- Page 1 BEATRICE R16 16 Channel Network Audio Intercom PRODUCT DETAILS 6 BROOKS PLACE, MAIDSTONE, KENT, ME14 1HE. ENGLAND. TEL: +44 (0) 1622 753662 Visit our Website at www.glensound.com...
- Page 2 Page 2 of 34...
- Page 3 Glensound Electronics Ltd Thank you for choosing a new Glensound product. All rights reserved. Information contained in this manual is subject to change without notice, if in doubt please contact us for the latest product information. If you need any help with the product then we can be contacted at: Glensound Electronics Ltd 1 –...
-
Page 4: Product Warranty
PRODUCT WARRANTY: All equipment is fully tested before dispatch and carefully designed to provide you with trouble free use for many years. We have a policy of supporting products for as long as possible and guarantee to be able to support your product for a minimum of 10 years. For a period of one year after the goods have been despatched the Company will guarantee the goods against any defect developing after proper use providing such defects arise solely from faulty materials or workmanship and... - Page 5 / AES67 desktop intercom ® This declaration of conformity is issued under the sole responsibility of the manufacturer. This equipment is manufactured by Glensound Electronics Ltd of Brooks Place Maidstone Kent ME14 1HE is marked and conforms to the following Union harmonisation legislation:...
- Page 6 RoHS DIRECTIVE EC directive 2002/95/EC restricts the use of the hazardous substances listed below in electrical and electronic equipment. This product conforms to the above directive and for this purposes, the maximum concentration values of the restricted substances by weight in homogenous materials are: Lead 0.1%...
- Page 7 WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT REGULATIONS 2006 (WEEE) Glensound Electronics Ltd is registered for business to business sales of WEEE in the UK our registration number is: WEE/JJ0074UR Page 7 of 34...
-
Page 8: Table Of Contents
GLENSOUND BEATRICE R16 Handbook Contents Issue 2 Description Page No. Contents PRODUCT WARRANTY: ........................4 OVERVIEW ............................9 R16 FRONT PANEL LAYOUT ......................10 R16 REAR PANEL LAYOUT ......................... 13 MICROPHONE PHANTOM POWER ...................... 15 LOUDSPEAKER DIM LEVEL ......................... 16 SIDETONE ............................ -
Page 9: Overview
OVERVIEW The BEATRICE range of IP intercoms was designed for broadcast, theatre and professional audio applications. Our Beatrice intercom system utilises the reliable and proven Dante network audio ® transmission protocol to allow real time distribution of uncompressed audio across standard networks. -
Page 10: R16 Front Panel Layout
R16 FRONT PANEL LAYOUT 4. Speak To All 5. Present LED 3. Panel 2. External 1. Headphone/ Speaker Volume Mic Input 6. Level 7. Speak To Group 15. Speak Keys 14. O/P Gain 9. Headphones 11. Mic Select 13. I/P Gain 8. - Page 11 5. Present LED Indicators There are 16 present indicators one for each talkback input from the audio network. These are a LED indicator. When an incoming audio signal is detected on the associated incoming circuit the present LED will illuminate (threshold -20dB) to show that audio is being received on that channel.
- Page 12 11. Mic Select This toggle switch selects which of the 2 microphones is to be used as the audio source. If the switch is in the up position then the panel mic is used and if the switch is in the down positon the external microphone input is used. 12.
-
Page 13: R16 Rear Panel Layout
They accept standard SFP modules. The status LEDs flash to show when data is being correctly communicated with the attached switch. If you require SFP modules then please email sales@glensound.co.uk for a quotation. Network Note (Applies to both 17 & 18) Factory default is to have the SFP &... - Page 14 18. Network RJ45s There are 2 standard network data RJ45 sockets provided to allow redundant network connectivity if using Dante network audio protocol. They are both ® gigabit network connections. The status LEDs flash to show when data is being correctly communicated with the attached switch.
-
Page 15: Microphone Phantom Power
MICROPHONE PHANTOM POWER The factory default configuration of the R16 has the front panel microphone input set as +12v phantom power on. It is possible to de activate or activate +12v phantom panel by moving an internal jumper. To turn on phantom power the lid of the unit must be removed. Please make sure the unit is turned off before starting this procedure To do this remove one of the sides of the unit, which is held in place by 4 screws (2 at the front &... -
Page 16: Loudspeaker Dim Level
LOUDSPEAKER DIM LEVEL The R16 has a loudspeaker dim circuit that automatically dims (reduces) the volume of the loudspeaker when any talkback key is operated. During initial test at the factory the DIM amount will have been set to the factory default level. -
Page 17: Sidetone
SIDETONE Sidetone, the audio level of the operator’s own voice in the headphone output. Some operators like sidetone as it provides confidence that their voice is being transmitted, while other do not like it as it can be a distraction. The sidetone level can be adjusted by the operator. -
Page 18: Speak Key Configuration
SPEAK KEY CONFIGURATION It is possible to set the operation of individual speak keys to behave in a way that is suitable for your way of working. To access the speak key configuration menu then first start with the Beatrice R16 turned off. -
Page 19: Audio Block Diagrams (Analogue Representation Of Digital Circuits)
AUDIO BLOCK DIAGRAMS (analogue representation of digital circuits) Audio Circuits TO Dante/ AES67 Network SEE ALSO FIXED MIXER Page 19 of 34... -
Page 20: See Also Fixed Mixer
SEE ALSO FIXED MIXER Audio Circuits FROM Dante/ AES67 Network PRESENCE I/P GAIN RX 1 Dante I/P 1 PRESENCE I/P GAIN RX 2 Dante I/P 2 PRESENCE I/P GAIN RX 3 Dante I/P 3 PRESENCE I/P GAIN RX 4 Dante I/P 4 PRESENCE I/P GAIN RX 5 Dante I/P 5... -
Page 21: Fixed Mixer
FIXED MIXER The Beatrice R16 includes multiple fixed ratio mixers with inputs & outputs directly on/ off the Dante/ AES67 network. In a small simple intercom system there may be requirements for one user to listen to multiple sources on one single talkback channel. The internal fixed mixer within the Beatrice R16 is suitable for setting this up. -
Page 22: Connecting To 4-Wire Equipment
CONNECTING TO 4-WIRE EQUIPMENT The Beatrice R16 can be interfaced to a maximum of two traditional 4-wire systems. To do this it is necessary to utilise the local audio inputs & local audio output circuits on the R16 and route these to/ from one of the talkback channels via the audio over IP network. -
Page 23: Ifb/ Aux Inputs
IFB/ AUX INPUTS There are four IFB (Interruptible Feed Back)/ AUX circuits within the Beatrice R16. These are incoming audio circuits from the Dante / AES67 network that are mixed in ® with the outgoing talkback circuits. The IFB/AUX circuit is always routed/ mixed with the outgoing talkback, if the associated talkback key is on, then the IFB/ AUX audio level is ducked, to allow the talkback to be clearly heard over it. -
Page 24: Connecting The Beatrice Units To A Dante Network
CONNECTING THE BEATRICE UNITS TO A DANTE NETWORK The Beatrices are network audio devices utilizing the reliable and versatile Dante audio over IP protocol. Dante is a proprietary system (although very widely used) the originators of which are Audinate. The information below is only meant as a very basic guide. Full details of the power of Dante network audio and instructions for using it can be found at www.audinate.com Getting Dante Controller... -
Page 25: Running Dante Controller
The format used for the factory name is: ‘BeatriceR8-snXXX’ Where ‘BeatriceR8’ refers to the Glensound product i.e. BeatriceR8. The ‘–snXXX’ refers to the serial number of the BeatriceD8 which can be found printed on the rear or side of the unit. -
Page 26: Device Not Showing Up In Dante Controller
Device Not Showing Up In Dante Controller If your Dante® device does not show up in Dante® Controller then the most likely issue is that the device’s IP Address is not appropriate for your network. A) It maybe that the device is set to obtain an IP address automatically using DHCP (this is the default configuration) and your network is setup for fixed IP addresses only and does not have a DHCP server. -
Page 27: Aes67 Mode
AES67 and therefore the Beatrice can be set to AES67 mode for interaction with other AES67 devices. Please note however that Glensound are relying on Audinate’s AES67 interface and are unfortunately not able to provide full AES67 support for the unit. AES67 support should be sought directly from Audinate. - Page 28 2. Sending AES67 Audio To transmit AES67 audio to the network a multicast flow must first be setup. This is done by selecting the ‘Create New Multicast Flow’ Icon in the Device View. Tick the AES67 Flow check box, then select up to 8 channels to be included in the flow then click ‘Create’...
- Page 29 3. Receiving AES67 Audio Once a compatible AES67 stream is detected on the network by Dante Controller the AES67 flows will appear in the Dante Transmitters section in the Routing tab. 4. AES67 Restrictions AES67 flows can only be generated with the following constraints: ...
-
Page 30: Updating The Brooklyn Module
Information’ heading. 2. Finding Out What The Latest Available Version Is Go the Beatrice R16’s web page at http://www.glensound.co.uk/product- details/beatrice-r16/ and open the ‘Firmware Latest Version’ Tab. This will give both the latest version numbers/ file names and also the location to download the file from. -
Page 31: Wiring Information
WIRING INFORMATION XLR & JACK Wiring STANDARD XLR AUDIO PINOUTS: 1: Ground/ Earth XLR SOCKET (FEMALE) 2: INPHASE/ POSITIVE/ MIC + 3: MATE/ NEGATIVE/ MIC - STANDARD HEADPHONE WIRING: TIP: A/ LEFT Ear RING: B/ RIGHT Ear SLEEVE: Common/ Earth RING SLEEVE Page 31 of 34... - Page 32 5 & 4 Pin Headset Wiring Options 5 PIN XLR AUDIO PINOUTS: 1: MATE/ NEGATIVE/ MIC - 2: INPHASE/ POSITIVE/ MIC + 3: GROUND/ EARTH 4: HEADPHONE LEFT 5: HEADPHONE RIGHT 4 PIN XLR AUDIO PINOUTS: 1: MIC GND/ MIC – 2: INPHASE/ POSITIVE/ MIC + 3: HEADPHONE GND 4: POSITIVE/ HEADPHONE +...
-
Page 33: D15 Socket Loop Input Wiring
D15 Socket Loop Input Wiring PIN Number Function Speak 1 Button Speak 2 Button Speak 3 Button Speak 4 Button Speak 5 Button Speak 6 Button Speak 7 Button Speak 8 Button Speak to Group Speak to All Cut Internal LS / HP Out Cut EXT SPKR Out 13 - 14 Not connected... -
Page 34: D25 Plug Loop Output Wiring
D25 Plug Loop Output Wiring PIN Numbers Function 1 & 14 Not Used 2 & 15 Not Used 3 & 16 Not Used 4 & 17 Not Used 5 & 18 Not Used 6 & 19 Not Used 7 & 20 Not Used 8 &...
