HumanCentric 101-1061 Quick Installation Manual

Vesa adapter for lg monitors 24mp58vq, 24mp58vq-p, 24mp59ht, 24mp59ht-p, 24mp60vq, 27mp58vq, 27mp58vq-p
Hide thumbs
1
2
3

Advertisement

Table of Contents

VESA Adapter for LG Monitors
24MP58VQ, 24MP58VQ-P, 24MP59HT, 24MP59HT-P, 24MP60VQ,
27MP58VQ, 27MP58VQ-P
Model 101-1061
Full product specifications: www.humancentric.com/101-1061
Need help? Contact support: support@humancentric.com
To reduce the risk of injury to persons, read all important precautions and warnings listed below.
HumanCentric assumes no responsibility for personal injury or property damage sustained by or
through the use of this product:
Do not hang anything other than the specified monitor on this mount. Exceeding the weight capacity
could result in injury or property damage.
Read all instructions carefully.
Incorrect installation may lead to damages or serious injury. Ensure that the product and monitor are
secure before use.

ADDITIONAL TOOLS REQUIRED

Phillips Head Screwdriver

PARTS INCLUDED

(A) VESA Adapter Bracket (x1)
© 2023 HumanCentric Ventures LLC
WARNING
(B) M4 x 12mm Screw (x6)
(C) M4 x 30mm Screw (x2)
www.humancentric.com/patents
(D) M4 Washer (x4)
(E) M4 Stando (x2)
www.humancentric.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 101-1061 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HumanCentric 101-1061

Summary of Contents for HumanCentric 101-1061

  • Page 1 WARNING To reduce the risk of injury to persons, read all important precautions and warnings listed below. HumanCentric assumes no responsibility for personal injury or property damage sustained by or through the use of this product: Do not hang anything other than the specified monitor on this mount. Exceeding the weight capacity could result in injury or property damage.
  • Page 2 Screw the bracket onto the back of the monitor using two M4 x 30 mm screws(C), two M4 x 12 mm screws(B), and four M4 washers(D). Important: Attach the adapter to the monitor with the “BACK” marking facing you. © 2023 HumanCentric Ventures LLC www.humancentric.com...
  • Page 3 (4) M4 x 12mm screws(B). Note: It is best to use the screws that came with your monitor arm. If you don't have these available, we have provided VESA standard screws for your convenience. © 2023 HumanCentric Ventures LLC www.humancentric.com...
