Kicker FHDESU14 Manual

Motorcycle Audio Kit for Harley Davidson
Electra Glide | Street Glide | Ultra Glide | Bat Wing Trikes
2014–Newer (FLHT)
Package Contents:
(1) Install Guide
(2) 6-1/2" KICKER Speakers
(1) 120W/60W KICKER Amp
Important: Over-tightening mounting fasteners may result in damage to your motorcycle. Please refer to your service manual for proper
procedures and torque specifi cations. KICKER is not responsible for damage resulting from improper installation techniques. This kit may not
be compatible with some aftermarket head units.
PROGRAMMING HD RADIO
NOTE: It is necessary to purchase a KICKER TDHDP Radio Flash Programmer or to have a motorcycle shop re-fl ash your radio before installation!
FRONT KIT PROGRAMMING WITH KICKER TDHDP
Follow instructions included with KICKER TDHDP
GETTING STARTED
1. Remove the seat and disconnect both negative and positive battery terminals.
2. Remove the windshield.
3. Remove the outer fairing.
a. Remove the four mounting screws, unplug the headlamp and set aside on a soft cloth.
4. Remove the fuel tank.
a. Unplug the fuel fi tting on the left side of the tank. You may remove the console if you want to retain vent line routing and connector
placement.
b. Remove all four mounting bolts and carefully lift the tank off the bike and set aside.
5. Remove wire caddy cover.
a. Carefully release each tab along the caddy until it lifts completely.
SPEAKER INSTALLATION
6. Remove one of the white speaker pods from the inner fairing. (Fig. 1)
a. There are fi ve fasteners in the center portion and three on the outside to release it from the inner fairing.
7. Remove the stock speaker and replace with the PSC652 speaker from the kit.
a. Install the provided speaker ring adapter onto the speaker pod. (Fig. 2)
b. Install the speaker into the pod and fasten with the original speaker screws. (Fig. 3)
8. Reinstall the pod to the inner fairing.
9. Repeat for the other side.
AMP INSTALLATION
Note: There may be some connectors that will need to be relocated off of the radio chassis for the amp bracket to fi t.
10. Fasten the amplifi er to the bracket with the supplied hardware.
a. Insert the bolts through the bottom of the bracket and install the locknuts to the amplifi er.
11. Using the supplied ¼" hardware, fasten the amp/bracket assembly to the radio chassis with the 12-pin connector facing the clutch side.
HARNESS INSTALLATION
12. Plug the harness into the amplifi er and route the speaker wires to their respective locations. (Fig. 6)
a. Separate the speaker connectors and plug in the amplifi er harness to each speaker.
13. Plug the switched power harness into the 2-place amp connector on the right side of the fairing. (Fig. 7)
14. Plug the blue wire on the kicker harness into the switched power harness lead with one wire.
a. This allows for an accessory 12V port to remain available.
15. Route the power leads along the left side of the frame neck, in the lectrical caddy to the seat area. (Fig. 8)
16. Reconnect the battery terminals.
FHDESU14
(2) Wiring Harnesses
(4) 8-32 x 1/2" Button Head Bolts
(4) 8-32 Nylock Nuts
®
(4) Black Cable Ties
(1) Stainless Steel Mounting Bracket
(1) Mounting Hardware
FRONT & REAR KIT PROGRAMMING WITH KICKER TDHDP
Follow instructions included with KICKER TDHDP
