- Page 1 High Speed Length Controllers 315D | 322D Publish Date: 7/24/2020 Manual Version 1 www.AuroraScientific.com © Aurora Scientific, 2020 VER. 1.00 page 1...
- Page 2 High Speed Length Controllers Instruction Manual Model: 315D | 322D Copyright © 2020 Aurora Scientific. Aurora Scientific 25 Industry Street Aurora, ON, Canada L4G1X6 Tel: 1-905-727-5161 Toll Free (N. America): 1-877-878-4784 Fax: 1-905-713-6882 Email: techsupport@aurorascientific.com Web Site: www.AuroraScientific.com © Aurora Scientific, 2020 VER.
- Page 3 High Speed Length Controllers Instruction Manual Model: 315D | 322D Revision History Date Version Document Changes Number 07/24/2020 Initial Draft © Aurora Scientific, 2020 VER. 1.00 page 3...
-
Page 4: Table Of Contents
5.2 ..Technical Support ........................... 18 5.3 ..Technical Support Contact Information and Return Shipping Addresses ........... 18 5.4 ..Warranty ..............................19 5.5 ..Returning Products to Aurora Scientific for Repair ................20 Specifications ............................21 © Aurora Scientific, 2020 VER. -
Page 5: Introduction
315D and 100 mN for the 322D. The 315D is the fastest version of our length controllers. The 315D has a step response time of 250 microseconds and the 322D has a response time of 350 microseconds. To achieve the fastest possible step response times the control electronics uses a proportional/integral/derivative (PID) servo control loop. -
Page 6: Quick Start Guide
4. Attach the lever arm to the motor shaft (for the 315D the arm is attached at the factory). Gently, push and the lever arm back forth. It should move freely until the mechanical stops are reached. -
Page 7: General Operating Procedure
3.2 Controlling Force High-speed length controllers cannot control force by themselves. Aurora Scientific has a digital controller available that interfaces with a high-speed length controller and a force transducer and allows the user to control force. Our model 600A Digital Controller can generate critically damped force clamps in as little as 1.5 msec. -
Page 8: Inhibit Shutdown
High Speed Length Controllers Instruction Manual Model: 315D | 322D 3.4 Inhibit Shutdown All models include an inhibit circuit that interrupts the current drive to the motor and lights the FAULT LED. When the instrument is inhibited all external control inputs (Length In and Length Offset) are disconnected internally and power is cut to the motor. -
Page 9: Calibration, Instrument Tuning And Maintenance
Length Scale Factor = actual movement measured / LENGTH OUT voltage Example: For a model 315D system the actual movement is measured as 1.5 mm and LENGTH OUT is measured as 9.92 volts. Therefore, the Length Scale Factor will be 1.50 mm/9.92 volts = 0.151 mm/volt. -
Page 10: Instrument Tuning
The researcher wants the system step response slightly faster or slower. Please read the entire procedure before attempting any changes. It is possible to damage the motor if the procedure is not understood completely. If there are any questions, please contact Aurora Scientific Inc. -
Page 11: Tuning
Place the arm on the motor such that it swings about the same distance to either side of the motor centerline. Tighten the arm's clamp. For model 315D the arm is factory installed. *** CAUTION: Lethal voltages are exposed during this procedure. *** Use caution whenever the top cover of the electronics box is removed. - Page 12 High Speed Length Controllers Instruction Manual Model: 315D | 322D Figure 1 Under Damped Response 11. The four potentiometers R28, R25, R59, and R31 should now be alternately turned in a generally CW direction until a critically damped square wave with a step response time as shown in the table below is achieved.
- Page 13 High Speed Length Controllers Instruction Manual Model: 315D | 322D System Step Response Time (ms) 315D 0.25 322D 0.35 Figure 2 R28 Adjusted to Remove Overshoot © Aurora Scientific, 2020 VER. 1.00 page 13...
- Page 14 High Speed Length Controllers Instruction Manual Model: 315D | 322D Figure 3 R25 Adjusted to Remove Low Frequency Oscillations Figure 4 R59 Adjusted to Remove High Frequency Oscillations © Aurora Scientific, 2020 VER. 1.00 page 14...
- Page 15 High Speed Length Controllers Instruction Manual Model: 315D | 322D Figure 5 R28 Adjusted to Remove Overshoot Figure 6 R28 Adjusted to Increase System Speed © Aurora Scientific, 2020 VER. 1.00 page 15...
- Page 16 High Speed Length Controllers Instruction Manual Model: 315D | 322D Figure 7 Tuning Finished - Critically Damped Response 12. When the servo is properly tuned, the following points should be checked: a. The output response should look critically damped with no overshoot or undershoot.
- Page 17 High Speed Length Controllers Instruction Manual Model: 315D | 322D 14. Measure the voltage at U9, pin 14. It should be between +5.0VDC and +11.5VDC. If the voltage is outside of this range, there is probably a motor problem. Contact Aurora Scientific Inc.
-
Page 18: Performance Guarantee, Technical Support, Warranty And Repair Information
Our performance guarantee states: if for any reason a new product does not meet your research needs then you can return it to Aurora Scientific for exchange or a full refund. The performance guarantee only applies to new products and must be exercised within 60 days of receipt of the instrument. -
Page 19: Warranty
Products manufactured by Aurora Scientific Inc. are guaranteed to the original purchaser for a period of three (3) years. Under this warranty, the liability of Aurora Scientific is limited to servicing, adjusting, and replacing any defective parts that are of Aurora Scientific manufacture. Aurora Scientific is not liable to the customer for consequential or other damages, labour losses, or expenses in connection with or by reason of the use or inability to use the products manufactured by Aurora Scientific. -
Page 20: Returning Products To Aurora Scientific For Repair
SHALL BE VALID UNLESS MADE IN WRITING AND SIGNED BY AN EXECUTIVE OFFICER OF AURORA SCIENTIFIC INC. 5.5 Returning Products to Aurora Scientific for Repair There are a few simple steps that must be completed before returning your product to Aurora Scientific. 1. Obtain a Return Material Authorization number (RMA#). Go to our website or contact our technical support department to obtain an RMA #. -
Page 21: Specifications
High Speed Length Controllers Instruction Manual Model: 315D | 322D 6 Specifications Model # 315D 322D Lever Arm Length [mm] Length Excursion [mm] Length Signal Resolution [micron] Length Scale Factor 0.15 0.30 [mm/Volt ±2%] Length Signal Linearity 99.5 99.9 Length Step Response Time 0.350...
