Page 4
COMMUNICATION WIRING DIAGRAM IN IQ3/SALTO Node CONEXIONADO COMUNICACIONES EN IQ3 / SALTO Node ANSCHLUSSPLAN des IW3/Salto SCHÉMA DE CÂVLAGE DE LA COMUNICATION DANS LE NOEUD DE IQ3/Salto DIAGRAMA DOS FIOS DE COMUNICAÇAO ENTRE IQ37/NODE SALTO RS485 CONNECTION TO TERMINAL. CONEXIÓN RS485 A BORNA.
Page 7
2. Ethernet test: without any type of set up, the IQ3 is a DHCP ready device. If your network supports it, it is possible to check the Ethernet connectivity by pinging the address SALTO-IQ3-XXXXXX(XXXXXX corresponds to the final 6 digits of MAC).
