Page 1 761 Let’s get started...
Page 2 Connecting – Stereo Connect the preamp to the corresponding INPUT connectors. Connect the SPEAKER OUTPUT to the loudspeaker terminals (positive [+] to red and negative [–] to black). Toggle the STEREO/MONO switch to STEREO, and skip to Step 2. STEREO SPEAKER SPEAKER OUTPUT...
Page 3 Mono Connecting – Connect the preamp to the LEFT CHANNEL input. Connect the positive [+] LEFT CHANNEL binding post to the positive loudspeaker terminal, and connect the positive [+] RIGHT CHANNEL binding post to the negative loudspeaker terminal. Toggle the STEREO/MONO switch to MONO. STEREO MONO (BRIDGED)
Page 4: Connecting Power
Network Connecting – Power & Connect the supplied power cable between the IEC connector and an electrical outlet. For use with MOONLink (optional), connect the two devices with the Ethernet cable, or connect the cable to a network router.
Page 5 3 Starting – Power Toggle the AC POWER rocker switch to On [I]. AC POWER...
Page 6 4 Starting – Standby Press the Standby button. Standby...
Page 7 5 Discovering – Website To view the User Manual and other information about this product, visit our website: simaudio.com...
