- Page 1 200C Publish Date: 10/4/2023 Manual Version 1.00 www.AuroraScientific.com © Aurora Scientific, 2023 VER. 1.00 page 1...
- Page 2 Instruction Manual Model: 200C Copyright © 2023 Aurora Scientific. Aurora Scientific 25 Industry Street Aurora, ON, Canada L4G1X6 Tel: 1-905-727-5161 Toll Free (N. America): 1-877-878-4784 Fax: 1-905-713-6882 Email: techsupport@aurorascientific.com Web Site: www.AuroraScientific.com © Aurora Scientific, 2023 VER. 1.00 page 2...
- Page 3 Instruction Manual Model: 200C Revision History Date Version Document Changes Number 04-Oct-2023 Initial Draft © Aurora Scientific, 2023 VER. 1.00 page 3...
-
Page 4: Table Of Contents
5.3 ..Technical Support Contact Information and Return Shipping Addresses ........21 5.4 ..Warranty ............................22 5.5 ..Returning Products to Aurora Scientific for Repair ................. 23 Specifications ..........................25 Appendix A - Compounds Detectable with the miniPID Sensor ............. 26 ©... -
Page 5: Introduction
Molecules having ionization energy levels below the lamp energy (10.6 eV) are the ones that are ionized. Appendix A contains a list of the ionization potentials of many common substances. Figure 1 200C Controller © Aurora Scientific, 2023 VER. 1.00 page 5... - Page 6 Because of this, the accuracy of the miniPID is dependent on the presence of interference gases. Figure 3 200C miniPID Sensor Long Mount © Aurora Scientific, 2023 VER. 1.00 page 6...
-
Page 7: Quick Start Guide
200C Series Accessories Accessories include power cord, tubing, fittings, and some tools. Table 1 Items included with a 200C Series Force Transducer For further description of the components of the system, see Section 3.1. © Aurora Scientific, 2023 VER. 1.00 page 7... -
Page 8: First Time Operation Of The 200C Minipid
4 times the cut-off frequency of the low-pass filter (4,000Hz sampling frequency). Over sampling is crucial if aliasing of the data is to be avoided. © Aurora Scientific, 2023 VER. 1.00 page 8... - Page 9 (rapidly increasing and decreasing signal that may appear to be noise), this is normal as the instrument is measuring © Aurora Scientific, 2023 VER. 1.00 page 9...
- Page 10 30 hours of use. If the sensor is used to detect very high gas concentrations or is used in dirty environments more frequent calibration may be required. See chapter 4 for the calibration procedure. © Aurora Scientific, 2023 VER. 1.00 page 10...
-
Page 11: General Operating Procedure
300- 1500 SCCM. The controller is half rack in size and can be mounted in a standard 19” rack by using an © Aurora Scientific, 2023 VER. 1.00... -
Page 12: Choice Of Tracer Gas
Instruction Manual Model: 200C Aurora Scientific Inc. half-rack adapter. AC power enters on the back panel of the controller. Also on the back panel is the sample pump outlet connection. Power Supply The power supply is built into the controller and is set for the line input voltage of the researcher’s country. -
Page 13: Troubleshooting
OFF, wait about 1 minute, and then switch the controller power back ON. 6. If repeated attempts to turn on the UV lamp fail then replace the lamp. If the new lamp does not light then contact Aurora Scientific Inc. for assistance. Pump does not run, pump 1. - Page 14 Re-tune the lamp by adjusting the lamp run voltage. Technical support is available by regular mail, email, phone, or fax. See Chapter 5.3 for technical support contact information. © Aurora Scientific, 2023 VER. 1.00 page 14...
-
Page 15: Calibration, Instrument Tuning And Maintenance
Thus it is critical to measure the inlet flowrate of the sensor before calibration and then set the flowrate of the calibration gas to ~1.1X the sensor flowrate. © Aurora Scientific, 2023 VER. 1.00 page 15... -
Page 16: Calibrated Gas Mixtures Technique
Also note that this method is a volumetric mixing operation and therefore the pressures and temperatures of the two gases must be the same in order to maintain accuracy. Use the calibration procedure outlined in section 4.1.1. © Aurora Scientific, 2023 VER. 1.00 page 16... -
Page 17: Mass Flow Meter Gas Mixing Technique
Electronic control modules are available to automate the mixing process. The calibration procedure remains the same as outlined in section 4.1.1. Aurora Scientific Inc. can supply any of the above calibration systems. Please contact us with your requirements. -
Page 18: Lamp Replacement
If there is no flow or the measured flow rate is significantly less than the as-shipped flow rate (listed on the miniPID Data Sheet) then perform the following checks. © Aurora Scientific, 2023 VER. 1.00 page 18... - Page 19 5. If step (4) shows that the sample line is okay then the problem is with the pump itself. In this case return the controller to Aurora Scientific Inc. for repair. Do not attempt to open the controller and replace the pump. HIGH VOLTAGE is present inside the controller.
-
Page 20: Detection Cell Cleaning
There are four socket head cap screws holding this cover in place. Removing these screws and the detector cover will void the warranty. © Aurora Scientific, 2023 VER. 1.00... -
Page 21: Performance Guarantee, Technical Support, Warranty And Repair Information
Our performance guarantee states: if for any reason a new product does not meet your research needs then you can return it to Aurora Scientific for exchange or a full refund. The performance guarantee only applies to new products and must be exercised within 60 days of receipt of the instrument. -
Page 22: Warranty
Products manufactured by Aurora Scientific Inc. are guaranteed to the original purchaser for a period of three (3) years. Under this warranty, the liability of Aurora Scientific is limited to servicing, adjusting and replacing any defective parts that are of Aurora Scientific manufacture. Aurora Scientific is not liable to the customer for consequential or other damages, labour losses or expenses in connection with or by reason of the use or inability to use the products manufactured by Aurora Scientific. -
Page 23: Returning Products To Aurora Scientific For Repair
Address and Phone Number (your company information), Consignee's Name, Address and Phone Number (Aurora Scientific Inc. is the Consignee), Country of Origin of Goods (this will be Canada if you purchased the instrument from Aurora Scientific or USA if your product was purchased from Cambridge Technology), Conditions of Sale (include the following statement: GOODS RETURNING TO FACTORY FOR REPAIR, TEMPORARY IMPORT), Number of Packages (normally 1), Description of Goods (e.g. - Page 24 Instruction Manual Model: 200C Asia, Australia and New Zealand Clients: ship your instrument to Aurora Scientific Asia in Hong Kong. Canadian, USA and all other Clients: ship your instrument to Aurora Scientific in Ontario, Canada. You may ship your instrument back to us via the courier of your choice or via parcel post. If possible, we prefer that you ship via FedEx.
-
Page 25: Specifications
Head warmed up and stabilized (30 minutes) at room temperature. 1 to 99%; Flow Adjust valve fully closed, and flow switch set to high. -3dB point Flow Adjust valve Closed - Open Standard Cubic Centimeters per Minute © Aurora Scientific, 2023 VER. 1.00 page 25... -
Page 26: Appendix A - Compounds Detectable With The Minipid Sensor
10.06 1-Chloro-2,3-Epoxypropane 10.60 3-Bromopropene 9.70 Chloroethene 10.00 2-Bromothiophene 8.63 2-Chloroethoxyethene 10.61 o-Bromotoluene 8.79 1-Chloro-2-Fluorobenzene 9.16 m-Bromotoluene 8.81 1-Chloro-3-Fluorobenzene 9.21 p-Bromotoluene 8.67 cis-1-Chloro-2-Fluoroethene 9.87 1,3-Butadiene 9.07 trans-1-Chloro-2-Fluoroethene 9.87 2,3-Butadione 9.23 Chloroform * 11.37 © Aurora Scientific, 2023 VER. 1.00 page 26... - Page 27 1,2-Dichloropropane * 10.87 Ethyl Bromide 10.29 1,3-Dichloropropane * 10.85 Ethyl Butyl Ketone 9.02 1,1-Dichloropropanone 9.71 Ethyl Chloroacetate 10.20 2,3-Dichloropropene 9.82 Ethyl Disulfide 8.27 Dicyclopentadiene 7.74 Ethyl Ethanoate 10.10 Diethoxymethane 9.70 Ethyl Ether 9.41 © Aurora Scientific, 2023 VER. 1.00 page 27...
- Page 28 Methyl Isopropyl Ketone 9.32 Isobutanol 10.47 Methyl Mercaptan 9.44 Isobutyl Acetate 9.97 Methyl Methacrylate 9.74 Isobutyl Alcohol 10.47 2-Methylpentane 10.12 Isobutylamine 8.70 3-Methylpentane 10.08 Isobutylbenzene 8.68 2-Methylpropanal 9.74 Isobutylene 9.43 2-Methylpropane 10.56 © Aurora Scientific, 2023 VER. 1.00 page 28...
- Page 29 8.78 Trifluoroethene 10.14 n-Propylbenzene 8.72 1,1,1-Trifluoro-2-Iodoethane 10.10 Propylene 9.73 Trifluoroiodomethane 10.40 Propylene Imine 8.76 Trifluoromethylbenzene 9.68 Propylene Oxide 10.22 n-Propyl Ether 9.27 Trifluoromethylcyclohexane 10.46 n-Propyl Formate 10.54 1,1,1-Trifluoropropene 10.90 Propyne 10.36 © Aurora Scientific, 2023 VER. 1.00 page 29...
- Page 30 Ionization potentials for several other compounds can be found in Ionization Potential and Appearance Potential Measurements, 1971-1981, R. D. Levin and S. G. Lias, National Bureau of Standards, Washington, D.C., October 1982. © Aurora Scientific, 2023 VER. 1.00 page 30...
