LAN IPv6 Address. Prefix Length: Set the IPv6 equivalent to the IPv4 subnet mask. This is done by specifying the number of bits rather than using IP notation.
- Page 45 Araknis Networks® X10 Series Router Advanced > IPV6 User Interface Manual … With PPPoE Selected When used with IPv6 on the WAN side, PPPoE is similar to IPv4 in that the WAN connection is authenticated using encapsulated Point-to-Point Protocol (PPP) frames.
-
Page 46: Advanced > Local Dns
Araknis Networks® X10 Series Router Advanced > Local DNS User Interface Manual Advanced > Local DNS This creates a local DNS server on the router for speedier results and forwarding. Use this expressly for devices in the local network (for example, to create a URL like backporchcamera.myhome.com). -
Page 47: Advanced > Snmp
Araknis Networks® X10 Series Router Advanced > SNMP User Interface Manual Advanced > SNMP Simple Network Management Protocol is used by network administrators to monitor the performance and settings of network devices. Configure SNMP to communicate with management devices in place on the network. - Page 48 Araknis Networks® X10 Series Router Advanced > SNMP User Interface Manual SNMPv3 Settings Section SNMP3 adds the ability to set up users with a more robust authentication scheme. The user table lists all users currently enabled. Trap Receiver IP Address: The IPv4 address to send all the Trap Community messages from all capable SNMP devices on the network.
-
Page 49: Advanced > Qos
Araknis Networks® X10 Series Router Advanced > QoS User Interface Manual Advanced > QoS This section is for advanced users only. QoS, or quality of service, is a protocol that tries to optimize traffic across the network. This is an advanced feature that rarely needs to be implemented except in large congested networks that require prioritization of network services. - Page 50 Araknis Networks® X10 Series Router Advanced > QoS User Interface Manual CoS to DCSP Mapping Section This section allows mapping of CoS values to DSCP values and ranges, as well as an associated queue. Consider each row as the mapping between these reference buckets.
-
Page 51: System Log
Araknis Networks® X10 Series Router System Log User Interface Manual System Log System Log Section Here you see recorded activities and status changes. -Return to Table of Contents- © 2018 Araknis Networks ®... -
Page 52: Specifications
Araknis Networks® X10 Series Router Specifications User Interface Manual Specifications Interfaces Features AN-110-RT-2L1W AN-110-RT-2L1W-WIFI WAN - RJ45 10/100/1000 Base-T 1 LAN - RJ45 10/100/1000 Base-T LAN/WAN - Combo RJ45/SFP 10/100/1000Base-T 1 (USB2.0) - Not Available at 1 (USB2.0) - Not Available at... - Page 53 Araknis Networks® X10 Series Router Specifications User Interface Manual L3 Features Features AN-110-RT-2L1W AN-110-RT-2L1W-WIFI WAN/LTE Link Failover Not Available at Launch Not Available at Launch Static Routing Inter-VLAN Routing DHCP Server DHCP Client DHCP Relay DNS Relay DDNS 1:1 NAT...
- Page 54 Araknis Networks® X10 Series Router Specifications User Interface Manual VPN Features Features AN-110-RT-2L1W AN-110-RT-2L1W-WIFI PPTP Server PPPoE OpenVPN Management Features AN-110-RT-2L1W AN-110-RT-2L1W-WIFI Web Management SNMP v1,2c,3 OvrC Pro Embedded Download/Upload Config File System Log HTTP & HTTPs System Time NTP/Manually...
