- Page 1 Industrial Series ATS-255 AiR METAL SHEARS INSTRUCTION MANUAL Order Code: A085 www.machineryhouse.com.au www.machineryhouse.co.nz www.machineryhouse.com.au www.machineryhouse.co.nz...
- Page 2 4. Do not use this tool for other than its intended cause a hazardous situation. use. If used for other purposes, Toolmaster disclaims any real or implied warranty and 16. Check air hoses for wear, and keep them away holds itself harmless from any injury that may from heat and sharp edges.
-
Page 3: Technical Specifications
Safety Specific For Air Metal Shear 1. ATS-255 shear is designed for cutting sheet 4. Do not lubricate the tool with combustible material, such as steel, aluminium and plastics. liquids, such as kerosene, diesel or jet fuel. If you are not familiar with the proper and safe 5. -
Page 4: Air Supply
Setup Any missing parts or damage should be reported immediately to your Toolmaster distributor. Do not use a damaged tool. Read this instruction manual thoroughly for operation, maintenance and safety Instructions. The diagram below is the ideal setup position. The lubricator is optional and if not used, then a few drops of Pneumatic Tool Oil need to be added to the airline connection before operation. -
Page 5: Changing The Blades
Operating Instructions 1. Remove protective cap from air inlet (Fig. 1). If an in-line oiler is not being used, add 4 or 5 drops of air tool oil (not included) into the air inlet. 2. Blow out air line to remove any dirt or moisture, then connect air supply hose to tool. Set air pressure to 90 psi. -
Page 6: Optional Accessories
2. Quarterly (every 3 months) – Tool Disassembly, Cleaning, and Inspection: Have the internal mechanism cleaned, inspected, and lubricated by a qualified technician. For a full service contact your local Toolmaster service agent. When not in use, disconnect from air supply, clean nibbler and store in a safe and dry place. -
Page 7: Troubleshooting
Troubleshooting Review the troubleshooting and procedures in this section if a problem develops with your Air Tool. If you are still unable to resolve the problem, then contact your local Toolmaster distributer. Symptoms Possible Cause Possible Solution 1. Not enough air pressure and/or air flow. 1. Check for loose connections and make sure that air supply is providing enough air flow (CFM) at required pressure (PSI) to the tool’s air...
