Contents
1
General safety instructions _______________________________ 2
2.
Installation ___________________________________________ 9
3.
Product description ____________________________________ 15
4.
Operating instructions __________________________________ 20
5.
Cleaning and maintenance ______________________________ 21
6.
Troubleshooting ______________________________________ 22
Thank you for choosing one of our products.
You are advised to read this manual carefully; it contains all the
information you need about the right conditions for the proper, safe use
of your dishwasher.
This manual contains only the basic information required to use the
appliance. The complete manual can be obtained from
www.smeg.com/download-manuals
by entering the product code shown on the plate attached to the inner
right hand edge of the dishwasher door.
The manual can be accessed quickly via the QR code using a device
with a QR reader application.
1
Advertisement
Related Manuals for Smeg Classica Aesthetic STX235CLLO
Summary of Contents for Smeg Classica Aesthetic STX235CLLO
-
Page 1: Table Of Contents
This manual contains only the basic information required to use the appliance. The complete manual can be obtained from www.smeg.com/download-manuals by entering the product code shown on the plate attached to the inner right hand edge of the dishwasher door. -
Page 2: General Safety Instructions
Warnings TRANSLATION OF THE ORIGINAL INSTRUCTIONS 1 General safety instructions This manual is an integral part of the appliance; it must always be kept intact together with the dishwasher for future reference (even if sold). Before using appliance, carefully read instructions contained in this manual. - Page 3 Warnings Never leave waste packaging unattended. Do not allow children to play with packaging materials. Separate waste packaging materials by type and consign them to the nearest recycling centre. The plate with the technical data, serial number and marking is in a visible position on the inside edge of the door.
- Page 4 Warnings Building-in the appliance underneath a hob is absolutely forbidden. Installing a hob on top of free- standing appliance is absolutely forbidden. To ensure stability, install the appliance only under continuous worktop, securely fixed to adjacent cabinets. If the appliance is installed in a high cabinet, both the appliance and the cabinet must be adequately fixed.
- Page 5 Warnings The appliance must be connected to the water supply by means of new hoses. Briefly test the appliance after installation. Run a wash cycle with a temperature of between 45 and 70°C with the dishwasher empty and using a specific dishwasher detergent.
- Page 6 Warnings Some detergents are strongly alkaline. Avoid contact with the skin and eyes. Detergents can be extremely dangerous if swallowed. They contain substances capable of causing permanent damage to the mouth and throat, and even leading to suffocation. Observe all the safety instructions on the packaging of these products.
- Page 7 Warnings void the warranty but may also put the user’s safety at risk. In the event of a fault, disconnect the dishwasher from the electrical power supply and shut off the water tap. In the event of damage to the supply cord, have it replaced by the manufacturer or an authorised technical service centre.
- Page 8 Warnings 1.1 Declaration of conformity The appliance complies with the essential requirements of the following European directives: - 2009/125/EC - 2011/65/EU - 2014/35/EU - IEC/EN 62471, risk group 1, for models with internal lighting. IEC/EN 61770 1.2 Disposal This appliance must be disposed of separately from other waste (directives 2012/19/EC).
-
Page 9: Installation
Warnings 2. Installation 2.1 Technical characteristics Water supply pressure min. 0,05 - max. 0,9 MPa (min. 0.5 – max. 9 bar) Water supply temperature max. 60°C Capacity 12-13 standard place settings Class of protection against IPX0 moisture Protection against electric class I shock Electrical data... - Page 10 Warnings A hole at least 8 cm in diameter is required to allow the power supply cable and hoses to pass. At the end of the installation, perform a short test of the appliance: open the water tap and check that there are no leaks.
- Page 11 Warnings For free-standing models only - Installing a hob on top of a free-standing dishwasher is absolutely forbidden. - If the appliance is accessible from one side, the door hinge area has to be covered for safety reasons (risk of injury). The covers are available as an accessory and can be ordered through the Technical Assistance Service.
- Page 12 Warnings 2.2 Water supply connection CONNECTING TO THE WATER SUPPLY Connect the intake hose to a cold water supply with ¾” gas thread, inserting the filter A supplied with the dishwasher. Take care to screw the hose firmly into place with your hands and then complete by tightening about ¼...
- Page 13 Warnings DRAIN CONNECTION Insert the dishwasher’s drain hose into a drain pipe having a diameter of at least 4 cm, or alternatively, place it inside the kitchen sink using the plastic support provided, taking care not to crush or excessively bend the hose.
- Page 14 Installation 2.3 Electrical connection Check that the voltage and the frequency of the mains match the ratings on the name plate of the appliance positioned on the inner edge of the door. The plug on the supply cord and the corresponding socket outlet must be of the same type and meet the regulations in force.
-
Page 15: Product Description
User instructions 3. Product description 3.1 Control panel All the dishwasher controls are grouped on the upper panel. Switching on, programming, switching off etc. are only possible when the door is open. ON/OFF BUTTON OPTION BUTTONS/LIGHTS SELECTED PROGRAM BUTTONS/LIGHTS START/PAUSE BUTTON TOP DISPLAY (3 FIGURES) SALT WARNING LIGHT RINSE AID WARNING LIGHT... - Page 16 User instructions SWITCHING ON With the door open, press the ON/OFF button on the top panel to switch on the dishwasher. The LED on the button and the DISPLAY light up. PROGRAMMING All programming operations are only possible with the door open and the dishwasher switched on.
- Page 17 User instructions PROGRAMS TABLE Program SOAK cold 0,02 AUTO When this cycle is selected, the dishwasher recognizes the type of soil SENSOR and automatically adjusts the washing parameters. (**) The program ends with a drying cycle. 44(2)/ 280(2)/ 0,734(2)/ ● 48°C cold 1,19...
- Page 18 User instructions Automatic door opening – Dry Assist Automatic door opening is included in programs indicated with ** in the first column (*) Standard program according to EN60436. The DRY ASSIST option (if the button is present) must be active. (1) Consumption and program duration are measured according to EN 60436.
- Page 19 User instructions Description of the programs: SOAK EXPRESS 27’ Rinses dishes while waiting to be Quick cycle for lightly soiled dishes, washed. washed immediately after use. AUTO SENSOR CRYSTAL 45° Normally soiled mixed loads such as Wine glasses and lightly soiled fine dishes and pans, even with dried-on china.
-
Page 20: Operating Instructions
User instructions 4. Operating instructions After having installed the dishwasher, remove the basket retainers. 4.1 Adding the salt The salt prevents the formation of scale deposits. Unscrew the cap of the salt container. Only for the first time, fill the container with a litre of water. -
Page 21: Cleaning And Maintenance
User instructions 5. Cleaning and maintenance Before carrying out any work, always unplug the appliance from the electrical supply or switch off the omnipolar circuit breaker. CLEANING THE WATER INTAKE FILTER Close the water supply tap, unscrew the end of the water intake hose, remove the filter A and clean it under running water. -
Page 22: Troubleshooting
User instructions 6. Troubleshooting The dishwasher has an autodiagnosis system capable of detecting and indicating a preset series of possible malfunctions. TABLE OF MALFUNCTIONS DETECTED BY THE AUTODIAGNOSIS SYSTEM FAULT DESCRIPTION Error 01 Anti-flooding system tripped (where installed). Error 02 The system that limits the water level in the dishwasher has been tripped.
