- Page 1 Washing Machine User’s Manual WCC 8632 XW WCC 8632 XS WCC 8632 XB Document Number= 2302061116_EN / 06-02-17.(10:15)
- Page 2 This product was manufactured using the latest technology in environmentally friendly conditions.
-
Page 3: Important Instructions For Safety And Environment
1 Important instructions for safety and environment This section contains safety instructions that will help protect from risk of personal injury or property damage. Failure to follow these instructions shall void any warranty. 1.1 General safety • This product can be used by children at and above 8 years old and by persons whose physical, sensory or mental capabilities were not fully developed or who lack expe- rience and knowledge provided that they are supervised or trained on the safe usage of the product and the risks it brings out. -
Page 4: Intended Use
• If the power cable is damaged, it must be replaced by the manufacturer, after sales service or a similarly qualified person (preferably an electrician) or someone designa- ted by the importer in order to avoid possible risks. • Place the product on a rigid, flat and level surface. • Do not place it on a long-pile rug or similar surfaces. • Do not place the product on a high platform or near the edge on a cascaded surface. • Do not place the product on the power cable. • Never use sponge or scrub materials. These will damage the painted, chrome plated and plastic surfaces. 1.2 Intended use • This product has been designed for domestic use. It is not suitable for commercial use and it must not be used out of its intended use. • The product must only be used for washing and rinsing of laundry that are marked accordingly. -
Page 5: Compliance With Weee Directive
1.6 Compliance with WEEE Directive This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). This product has been manufactured with high quality parts and materials which can be reused and are suitable for recycling. Do not dispose of the waste product with normal domestic and other wastes at the end of its servi- ce life. -
Page 6: Connecting Water Supply
1. Loosen all the bolts with a suitable spanner until they 1. Tighten all hose nuts by hand. Never use a tool when rotate freely (C) . tightening the nuts. 2. Remove transportation safety bolts by turning them gently. 2. Open the taps completely after making the hose connection to check for water leaks at the connection points. If any leaks occur, turn off the tap and remove the nut. - Page 7 3 Preparation • If the length of the hose is too short, use it by adding an original extension hose. Length of the hose may 3.1 Sorting the laundry not be longer than 3.2 m. To avoid water leak failures, • Sort laundry according to type of fabric, colour, and the connection between the extension hose and the degree of soiling and allowable water temperature. drain hose of the product must be fitted well with an • Always obey the instructions given on the garment tags.
- Page 8 3.4 Initial use Detergent Drawer The detergent drawer is composed of three compartments: Before starting to use the product, make sure that all – (1) for prewash preparations are made in accordance with the instructions in – (2) for main wash sections “Important safety instructions” and “Installation”.
- Page 9 adjusting detergent amount Tablet detergents may leave residues in the detergent The amount of washing detergent to be used depends compartment. If you encounter such a case, place the on the amount of laundry, the degree of soiling and water tablet detergent between the laundry, close to the lower part of the drum in future washings.
-
Page 10: Tips For Efficient Washing
Clothes 3.8 Tips for efficient washing Dark colours (Recommended temperature range based Clothes on soiling level: cold -40 °C) Light colours and whites Liquid detergents suitable for colours (Recommended temperature range based Heavily Soiled and dark colours can be used at dosages on soiling level: 40-90 °C) recommended for heavily soiled clothes. -
Page 11: Operating The Product
4 Operating the product 4.1 Control panel 1 - Programme Selection knob (Uppermost position On / Off) 5 - Start / Pause button 2 - Display 6 - Auxiliary Function buttons 3 - Delayed Start Indicator 7 - Spin Speed Adjustment button 4 - Programme Follow-up indicator 8 - Temperature Adjustment button 4.2 Preparing the machine • Woollens 1.Make sure that the hoses are connected tightly. Use this programme to wash your woolen clothes. Select 2.Plug in your machine. -
Page 12: Special Programmes
4.6 Special programmes • Delicate 20° You can wash your delicate clothes in this programme. For specific applications, select any of the following It washes with a gentler action without any interim spins programmes. compared to the Synthetics programme. It should be used • Rinse for clothes for which delicate washing is recommended. Use this programme when you want to rinse or starch • Hand wash separately. - Page 13 4.9 Programme and consumption table Auxiliary functions Selectable Programme temperature range °C 60** 1.07 1600 40-60 0.695 Cotton Eco 60** 1600 40-60 40** 0.68 1600 40-60 2.60 1600 Cold-90 Cottons 1.80 1600 Cold-90 0.90 1600 Cold-90 1.00 Cold-60 Synthetics 0.58 Cold-60 2.20 1400...
-
Page 14: Auxiliary Function Selection
4.10 Auxiliary function selection If you want to spin the laundry held in water, adjust the Spin Speed and press Start / Pause button. Select the required auxiliary functions before starting Program resumes. Water is drained, laundry is spun and the the program. Furthermore, you may also select or programme is completed. cancel auxiliary functions that are suitable to the running • Pet hair removal programme without pressing the Start / Pause button when This function helps to remove pet hair that remain on your the machine is operating. - Page 15 4.11 Starting the programme If the machine does not pass to the spinning step, Rinse 1. Press Start / Pause button to start the programme. Hold function might be active or the automatic unbalanced 2. Programme follow-up light showing the startup of the load detection system might be activated due to the unbalanced distribution of the laundry in the machine. programme will turn on. 4.14 Loading door lock If no programme is started or no button is pressed within 1 minute during programme selection process, the There is a locking system on the loading door of the...
-
Page 16: Maintenance And Cleaning
3 After cleaning, replace the siphon back to its seating and Depending on the step where the programme was push its front section downwards to make sure that the canceled in, you may have to put detergent and softener locking tab engages. again for the programme you have selected anew. -
Page 17: Cleaning The Water Intake Filters
5.4 Cleaning the water intake filters 2 Open the filter cap. There is a filter at the end of each water intake valve at the rear of the machine and also at the end of each water intake hose where they are connected to the tap. These filters prevent foreign substances and dirt in the water to enter the washing machine. -
Page 18: Technical Specifications
6 Technical specifications Complying Commission Delegated Regulation (EU) No 1061/2010 Supplier name or trademark Beko WCC 8632 XW/ WCC 8632 XS/ WCC 8632 XB Model name Rated capacity (kg) Energy efficiency class / Scale from A+++ (Highest Efficiency) to D (Lowest Efficiency) A+++ Annual Energy Consumption (kWh) Energy consumption of the standard 60°C cotton programme at full load (kWh) 1.070 Energy consumption of the standard 60°C cotton programme at partial load (kWh) -
Page 19: Troubleshooting
7 Troubleshooting Program does not start after closing the door. • Start / Pause / Cancel button was not pressed. >>> *Press the Start / Pause / Cancel button. Programme cannot be started or selected. • Washing machine has switched to self protection mode due to a supply problem (line voltage, water pressure, etc.). >>> To cancel the programme, turn the Programme Selection knob to select another programme. Previous programme will be cancelled. (See “Canceling the programme”) Water in the machine. - Page 20 Dark wash Dark wash Cottons Pre-wash Main Rinse Wash Spin Delicate Pet hair Door Ready (Darkcare) (Darkcare) wash removal Drain Anti- Child- Hand BabyProtect Cotton Woollens expres 14 Daily mini 30 Duvet On/Off Super short (Pump) creasing proof lock Wash (Bedding) express Temperature...
- Page 21 www.beko.com...
