Summary of Contents for Wibrain B1E

  • Page 2: Table Of Contents

    Chapter 1 >> Getting Started Before You Get Started Safety Precautions Proper Posture During Product Use Important Safety Information Replacement Parts and Accessories Regulatory Compliance Statements Approval of Windows XP Overview...
  • Page 3: Before You Get Started

    Use the Glossary to look up any technical terms. ○ If a problem occurs, refer to the FAQ included in the User Guide or refer to the website (www.wibrain.com). NOTE ■ Some devices and software referred to in the User Guide may not be provided and/or changed.
  • Page 4 The information in this document is subject to change without notice due to improving the performance of the product. Wibrain shall not be liable for any data loss. Please take care to avoid losing any important data and backup your data to prevent any such data loss.
  • Page 5: Safety Precautions

    ● Safety Precautions For your security and to prevent damage, please read the following safety instructions carefully. Warning Failing to follow instructions marked with this symbol may cause personal injury and even fatality. Installation Related - Do not use the product in places exposed to humidity such as a bathroom. There is a danger of electric shock.
  • Page 6 Usage Related - Disconnect all cables connected to the product before cleaning it. There is a danger of electric shock or damage to the product. - Do not connect a phone line connected to a digital phone to the modem. There is a danger of a electric shock, fire or damage to the product.
  • Page 7 - Do not throw, disassemble or put the battery into water. This may cause injury, fire or explosion. - Use only a battery authorized by Wibrain, Inc. Failing to do so may cause explosion. - Avoid contact with metal objects such as car keys or clips when keeping or carrying battery.
  • Page 8 - Take care not to throw or drop parts of the product. This may cause injury or damage to the product. - Use parts authorized by Wibrain only. Failing to do so may cause fire or damage to the product.
  • Page 9 Cautions on Preventing Data Loss (Hard Disk Management) To prevent data loss due to damaged hard disk drive please backup your data frequently. - Take care not to damage the data on hard disk drive. ■ A hard disk drive is sensitive to external impact. Impact may cause loss of data on the surface of the disk. ■...
  • Page 10: Proper Posture During Product Use

    ● Proper Posture During Product Use Maintaining proper posture during product use is very important to prevent physical harm. The following instructions are about maintaining proper posture during product use. Please read and follow them carefully when using the product. Otherwise, the probability of (RSI: Repetitive Strain Injury) from repeated operations may increase and serious physical harm may occur.
  • Page 11 Illumination ■ Do not use product in dark locations. The illumination level for product use should be as bright as for reading a book. ■ Indirect illumination is recommended. Use a curtain to prevent reflection on the LCD screen. Operation Condition ■...
  • Page 12: Important Safety Information

    ● Important Safety Information. ● Important Safety Information ● Safety instructions ● Safety instructions Your system is designed and tested to meet the latest standards for safety of information technology equipment. Your system is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that the safety instructions marked on the product However, to ensure safe use of this product, it is important that the safety instructions marked on the product and in the documentation are followed.
  • Page 13: Replacement Parts And Accessories

    Do not put rechargeable batteries or products powered by non-removable rechargeable batteries in the garbage. Contact Wibrain for information on how to dispose of batteries that you cannot use or recharge any longer. Follow all local regulations when disposing of old batteries.
  • Page 14: Regulatory Compliance Statements

    ● Regulatory Compliance Statements ● ● Wireless Guidance Wireless Guidance Low power, Radio LAN type devices (radio frequency (RF) wireless communication devices), operating in the Low power, Radio LAN type devices (radio frequency (RF) wireless communication devices), operating in the 2.4GHz Band, may be present (embedded) in your system.
  • Page 15: Approval Of Windows Xp

    After completing installation you will see a prompt that reads: “Let’s activate Windows”. Check “Yes, let’s activate Windows over the Internet now”. b. Follow the instruction or visit the Wibrain web-site (www.wibrain.com) and refer to the online FAQ. NOTE If the Windows XP label gets damaged you may have difficulty getting approval.
  • Page 16: Overview

    ● Overview ● In the Giftbox Before You Get Started ■ The items marked with this symbol are optional items which may be changed or may not be provided depending on the model. ■ The actual color and appearance of the product may differ from the pictures used in this guide. ■...
  • Page 17 ● Front View A / B Keyboard : The keyboards allow users to enter numbers and characters directly LCD : Display screen. Buttons : You can configure these buttons to launch frequently used programs. Touch Pad (Synaptic) ● Back View WEBCAM : Retractable camera.
  • Page 18 Hand Strap Hole : You can anchor the hand strap here. Battery : A lithium-Ion rechargeable battery supplies power for the product. Stylus Pen Slot : You can keep the stylus pen here. Vents : Releases heat generated by internal components. Avoid blocking the vents as this may overheat the product.
  • Page 19 Power Supply Jack : Insert power adaptor here to supply power and charge device. WiFi Switch : Slide switch upward to enable wireless LAN access. USB Port : To connect external devices here. ● LED Status Explanation LED On ▼ Top Hold / Blue Hold On Hold Off...
  • Page 20 Chapter 2 >> Using the Product Turning the Product On and Off Entering Text Using B1 Utility Programs...
  • Page 21 ● Turning the Product On and Off ● Turning On 1. Attach the battery or connect the AC adapter. 2. Press the power button. ● Turning Off 1. Click the “Start” button on the taskbar. 2. Click the “Turn Off” button in the middle of the window. The product will be shut down. NOTE If the product does not shutdown properly due to a system error, push and hold the power switch for more than 5 seconds to turn it off.
  • Page 22 ● Entering Text : You can input characters using the Keyboards. Before You Get Started ■ For long periods of use, use a bluetooth or USB keyboard for your convenience. ■ Also, connecting an external monitor would help reduce eye strain for long term use. ■...
  • Page 23 Using Hotkeys Input Input Page Up Page Down Arrow Key (↑) Arrow Key (→) Arrow Key (↓) Arrow Key (←) Mouse Left Key Mouse Right Key Volume Down Volume Up Input with Fn key Function Display Setting (LCD, VGA) Resolution Setting (1024x600/ 800x600 / 800x480) LCD Back Light Setting + Brighter...
  • Page 24 Using Touch Pad It functions just like computer mouse. Before You Get Started ■ Use your fingers only. Sharp objects may scratch or damage the touch pad surface. ■ using the touchpad while windows is booting may delay startup. Touch Pad : Moves the on screen cursor.
  • Page 25 Using Touch Screen Before You Get Started ■ Included stylus pen is recommended. Sharp objects may scratch or damage the LCD surface. 1. Setting the touch screen ○ “ Go to Start-> Program -> TDTOUCH -> Touchware”. ○ In the calibrate tab of the Techdine Touchware area, click the “Calibrate” button.
  • Page 26 ○ Press and hold the crosshair(+) displayed on the screen for 3~4 seconds with the stylus pen wherever it appears on the screen. ○ Once you have pressed all the crosshairs, the calibration finishing window pops up. Tap the OK button to apply the calibration result for pointing position correction. 2.
  • Page 27 ● Using the B1 Utility Program What the “MFSmgr”program is It’s executed automatically when the system is started. The setting will be saved and applied automatically. ● The features of “MFmgr” program Setting the speed of Fan Setting the Keyboard Backlight Mode Setting the VGA/CRT Out Setting the Resolution ●...
  • Page 28: Using The Network

    Chapter 3 >> Using the Network Wireless Network Using Bluetooth Using Wired Network BIOS Setup System Management Battery Product Specifications...
  • Page 29: Wireless Network

    ● Wireless Network A wireless network (Wireless LAN) environment is a networking environment that enables communication between multiple products at home or a small-size office through wireless LAN devices. Before You Get Started ■ The descriptions below are for models with a Wireless LAN card or device. To check the installed wireless LAN card, click Start ->...
  • Page 30 ② When the Network Connection window pops up, click View Wireless Networks. ③ Select an AP to connect to and click Connect. If a network key is necessary you will be prompted sto enter it now. Enter the network key and then click the Connect button. NOTE ■...
  • Page 31: Using Bluetooth

    ● Using Bluetooth Bluetooth is a wireless communications technology that allows access to nearby devices such as another computer, cell phone, printer, keyboard, mouse, etc. without a cable connection. Using Bluetooth you can exchange files, connect to the Internet and construct a private network. Before You Get Started ■...
  • Page 32 ● BlueSoleil (Standard) Edition Quick Guide Start up BlueSoleil ① Double click the BlueSoleil icon on the Windows Desktop. The mail page of BlueSoleil will appear as below. ② Click the red ball in the middle of the main page to start searching for Bluetooth devices nearby. ③...
  • Page 33 ⑥ Double click the device icon to browse its services. Note:In some cases, you need to make a connection between BlueSoleil and the remote device by inputting the same passkey on both ends. In BlueSoleil the following window will pop up, you can enter the passkey here. ⑦...
  • Page 34 ⑨ Cancelation : Right-click on the device icon and click cancel. Notice for Windows XP Expected outcome: Installed Files & Directories (by default): ● Go to “Start -> Program -> IVT BlueSoleil -> BlueSoleil” BlueSoleil execution and support files will be found here. ●...
  • Page 35: Using Wired Network

    ● Using Wired Network A wired network is a network environment used for a company or broadband internet connection at home. ① Connect a LAN cable to the LAN port on the Desktop Cradle (Optional Item). ② Go to Start -> Control Panel -> Network and Internet Connection -> Network Connection ③...
  • Page 36: Bios Setup

    How to enter the BIOS Setup Utility ① Press the “Del” key when the “Wibrain” logo appears. ② The Bios Setup screen appears as below. If not, restart the product and press the “Del” key several times when the “Wibrain” logo appears.
  • Page 37: System Management

    ● System Management System Recovery & Reinstallation ■ The system Recovery should be needed as below conditions. - Virus Infection - Unstable System - Formatting the hard disk by accident ■ If it’s difficult to boot the reasons of system errors or viruses, your system would be recovered as a mass production stage.
  • Page 38: Battery

    ● Battery Please refer to the following instructions when running the product on battery power without connecting the AC adapter. A Lithium-Ion battery is supplied with this product. Read carefully and follow the precautions printed on the battery before use. Precautions Use only chargers specified in the User Guide.
  • Page 39: Product Specifications

    ● Product Specifications The system specifications may differ depending on your model. For detailed system specifications refer to the product catalog. Operating System Main Memory* Network Hard Disk Drive* Dimensions Weight Battery* Operating Environment Speakers Operating Voltage Output Voltage ■ The ( * ) mark represents optional components. Optional components may not be provided or different components may be provided depending on product model.
  • Page 40 Chapter 4 >> FAQ and Troubleshooting FAQ and Troubleshooting Certificate...
  • Page 41 Then, install the battery pack again. If the issue persists the installed battery pack is not compatible. Remove the battery pack and contact an authorized Wibrain Repair center. The battery cannot be charged. The warranty on the battery is 6 months. If it is under the warranty period you may exchange it.
  • Page 42 How to install a different Windows version. B1 has been optimized for Windows XP. If you install a different Windows version, we cannot guarantee proper operation. The Windows label on my battery pack is torn. If you can see the product key properly there is no problem. The original label is designed for protection purposes.
  • Page 43 CTK Co., Ltd. EMC: CTK Co., Ltd. The CE Marking on the products and/or their packaging signifies that WIBRAIN, INC. holds the reference technical file available to the European Union authorities. Place and date of issue: 306 JEI Platz, 459-11 Gasan-dong, Geumcheon-gu, Seoul, Korea /...
