- Page 1 BEATRICE P1 & P2 Phone handset Dante network intercom PRODUCT DETAILS THE DESIGN BUILDINGS, 6 BROOKS PLACE, MAIDSTONE, KENT, ME14 1HE. UK. TEL: +44 (0) 1622 753662 Visit our Website at www.glensound.com...
- Page 2 Glensound Electronics Ltd Thank you for choosing a new Glensound product. All rights reserved. Information contained in this manual is subject to change without notice, if in doubt please contact us for the latest product information. If you need any help with the product then we can be contacted at:...
-
Page 3: Product Warranty
PRODUCT WARRANTY All equipment is fully tested before dispatch and carefully designed to provide you with trouble free use for many years. We have a policy of supporting products for as long as possible and guarantee to be able to support your product for a minimum of 10 years. For a period of one year after the goods have been despatched the Company will guarantee the goods against any defect developing after proper use providing such defects arise solely from faulty materials or... -
Page 4: Eu Declaration Of Conformity
Phone handset Dante intercom This declaration of conformity is issued under the sole responsibility of the manufacturer. This equipment is manufactured by Glensound Electronics Ltd of Brooks Place Maidstone Kent ME14 1HE is marked and conforms to the following Union harmonisation legislation:... -
Page 5: Rohs Directive
RoHS DIRECTIVE RoHS 2 Directive 2011/65/EU restricts the use of the hazardous substances listed below in electrical and electronic equipment. This product conforms to the above directive and for these purposes, the maximum concentration values of the restricted substances by weight in homogenous materials are: Lead 0.1%... -
Page 6: Waste Electrical And Electronic Equipment Regulations 2006 (Weee)
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT REGULATIONS 2006 (WEEE) Glensound Electronics Ltd is registered for business to business sales of WEEE in the UK our registration number is: WEE/JJ0074UR Page 6 of 27... -
Page 7: Table Of Contents
GLENSOUND BEATRICE P1 & P2 HANDBOOK CONTENTS Description Issue 1 Page No. Contents PRODUCT WARRANTY ........................3 EU DECLARATION OF CONFORMITY ....................4 RoHS DIRECTIVE ..........................5 WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT REGULATIONS 2006 (WEEE) ....6 HANDBOOK CONTENTS ........................7 OVERVIEW ............................. -
Page 8: Overview
OVERVIEW The BEATRICE range of IP intercoms was designed for broadcast, theatre and professional audio applications. Our Beatrice intercom system utilises the reliable and proven Dante network audio transmission protocol to allow real time distribution of uncompressed audio across standard networks. As such the BEATRICE P1 & P2 units are also fully compatible with other manufacturers’... -
Page 9: P1 & P2 Rear Panel Layout
P1 & P2 REAR PANEL LAYOUT 3. RJ45 Connector 1. Encoder 5. USB Connector 2. Status LEDS 4. UPDATE Switch 1. Encoder This encoder is used to control parameters for the config settings of the device. 2. Status LEDs These LEDs indicate which setting the encoder is adjusting whilst changing config levels. -
Page 10: P1 Front Panel Layout
P1 FRONT PANEL LAYOUT 3. Incoming call LED 2. Call switch 4. Handset 1. Present LED 1. Handset The handset connects to the device via the 4P4C RJ connector on the front of the device. Please refer to the end of the manual for wiring information. When the handset is picked up the microphone audio is sent to the Dante network and muted when placed back. -
Page 11: Config Mode
CONFIG MODE The Beatrice P1 and P2 have a configuration mode that allows the user to adjust certain settings and parameters of the device. To enter config mode, press the encoder switch for 3 seconds. Config mode is linear, where settings are changed in groups that are cycled through. Group four –... -
Page 12: Reset To Factory Default Settings
RESET TO FACTORY DEFAULT SETTINGS To reset the device to a base default configuration simply hold down the update button continuously for 11 seconds. The device will beep on success. The default settings are as follows: Mic gain level 28 / 31 Sidetone level 11 / 31 Dante receive level... -
Page 13: Audio Block Diagram (Analogue Representation Of Digital Circuits)
AUDIO BLOCK DIAGRAM (analogue representation of digital circuits) Audio Circuits TO and FROM Dante/ AES67 P1 Block diagram P2 Block diagram Page 13 of 27... -
Page 14: Connecting The Beatrice Units To A Dante Network
CONNECTING THE BEATRICE UNITS TO A DANTE NETWORK The Beatrices are network audio devices utilizing the reliable and versatile Dante audio over IP protocol. Dante is a proprietary system (although very widely used) the originators of which are Audinate. The information below is only meant as a very basic guide. Full details of the power of Dante network audio and instructions for using it can be found at www.audinate.com Getting Dante Controller... -
Page 15: Running Dante Controller
The format used for the factory name is: ‘BeatriceP1-snXXX’ Where ‘BeatriceP1’ refers to the Glensound product i.e. BeatriceP1. The ‘–snXXX’ refers to the serial number of the BeatriceD8 which can be found printed on the rear or side of the unit. -
Page 16: Device Not Showing Up In Dante Controller
Device not showing up in Dante Controller If your Dante device does not show up in Dante Controller then the most likely issue is that the device’s IP Address is not appropriate for your network. A) It maybe that the device is set to obtain an IP address automatically using DHCP (this is the default configuration) and your network is setup for fixed IP addresses only and does not have a DHCP server. -
Page 17: Aes67 Mode
AES67 and therefore the Beatrice can be set to AES67 mode for interaction with other AES67 devices. Please note however that Glensound are relying on Audinate’s AES67 interface and are unfortunately not able to provide full AES67 support for the unit. AES67 support should be sought directly from Audinate. -
Page 18: Sending Aes67 Audio
Sending AES67 Audio To transmit AES67 audio to the network a multicast flow must first be setup. This is done by selecting the ‘Create New Multicast Flow’ Icon in the Device View. Tick the AES67 Flow check box, then select up to 8 channels to be included in the flow then click ‘Create’... -
Page 19: Receiving Aes67 Audio
Receiving AES67 Audio Once a compatible AES67 stream is detected on the network by Dante Controller the AES67 flows will appear in the Dante Transmitters section in the Routing tab. AES67 Restrictions AES67 flows can only be generated with the following constraints: ... -
Page 20: Updating Firmware
A windows based PC USB Type A to Micro B cable A copy of ‘DfuSe Demo’ software The latest firmware from Glensound A Beatrice P1/2 and a PoE source Instructions 1. Download and install DfuSE Demo ‘DfuSE Demo’... - Page 21 Connect the Beatrice P1/2 to the PC via the USB cable. The micro USB connector is located on the side panel of the Beatrice P1/2. Figure 2 USB connector 5. Firmware update preperation To prepare the Beatrice P1/2 for a firmware update; 1.
- Page 22 Figure 3 Device successfully recognised Now the .dfu file needs to be selected so that DfuSe Demo knows the correct firmware to put on to the Beatrice P1/2. Figure 4 Choose .dfu file Page 22 of 27...
- Page 23 Click choose and then select the .dfu file that you downloaded from the Glensound website. This will be located in your downloads folder by default. If the file loads successfully then it will read along the bottom ‘File correctly loaded’.
- Page 24 Click yes to proceed. Figure 7 Start upgrade The progress bar along the bottom will show the status of the operation. Figure 8 Upgrade status Page 24 of 27...
- Page 25 If the operation was successful, DfuSe Demo will report that “Targery 00: Verify Successful!”. You may also see that it will report how much data was successfully transferred. Figure 9 Successful upgrade! 8. Final steps Now click “Leave DFU mode” to finish the procedure. Figure 10 Final step You may now disconnect the USB cable and continue to use the Beatrice P1/2 with the freshly updated firmware!
-
Page 26: Updating The Ultimo Chipset
The ‘Product Version:’ shows the currently installed version of Ultimo Chipset dnt code. Finding Out What The Latest Available Version Is Go the Beatrice’s web page at Glensound.com and open the ‘Firmware Latest Version’ Tab. This will give both the latest version numbers/ file names and also the location to download the file from. -
Page 27: Wiring Information
WIRING INFORMATION Headset Wiring 4P4C RJ AUDIO PINOUTS: 1 2 3 4 1: MATE/ NEGATIVE/ MIC - 2: EARPIECE + 3: EARPIECE – 4: INPHASE/ POSITIVE/ MIC + Page 27 of 27...
