OSD Functions

ICON
CONTROL
H. POSITION
V. POSITION
H.SIZE
V.SIZE
V. LINEARITY
PINCUSHION
TRAPEZOID
PIN BALANCE
PARALLELOGRAM
T. PIN CORNER
B. PIN CORNER
T. PIN BALANCE
B. PIN BALANCE
COLOR TEMP
Adjust the position of the display horizontally (left or right).
Adjust the position of the display vertically (up or down).
Adjust the display width (horizontal size).
Adjust the display height (vertical size).
Adjust the vertical linearity.
Adjust the left and right margins for more convex or more concave margins.
Adjust the trapezoid of the screen by moving the lines inward or outward.
Adjust the side balance when the sides of the screen are bowed towards left or right.
Adjust the parallelogram when the screen is leaning left or right.
Adjust the pin corner top when the top sides of the screen are bowed.
Adjust the pin corner bottom when the bottom sides of the screen are bowed.
Adjust the side pin corner balance top when the top sides of the screen are bowed
towards left or right.
Adjust the side pin corner balance bottom when the bottom sides of the screen are bowed
towards left or right.
Choose different preset color temperatures or set your own customized color parameters.
