Specifications; Warranty Provisions - Tectro SRE 803 injection Operating Instructions Manual

O
transportation cap
4
40
N
TRANSPORTATION
Take the following measures to avoid fuel leakage during the transportation of
the heater:
1 Let the heater cool down.
Remove the removable tank ¶ from the heater and remove the fuel filter
2
(refer to Section L, Fig. M). Some drops may leak from the filter; keep a cloth
at hand. Store the fuel filter and the removable tank outside the heater.
3 Place the transportation cap into the position of the fuel filter (Fig. N).
Press it tight.
4 Always move the heater in an upright position.
O

SPECIFICATIONS

Ignition
Fuel
Capacity (kW) max.
Capacity (kW) min.
Suitable space (m 3 ) **
Fuel consumption (l/hr)
Fuel consumption (g/hr)
Burning time per tank (hr)
Capacity removable tank (litres) 5,4
Weight (kg)
* At maximum setting
** Specified values are indicative
P

WARRANTY PROVISIONS

Your heater comes with a 24-month warranty starting on the date of purchase.
Within this period all defects in material or workmanship will be repaired without
any charge. The following provisions shall apply regarding this warranty:
1 We expressly dismiss all other claims for damages, including consequential
damages.
2 Any repairs or replacements of components within the term of warranty will
not result in an extension of the term of warranty.
3 The warranty shall no longer apply, when the heater has been modified,
non-original parts have been used, or when it is repaired by third parties.
4 The warranty shall not apply to parts that are subject to normal wear, such as
the burner mat and the manual fuel pump.
electrical Dimensions (mm)
paraffin (including base plate) depth
3,6
1,05 Accessories
35-150
* 0,375 Mains
* 300
* 14 Electrical consumption igniter
11 Fuse rating
width 516
315
height 450
manual fuel pump
transportation cap
220V/230V
-- AC/50 Hz
368 W
continuous 28 W
250V, 5A
