VESA Adapter Plate for 200 mm x 100 mm
Model 101-2041
Full product specifications: www.humancentric.com/101-2041
Need help? Contact support: support@humancentric.com
To reduce the risk of injury to persons, read all instructions carefully. HumanCentric assumes no responsibility
for personal injury or property damage sustained by or through the use of this product.
1.
Read all instructions carefully.
2.
Incorrect installation may lead to damages or serious injury. Ensure the product and monitor are secure
before use.
Make sure the monitor mount that this product will be mounted to can support the combined weight of the
3.
monitor and adapter.
COMPATIBILITY INFORMATION
Works with mounts that have VESA patterns of 50 x 50, 75 x 75 or 100 x 100 mm
© 2023 HumanCentric Ventures LLC
WARNING
200mm
100mm
75mm
50mm
www.humancentric.com/patents
www.humancentric.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for HumanCentric 101-2041
Summary of Contents for HumanCentric 101-2041
- Page 1 Need help? Contact support: support@humancentric.com WARNING To reduce the risk of injury to persons, read all instructions carefully. HumanCentric assumes no responsibility for personal injury or property damage sustained by or through the use of this product. Read all instructions carefully.
- Page 2 flat, even surface: Ensure that you choose an appropriate length screw and spacer combination that is not too long or too short: Will not hold Will damage monitor monitor © 2023 HumanCentric Ventures LLC www.humancentric.com...
- Page 3 Using the screw / spacer combination you selected in the previous step, attach the mounting plate to the back of the monitor. To complete the installation, follow the instructions that came with your monitor mount. © 2023 HumanCentric Ventures LLC www.humancentric.com...
- Page 4 Check that the mount is secure and safe to use at regular intervals (at least every three months). HumanCentric intends to make this manual accurate and complete. However, HumanCentric makes no claim that the information contained herein covers all details, conditions, or variations. Nor does it provide for every possible contingency in connection with the installation or use of this product.
