User Manual PN 84468 Rev B
COPYRIGHT © 2018
F
THALES DEFENSE & SECURITY, INC.
ALL RIGHTS RESERVED
Thales MissionLINK
User Guide
SEPTEMBER 2018
™
i
Advertisement
Related Manuals for Thales MissionLINK
Summary of Contents for Thales MissionLINK
- Page 1 This document contains technology controlled for export by the U.S. Department of Commerce in accordance with Export Administration Regulations. Diversion contrary to U.S. law prohibited. User Manual PN 84468 Rev B COPYRIGHT © 2018 THALES DEFENSE & SECURITY, INC. ALL RIGHTS RESERVED...
- Page 2 RECORD OF CHANGES Date Description of Change Author Rev A June 2018 Initial Release SJacques Rev B Sept 2018 ECN: 42153 SJacques x Update based on Beta user feedback and Testing WARNING – INFORMATION SUBJECT TO EXPORT CONTROL RESTRICTIONS WARNING – INFORMATION SUBJECT TO EXPORT CONTROL RESTRICTIONS WARNING –...
- Page 3 E x p o rt Comp l ianc e : T h i s p r odu c t is c o ntrolled b y t h e ex p o rt la w s and re g u lations of t h e United S t ates of A m eri c a . T h e U . S . G o vernment may restri c t t h e ex p o rt or re -ex p o rt of t h i s p r odu c t to c e rtain individuals and / o r destinations .
- Page 4 YSTEM ESCRIPTION Terminal Unit (TU) ......................2-4 Broadband Active Antenna (BAA) ..................2-7 GETTING STARTED ................... 3-1 ........................3-1 ETTING TARTED THALES MANAGEMENT PORTAL ............4-1 ............4-1 ETTING TO NOW THE HALES ANAGEMENT ORTAL Menu Components ....................... 4-3 Main Dashboard ........................4-7 Status ............................
- Page 5 ACRONYMS / GLOSSARY ................. 8-1 ......................8-1 CRONYMS LOSSARY SPARE PARTS ....................9-1 SPARE PARTS ........................9-1 INDEX ..........................I NDEX List of Figures 1-1 E ......1-2 IGURE ARTH SHOWING RIDIUM SATELLITES IN SIX DEFINED ORBITAL PLANES 1-2 T .
- Page 6 4-23 S Æ D ....................... 4-19 IGURE ETTINGS ISTRESS 4-24 S Æ S ..................4-20 IGURE ETTINGS ATELLITE CREEN 4-25 S Æ W ....................4-22 IGURE ETTINGS CREEN 4-26 S Æ LAN S ....................4-24 IGURE ETTINGS CREEN 4-27 S Æ...
- Page 7 L i st of T a b l es 2-1 T LED S ....................2-5 ABLE ERMINAL TATUS 3-1 T IP P .................. 3-2 ABLE YPICAL HONE ONFIGURATION 3-2 T LED S ....................3-5 ABLE ERMINAL TATUS 4-1 Q ........................4-4 ABLE UICK CONS...
- Page 8 Improper installation could lead to system failure or could result in injury. The following are general safety precautions and warnings that all personnel must read and ™ understand prior to installation, operation and maintenance of the Thales MissionLINK system. Each chapter may have other specific warnings and cautions.
- Page 9 ANTENNA RADIATION HAZARDS To comply with FCC Radio Frequency radiation exposure limits, the antenna must be installed at a minimum safe distance as shown below. WARNING During operation, the antenna radiates high power at microwave frequencies that can be harmful to individuals. While the unit is operating, personnel should maintain a minimum safe distance of 1.0 meter (3.3 ft.) from the antenna.
- Page 10 FCC Information FCC Identifier: OKCMF350BV Contains FCC ID: QOQWF121 NOTE Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
- Page 11 Industry Canada Information Industry Canada: 473C-MF350BV Contains IC: 5123A-BGTWF121 NOTE Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
- Page 12 User Manual PN 84468 Rev B...
- Page 13 ™ MissionLINK system. It, however, cannot cover all topics and advanced features. For questions or topics that are not covered in this manual please contact your service provider or Thales at www.Thalesdsi.com. THE IRIDIUM SATELLITE NETWORK The Iridium satellite network is comprised of 66 Low-Earth Orbiting (LEO), cross-linked satellites, providing voice and data coverage over Earth’s entire surface.
- Page 14 MissionLINK system. ™ A MissionLINK voice or data call is sent to the closest satellite overhead that has a high signal strength. The traffic is then routed through the satellite network to a Ground Station or Gateway. At the gateway, traffic is converted back to internet protocol (IP) and voice, depending on call type and delivered to the IP cloud or the public switched telephone network (PSTN).
- Page 15 SYSTEM OVERVIEW SYSTEM DESCRIPTION ™ ™ The MissionLINK system operates using Iridium Certus broadband services over a network of 66 satellites that cover 100% of the globe, including remote locations and the poles. The solution utilizes this robust network service to provide highly reliable, mobile and essential voice, text and web communications.
- Page 16 Least Cost Routing automatically routes the data to an optional, lower cost network (i.e., cellular, Wi-Fi, etc.). x Custom Thales softphone application available from the Apple Store and Google Play for use on iOS and Android devices. x Low profile, IP66 rated antenna with single RF cable to the Terminal Unit (TU).
