OWNER'S MANUAL
Safety and Reference
Please read this manual carefully
before operating your set and retain
it for future reference.
OLED77M3PUA
OLED83M3PUA
The model and serial number of the product are
located on the back and on one side of the product.
Record them below in case you ever need service.
Model
Serial No.
*MFL719463362306REV01*
Copyright © 2023 LG Electronics Inc.
All Rights Reserved.
Supplier`s Declaration of
Conformity
Trade Name
LG
Responsible
LG Electronics USA,
Party
Inc.
Address
111 Sylvan Avenue,
North Building,
Englewood Cliffs,
NJ 07632
E-mail
lg.environmental@
lge.com
LG Customer Information Center
For inquires or comments, visit www.
lg.com or call;
USA, Consumer
1-800-243-0000
User
USA, Commercial
1-888-865-3026
User
1-888-542-2623 CANADA
Register your product Online!
www.lg.com
www.lg.com
Printed in Korea

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OLED83M3PUA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LG OLED83M3PUA

  • Page 1 Printed in Korea Copyright © 2023 LG Electronics Inc. All Rights Reserved. OWNER’S MANUAL Safety and Reference Please read this manual carefully before operating your set and retain Supplier`s Declaration of it for future reference. Conformity Trade Name OLED77M3PUA...
  • Page 2: Important Safety Instruction

    By using this product, you agree that all disputes between you and LG arising out of or relating in any way to this product (including but not limited to warranty disputes) shall be resolved exclusively through binding arbitration on an individual basis. The terms of the arbitration agreement (including details on the procedure for resolving disputes) is available at www.lg.com/us/arbitration (USA) or www.lg.com/ca_en/arbitration (Canada).
  • Page 3 Warning! Safety instructions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. This symbol is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
  • Page 4 • Be careful if you have pets this product. • Cleaning • Use only an authorized attachments / accessories approved by LG - When cleaning, unplug the power cord and wipe gently with a soft/ Electronics. Otherwise, this may result in fire, electric shock, malfunction, dry cloth.
  • Page 5: Installation

    Installation Lifting and moving the TV Screen When moving or lifting the TV screen, read the following to prevent the • Do not apply foreign substances (oils, lubricants, etc.) to the screw parts TV screen from being scratched or damaged and for safe transportation when assembling the product.
  • Page 6: Mounting To The Wall

    We recommend that you use an LG brand wall mount. The LG wall mount is easy to adjust or to connect the cables. When you do not use LG’s wall mount bracket, use a wall mount bracket where the device is adequately secured to the wall with enough space to allow connectivity to external devices.
  • Page 7: Turning On The Tv

    Starting TV Turning on the TV Using hands-free voice control You can simply operate the TV functions, using the button. To use hands-free voice control, follow these steps. • The voice recognition microphone is on the front bottom of the Zero Connect Box.
  • Page 8 Precautions before using wireless TV Wireless TVs use high-frequency radio waves of 60 GHz to transmit a large amount of data in a very short time, enabling wireless transmission of high-quality video and audio. The 60 GHz frequency band used in wireless TVs is advantageous for large-capacity data transmission, has good linearity, and is well-suited for transmission and reception in a specific direction.
  • Page 9 Details for wireless TV (TV Screen + Zero Connect Box) Viewing appearance TV Screen Zero Connect Box (WM23EA) Front Back Side...
  • Page 10 Wireless signal receiver & Power button Note This area has an antenna that receives the video transmitted from the • The wireless TV consists of the TV Screen and Zero Connect Box. antenna of the Zero Connect Box. • The Zero Connect Box transmits video and audio wirelessly to the TV If there are any obstacles around this area, the screen may be disconnected or Screen.
  • Page 11 Wireless default placing and setting Recommended installation methods (installing Zero Connect Box) Frontal installation Diagonal installation Side installation Bottom installation Installation don’ts (installing Zero Connect Box) Installing on shelf above TV Screen Installing on wall behind TV Screen Installing behind wall Installing inside the cabinet...
  • Page 12 Checking before turning on wireless TV Clearing obstacles • Remove any obstacles between the TV Screen and Zero Connect Box. If there are obstacles, the wireless signal is attenuated and causes screen disconnection. Placing Zero Connect Box on top of cabinet •...
  • Page 13 Checking after turning on wireless TV Checking wireless signal strength on Zero Connect Box (top LED color) • Once default placing and settings are completed, check the color of the top LED in front of the sliding button of the Zero Connect Box. •...
  • Page 14 Precaution Notes Wireless Precaution Notes • The quality of the image and audio may deteriorate depending upon the installation environment (installed location, surrounding devices, obstacles, and distance). • Do not place obstacles between the TV Screen and Zero Connect Box. The screen may fail to display due to interference from obstacles. •...
  • Page 15 Installing on shelf above TV Screen Installing on wall behind TV Screen Installing behind wall Installing inside the cabinet Placing electronic devices on top of Zero Connect Box...
  • Page 16 Installing according to usage scenarios Installing Zero Connect Box in front of TV Screen Checking before turning on wireless TV If you have installed the Zero Connect Box in front of the TV Screen, follow these steps. 1 Direct the front LED of the Zero Connect Box towards the wireless receiver on the TV Screen. 2 If the front LED is not directed towards the TV Screen wireless receiver, turn the dial on top of the Zero Connect Box left or right until the sliding button faces the TV Screen wireless receiver.
  • Page 17 Installing Zero Connect Box diagonally from TV Screen Checking before turning on wireless TV If you have installed the Zero Connect Box diagonally from the TV Screen, follow these steps. 1 Direct the front LED of the Zero Connect Box towards the wireless receiver on the TV Screen. 2 If the front LED is not directed towards the TV Screen wireless receiver, turn the dial on top of the Zero Connect Box left or right until the sliding button faces the TV Screen wireless receiver.
  • Page 18 Installing Zero Connect Box to the side of TV Screen Checking before turning on wireless TV If you have installed the Zero Connect Box to the side of the TV Screen, follow these steps. 1 Direct the front LED of the Zero Connect Box towards the wireless receiver on the TV Screen. 2 If the front LED is not directed towards the TV Screen wireless receiver, turn the dial on top of the Zero Connect Box left or right until the sliding button faces the TV Screen wireless receiver.
  • Page 19 Installing Zero Connect Box to the bottom of TV Screen Checking before turning on wireless TV If you have installed the Zero Connect Box to the bottom of the TV Screen, follow these steps. 1 Position the Zero Connect Box so that the front LED is facing the viewer in front of the TV Screen. 2 Turn the dial on the top of the Zero Connect Box left or right to adjust the direction of the sliding button towards the viewer.
  • Page 20: External Devices

    Remote RS-232C setup To obtain the RS-232C external control setup information, please visit www. lg.com. Download and read the manual, (Depending upon model). • Do not drop the product or let it fall over when connecting external devices. Otherwise, this may result in injury or damage to the product.
  • Page 21: Specifications

    Specifications Power requirement AC 120 V~ 50/60 Hz Product specifications may be changed without prior notice due to upgrade of product functions. Estimated yearly energy consumption indicated on the FTC label is measured in accordance with the Test Procedures for Television Sets (USA only). The actual energy consumption depends on the usage environment (The content watched, TV settings, etc.).
  • Page 22: Product Information

    Product Information Wireless module(LGSBWAX12)Specifications Wireless module(LGSRFT1)Specifications Wireless LAN (IEEE 802.11a/b/g/n/ac/ax) Frequency range Output Power (Max.) Frequency range Output Power (Max.) 57.24 to 65.88 GHz 39 dBm 2,400 to 2,472 MHz 17 dBm As band channels can vary per country, the user cannot change or adjust the operating frequency.
  • Page 23: Open Source Software Notice Information

    LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com.
  • Page 24: Troubleshooting

    Troubleshooting In TV / HDMI input, press the button on the remote control three times to display the model name and serial number on the screen. Cannot control the TV with • Check if anything such as tape has been placed over the receiver. the remote control.
  • Page 25 • The motion sensor is located on the bottom center of the product. The product does not turn on continuously due • The motion sensor is only supported by some models. to Always Ready mode • If there is a foreign substance on the motion sensor, it may not work properly. operation or does not •...
  • Page 26 Precautions for Protecting the OLED TV Screen Recommendations for Minimizing Unlike regular LED/LCDs, OLED TVs produce images that emit light for each pixel, achieving a perfect black color and delivering clear images without Image Retention blurring. When watching the TV for a long time, press the button on the remote Due to the nature of the organic materials used to achieve high-resolution ] →...
  • Page 27 Regulatory...
  • Page 28 If the existing television set is going to be retained and relocated, the same considerations as above should be applied. Symbols Refers to alternating current (AC). Refers to stand-by. Refers to direct current (DC). Refers to “ON” (power). Refers to class II equipment. Refers to dangerous voltage. LG Take-back & Recycling Policy...
