HermanMiller
Nelson
Bubble Lotus Table Lamp
™
Nelson
Bubble Lotus Floor Lamp
™
FOR INDOOR DRY LOCATION USE ONLY.
DO NOT COVER ANY PART OF THE LUMINAIRE.
LAMP IS HOT! WHEN TURNED OFF, ENSURE LAMP HAS COOLED
BEFORE CHANGING.
IF THE LUMINAIRE IS DAMAGED, IT SHOULD BE REPLACED, OR
REPAIRED BY THE MANUFACTURER OR THEIR SERVICE AGENT OR
SIMILAR QUALIFIED PERSON IN ORDER TO AVOID ANY HAZARD.
CAUTION
PLASTIC BAGS CAN BE DANGEROUS.
TO AVOID DANGER OF SUFFOCATION,
KEEP THIS BAG AWAY FROM BABIES AND CHILDREN
No Tools Required
Technical Specifications
Light source type: E27
Only use LED or Compact fluorescent energy saving lamps.
Lamp and colour to be specified separately.
Electrical
Class:
1 (This product must be earthed)
Input Voltage (VAC):
Small Luminaire: 100 - 240V, all others
110-240V
220-240V
Input Frequency (Hz):
50/60 Hz
Power Consumption (W): All Luminaire are individually marked
Environmental
Ingress Protection: IP20
Operating Temperature Range: +25°C
Storage Temperature Range: -10°C to +50°C
Humidity (non-condensing): 20-50% Non-condensing, dry locations only
Physical Specifications
All Luminaire vary in size and weight: *Typically
Small Shade = *.45kg; Medium Shade= *1.43 kg; Large Shade = *2.04 kg
Table Base = *1.5 kg; Floor Base = *4.26 kg
Herman Miller Nelson Bubble Lamp Series
Parts Included (Cigar shown, Others available)
A. Lamp Shade
(Cigar Shown, Others available)
Only installed on large and medium
floor lamps.
Technical
Plastic polymer sprayed over a steel frame. Each Luminaire is supplied
with Lotus base and power cord.
Cleaning Instructions
The surface can be dusted with a soft dry cloth. To remove dirt or grease,
use water with a mild soap and rub gently using a soft white cloth or
paper towel.
Do not use solvent-based cleaners or glass cleaners on this product.
Please ensure luminaire is turned off during cleaning.
Translations
For translated versions of this document please visit the following links:
UK. hermanmiller.co.uk/nelson-bubble-lamps
FR. hermanmiller.fr/nelson-bubble-lamps
DE. hermanmiller.de/nelson-bubble-lamps
IT. hermanmiller.it/nelson-bubble-lamps
NL. hermanmiller.nl/nelson-bubble-lamps
1
B. Shade Support and Base and Mounting
Screw
Floor Lamp Shown
Part # 1BTKPV Rev. A
Assembly Instructions
Advertisement
Table of Contents
Related Manuals for HermanMiller Nelson Bubble Lotus Table Lamp
Summary of Contents for HermanMiller Nelson Bubble Lotus Table Lamp
- Page 1 Translations Ingress Protection: IP20 Operating Temperature Range: +25°C For translated versions of this document please visit the following links: Storage Temperature Range: -10°C to +50°C UK. hermanmiller.co.uk/nelson-bubble-lamps Humidity (non-condensing): 20-50% Non-condensing, dry locations only FR. hermanmiller.fr/nelson-bubble-lamps Physical Specifications DE. hermanmiller.de/nelson-bubble-lamps All Luminaire vary in size and weight: *Typically IT.
- Page 2 BEFORE YOU BEGIN READ THESE INSTRUCTIONS COMPLETELY How to assemble your lamp AND CAREFULLY. Step 1: (Table lamb and Floor lamb steps are the same except where THIS PRODUCT CAN BE MOUNTED WITHIN ARM’S REACH. noted) Save These Instructions Use only in the manner intended by the manufacturer. If you have any After installing a light bulb, lower the lamp shade over the support frame.
- Page 3 For more information about the care and assembly of this product, please visit hermanmiller.com/care-and-assembly. HermanMiller and Y are among the registered trademarks of Herman Miller, Inc. Nelson is among the trademarks of Herman Miller, Inc. Printed in USA. Please recycle.
