  • Page 1 Sandpit 255E363.65K.001...

  • Page 2: Installation Instructions

    Hauptabmessungen Dimensiones principales Dimensions principales - obstacle free zone Obstakelvrije zone Hindernissfreie raum Zona libre de obstáculos Zone libre d’obstacles - ground plan Bodemplan Bodenplan Plan de superficie Plan de surface 255 363 65K 001 © Copyright BOERplay 29-9-2022 Revision:...
  • Page 3 Hoofdafmetingen Hauptabmessungen Dimensiones principales Dimensions principales 3,60 m 0,43 m 0,40 m 0,00 m 255 363 65K 001 © Copyright BOERplay 29-9-2022 Revision:...
  • Page 4 Zona libre de obstáculos Zone libre d’obstacles 6,60 m Impact area Opvangzone Ausprallbereich Zona de impacto Zone d‘impact Obstacle free zone Obstakelvrije zone Hindernissfreie raum Zona libre de obstáculos Zone libre d’obstacles 255 363 65K 001 © Copyright BOERplay 29-9-2022 Revision:...
  • Page 5 Bodemplan Bodenplan Plan de superficie Plan de surface 1,50 m 3,60 m 1,50 m Ground level Maaiveld Bodennahe Nivel del suelo Niveau au sol 0,10 m 255 363 65K 001 © Copyright BOERplay 29-9-2022 Revision:...

  • Page 6: Assembly Manual

    Montagereihenfolge Orden de esemblado Ordre de montage - assembly manual - module Montagehandleiding - module Montageanleitung - Modul Manual de ensamblado - módulo Manuel de montage - module MOD.255.105.K MOD.255.904 MOD.255.004.xxx 255 363 65K 001 © Copyright BOERplay 29-9-2022 Revision:...
  • Page 7 Benodigde gereedschappen Benötigtes Werkzeug Herramientas requeridas Outils nécessaires TX-25 No. 17 No. 17 © Copyright BOERplay Revision:...
  • Page 8 Montagevolgorde Montagereihenfolge Orden de esemblado Ordre de montage MOD.255.004.xxx MOD.255.105.K 255 363 65K 001 © Copyright BOERplay 29-9-2022 Revision:...
  • Page 9 Colóquelo por la parte inferior y hágalo encajar doblando el exceso de material hacia la parte inferior Placez sur le fond et adaptez-le en pliant le matériau excédentaire vers le dessous BOER PLAY xxx.xxx.xxx EN 1176 www.boerplay.com 255 363 65K 001 © Copyright BOERplay 29-9-2022 Revision:...
  • Page 10 LOGBOOK Type indication Basic Play Article number 255E363.65K.001 Product Name Sandpit Maximum fall height 0,5 m Construction year 2023 Certificate 069525 Inspection body TUV Nederland QA BV Ekkersrijt 4401 5692 DL Son Manufacturer name Boer Speeltoestellen Hyacintstraat 2 - 4255 HX Nieuwendijk...
  • Page 11 LOGBOOK Inspection and maintenance Date of Time of Name Name Parts to be inspection inspection executor of executor of Found defects replaced maintenance maintenance inspection maintenance Accidents Date Age of Measures taken Probable cause of injury Occurred injury accident victim after accident...

  • Page 12: Inspection And Maintenance Intervals

    Inspection and maintenance intervals months Nr. Inspection Maintenance between inspections Verify equipment's stability, junctions and Add missing parts, secure joints, apply missing parts. Inspect bolts, screws and nuts for missing fixing agent and replace absence, jams, corrosion and wear. corroded parts. Replace worn parts and/or remove non- Check suspension for wear.
  • Page 13 7. Remember that bad maintenance leads to unsafe conditions and notably faster impoverishment of the playground area. 8. Replacement parts can be ordered at the manufacturer with the OEM part numbers on the module drawing. Drawings can be found in the user guide. 9.
  • Page 15 - module Montagehandleiding - module Montageanleitung - Modul Manual de ensamblado - módulo Manuel de montage - module MOD 255 105 K © Copyright BOERplay 12-9-2022 Revision:...
  • Page 16 ORE.MNP.066.100 ORE.MNP.067.100 250 mm ORE.MNP.066.100 ORE.MNP.067.100 ORE.MNP.067.100 ORE.MNP.066.100 50 mm ORE.MNP.066.100 ORE.MNP.067.100 MOD 255 105 K © Copyright BOERplay 12-9-2022 Revision:...
  • Page 17 ORE.MNP.066.100 ORE.MNP.067.100 ORE.MNP.066.100 ORE.MNP.067.100 MOD 255 105 K © Copyright BOERplay 12-9-2022 Revision:...
  • Page 18 Type Progr. Volgnr. Bew. Rev. Benaming Opmerking Lengte 4,0 m Benaming MOD 255 904 Worteldoek Title Tekening Opmerking 4x4,64 Drawing Comment Datum Samenstelling module Assembly module 25-8-2022 Date...
  • Page 19 060 Black Zwart / Schwarz / Negro / Noir BSV.017.010.008 BSV.034.010.002 BSV.030.010.002 KST.DON.010.xxx xxx: 060 Black Zwart / Schwarz / Negro / Noir BSV.035.010.030 SME.MNP.115.372 BSV.017.010.008 BSV.030.010.002 BSV.034.010.002 BSV.035.010.030 KST.DON.010.xxx KST.DOP.010.xxx SME.MNP.115.372 MOD 255 004 xxx © Copyright BOERplay 5-10-2022 Revision:...
