ACCUDUAL
Quick Installation Guide
Package content
®
1. InneRAID
®
2. InneRAID
3. InneRAID User Kit CD
4. Internal RS232 (3 to 9) cable with bracket
5. Serial/RS232 (9 to 9) cable
6. Two keys for drive trays
7. Mounting screw pack (18 in 1)
Familiar with RAID box
Over view
ACD-75211 is a reliable and affordable solution for SATA RAID 1 disk mirroring.
The RAID box mirrors data to two hard drives in RAID box simultaneously, and
delivers optimized performance. And featuring intelligent online recovery, the
RAID box lets you hot swap a failed hard drive and automatically rebuild the
data to the new hard drive without any system down time. The RAID box also
provides the high flexibility in SATA system interface .
ACD-75211 RAID box
Slim SATA RAID box with 2 drive trays
Slim Quick Install Guide
ver1.0
ACD-75211 RAID BOX
1
Advertisement
Related Manuals for Accusys ACD-75211
Summary of Contents for Accusys ACD-75211
- Page 1 Familiar with RAID box Over view ACD-75211 is a reliable and affordable solution for SATA RAID 1 disk mirroring. The RAID box mirrors data to two hard drives in RAID box simultaneously, and delivers optimized performance. And featuring intelligent online recovery, the RAID box lets you hot swap a failed hard drive and automatically rebuild the data to the new hard drive without any system down time.
- Page 2 When a RAID1 member disk fails, array management simply directs all application requests to the remaining disk. RAID1 is suitable for data which reliability requirements are extremely high, or for data to which high performance access is required. ACD-75211 RAID BOX...
- Page 3 ACCUDUAL Front View of ACD-75211 RAID BOX The LED indicators that are built in right-side of drive tray for indicating hard drive status. Please refer to below table for all status in details. When hearing the beeper sounds “bi-bi-bi”, please check the indicator status and react to the event immediately.
- Page 4 ACCUDUAL Rear view of ACD-75211 RAID BOX 1. SATA DC power input connector 2. SATA host connector 3. RS232 connector (J10) 4. Reserved for future functions (J9 default is closed) 5. Standard AT/ATX DC power input connector Note ® InneRAID...
- Page 5 ACCUDUAL Install ACD-75211 into system Follow the following instructions to establish the connection. 1. After fully configured RAID box. 2. Power down your host computer. 3. Mount the RAID box into the system. 4. Connecting the SATA cable from system computer to RAID box.
- Page 6 Note If you have installed non-identical hard drives, your computer will recognize RAID box as a single hard disk with a capacity equal to the smaller hard disk drive installed in the RAID box. ACD-75211 RAID BOX...
