Instruction Manual
CB6012A and CB6024A
Battery Charger
Programming the device configuration:
Note that device programming is possible only after the device is turned on,
when the battery is not connected. While the user interface shows device
activity, to enter programming mode, press the button for more than 2 seconds
until the LED flashes ORANGE. When you release the button, the LED flashes
once in GREEN followed by a pause. This means that the battery chemistry is
open lead. Press the button repeatedly to scroll through the chemistries to the
desired one-the LED displays a number of GREEN flashes corresponding to the
chemistry according to Table 2. Confirm by pressing the button for more than 2
seconds when the desired chemistry is displayed. The LED flashes GREEN to
indicate that the chemistry has been tentatively set. Note that the chemistry
must be selected: a short press of the button when NiCd is displayed will restart
the chemistry selection from Open Lead. After confirming the chemistry with a
long press, the enabling state of the power function can be selected with the
same logic, except that the LED will flash RED. When the desired option
(enabled or disabled) is displayed, long press the button to confirm the
selection-the LED will flash RED for confirmation.
When programming is completed, the device summarizes the new
configuration as described in "Displaying the current device configuration,"
then resumes the normal display of device activity.
NOTE that the entire programming process must be completed in order for the
configuration to be confirmed and maintained even during power-cycling. If the
button is not pressed for 60 seconds during the programming process, the
programming process stops and the device returns to displaying device
activity without changing settings.
4 Standards and Certification
4.1 Immunity and Emission
The CE mark in conformity to EMC 2014/30/EU: Electromagnetic Compatibility
Directive; 2014/35/EU: Low Voltage Directive; ROHS 2011/65/EU: Restriction
of the use of certain Hazardous Substances in Electrical and Electronic
Equipment (RoHS), as amended by 2015/863/EU
EMC Immunity: EN61000-6-2
EMC Emission: EN61000-6-3, EN 55022 Class B
4.2 Electrical Safety for mounting
According to:
Electrical Equipment for Machinery EN 60204
Electrical safety (of information technology equipment) IEC/EN
EN62368-1.
Safety requirements for electrical equipment for measurement,
control and Laboratory use IEC/EN 61010
