- Page 1 WCY 71232 HPTL Washing Machine User’s Manual Get other manuals https://www.bkmanuals.com...
-
Page 2: Important Instructions For Safety And Environment
1 Important instructions for safety and person (preferably an electrician) or someone designated by the importer in order to avoid possible risks. environment 1.2 Intended use This section contains safety instructions that will help protect • This product has been designed for domestic use. It is not from risk of personal injury or property damage. Failure to suitable for commercial use and it must not be used out follow these instructions shall void any warranty. of its intended use. -
Page 3: Appropriate Installation Location
2 Installation 2. Remove transportation safety bolts by turning them gently. Refer to the nearest Authorised Service Agent for installation 3. Attach the plastic covers supplied in the User Manual bag of the product. To make the product ready for use, review into the holes on the rear panel. (P) the information in the user manual and make sure that the electricity, tap water supply and water drainage systems are appropriate before calling the Authorized Service Agent. If they are not, call a qualified technician and plumber to have any necessary arrangements carried out. Preparation of the location and electrical, tap water and waste water installations at the place of installation is Keep the transportation safety bolts in a safe place to under customer's responsibility. -
Page 4: Adjusting The Feet
points. If any leaks occur, turn off the tap and remove the 1. Loosen the lock nuts on the feet by hand. nut. Retighten the nut carefully after checking the seal. To 2. Adjust the feet until the product stands level and prevent water leakages and damages caused by them, balanced. keep the taps closed when the machine is not in use. 3. Tighten all lock nuts again by hand. 2.5 Connecting to the drain • The end of the drain hose must be directly connected to the wastewater drain or to the washbasin. Your house will be flooded if the hose comes warning out of its housing during water discharge. Moreover, there is risk of scalding due to high washing temperatures! To prevent such situations and to ensure smooth water intake and discharge of the machine, fix the end of the Do not use any tools to loosen the lock nuts. - Page 5 3 Preparation 3.4 Initial use Before starting to use the product, make sure that all 3.1 Sorting the laundry preparations are made in accordance with the instructions in • Sort laundry according to type of fabric, colour, and sections “Important safety instructions” and “Installation”. degree of soiling and allowable water temperature. To prepare the product for washing laundry, perform first • Always obey the instructions given on the garment tags. operation in Drum Cleaning programme. If your product 3.2 Preparing laundry for washing is not equipped with Drum Cleaning programme, perform the Initial Use procedure in accordance with the methods • Laundry items with metal attachments such as, underwired bras, belt buckles or metal buttons will described under “5.2 Cleaning the loading door and the damage the machine. Remove the metal pieces or wash drum” section of the user manual.
-
Page 6: Using Detergent And Softener
Adjusting detergent amount The loading door is locked while a programme is running. The amount of washing detergent to be used depends The door can only be opened a while after the programme on the amount of laundry, the degree of soiling and water comes to an end. hardness. In case of misplacing the laundry, noise and warning • Do not use amounts exceeding the dosage quantities vibration problems may occur in the machine. recommended on the detergent package to avoid 3.7 Using detergent and softener problems of excessive foam, poor rinsing, financial savings and finally, environmental protection. When using detergent, softener, starch, fabric dye, bleach • Use lesser detergent for small amounts or lightly soiled or limescale remover read the manufacturer's instructions... -
Page 7: Tips For Efficient Washing
• Use just a little amount (approx. 50 ml) of bleaching agent Using starch and rinse the clothes very well as it causes skin irritation. • Add liquid starch, powder starch or the fabric dye into the Do not pour the bleaching agent onto the clothes and do softener compartment. not use it for coloured clothes. • Do not use softener and starch together in a washing • When using oxygen based bleaches, select a programme cycle. that washes at a lower temperature. • Wipe the inside of the machine with a damp and clean • Oxygen based bleaches can be used together with cloth after using starch. -
Page 8: Operating The Product
4 Operating the product 4.1 Control panel 1 - Programme Selection knob (Uppermost position On/Off) 5 - Start / Pause button 2 - Display 6 - Auxiliary Function buttons 3 - Delayed Start button (in some models) 7 - Spin Speed Adjustment button 4 - Programme Follow-up indicator 8 - Temperature Adjustment button 8 / 20 EN... -
Page 9: Preparing The Machine
4.2 Preparing the machine 4.5 Additional programmes Make sure that the hoses are connected tightly. Plug in your For special cases, additional programmes are available in machine. Turn the tap on completely. Place the laundry in the the machine. machine. Add detergent and fabric softener. Additional programmes may differ according to the 4.3 Programme selection model of the machine. -
Page 10: Special Programmes
4.6 Special programmes For specific applications, select any of the following programmes. • Rinse Use this programme when you want to rinse or starch separately. • Spin+Drain Use this programme to apply an additional spin cycle for your laundry or to drain the water in the machine. Before selecting this programme, select the desired spin speed and press Start / Pause button. First, the machine will drain the water inside of it. Then, it will spin the laundry with the set spin speed and drain the water coming out of them. If you wish to drain only the water without spinning your laundry, select the Pump+Spin programme and then select the No Spin function with the help of Spin Speed Adjustment button. Press Start / Pause button. -
Page 11: Programme And Consumption Table
4.9 Programme and consumption table Auxiliary functions Programme Temperature Cotton 2.30 1600 • • • • Cold-90 Cotton 1.54 1600 • • • • Cold-90 Cotton 0.85 1600 • • • • Cold-90 Cotton Eco 60** 1.175 1600 40-60 Cotton Eco 60** 0.934 1600 40-60... -
Page 12: Auxiliary Function Selection
4.10 Auxiliary function selection Use the following auxiliary functions according to your prevent them from getting wrinkled when there is no water daily needs. Select the desired auxiliary functions before in the machine. Press Start / Pause button after this process starting the programme. -
Page 13: Progress Of Programme
the Loading Door while the Loading Door light is off, you If the Programme Selection knob is turned when the have to cancel the current programme; see "Canceling the Child Lock is active, “Con” appears on the display. programme". The Child Lock does not allow any change in the programmes and the selected temperature, speed and Changing the selections after auxiliary functions. programme has started Even if another programme is selected with the Switching the machine to pause mode Programme Selection knob while the Child Lock is Press the Start / Pause button to switch the machine to active, previously selected programme will continue pause mode while a programme is running. The light of running. -
Page 14: Maintenance And Cleaning
5 Maintenance and cleaning Repeat Drum Cleaning process in every 2 months. Service life of the product extends and frequently faced problems decrease if cleaned at regular intervals. 5.1 Cleaning the detergent drawer Use an anti-limescale suitable for the washing machines. Clean the detergent drawer at regular intervals (every 4-5 washing cycles) as shown below in order to prevent After every washing make sure that no foreign substance is accumulation of powder detergent in time. left in the drum. 1. Press the dotted point on the siphon in the softener compartment and pull towards you until the compartment is removed from the machine. If the holes on the bellow shown in the figure is blocked, If more than normal amount of water and softener open the holes using a toothpick. -
Page 15: Draining Remaining Water And Cleaning The Pump Filter
5.5 Draining remaining water and Discharging the water when the product has an emergency draining hose: cleaning the pump filter The filter system in your machine prevents solid items such as buttons, coins and fabric fibers clogging the pump impeller during discharge of washing water. Thus, the water will be discharged without any problem and the service life of the pump will extend. If the machine fails to drain water, the pump filter is clogged. Filter must be cleaned whenever it is clogged or in every 3 months. Water must be drained off first to clean the pump filter. -
Page 16: Technical Specifications
6 Technical specifications Models (EN) WCY 71232 HPTL Maximum dry laundry capacity (kg) Height (cm) Width (cm) Depth (cm) 56.5 Net weight (±4 kg.) Electrical input (V/Hz) 220-240V~/50Hz Total current (A) 2000-2350 Total power (W) 1200 Spin speed (rpm max.) 1.00... -
Page 17: Troubleshooting
7 Troubleshooting Programme cannot be started or selected. • Washing machine has switched to self protection mode due to a supply problem (line voltage, water pressure, etc.). >>> To cancel the programme, turn the Programme Selection knob to select another programme. Previous programme will be cancelled. (See “Canceling the programme”) Water in the machine. • Some water might have remained in the product due to the quality control processes in the production. >>> This is not a failure; water is not harmful to the machine. -
Page 18: Product Fiche
PRODUCT FICHE Complying Commission Delegated Regulation (EU) No 1061/201 Supplier name or trademark Beko WCY 71232 HPTL Model name Rated capacity (kg) Energy efficiency class Annual Energy Consumption (kWh) Energy consumption of the standard 60°C cotton programme at full load (kWh) 1.175... - Page 19 19 / 20 EN Washing Machine / User’s Manual Get other manuals https://www.bkmanuals.com...
- Page 20 20 / 20 EN Washing Machine / User’s Manual Get other manuals https://www.bkmanuals.com...
