Summary of Contents for Redtronic Bullitt Advanced
- Page 1 ADVANCED USER MANUAL...
-
Page 2: Table Of Contents
Contents Introduction Lightbar Specification Power Specification LBAR Main Controller 4.1 Input / Output functions 4.2 Wiring and Connectivity Setting the Flash Pattern 5.1 360 Output 1&2 5.2 Alley Lights CAP168 / ICAO / CAA / ACAA / Airport mode Setting Dim Mode ECE R65 Monitor Output Setting the Colour 10.0... - Page 3 Appendix 1 Dipswitch settings Appendix 2 Diagnostics Appendix 3 Glossary of Terms M003 Issue: 1.6 Created by: Technical Dept. January 2024...
-
Page 4: Introduction
• Front Take-Downs Power Specification (-ve earth) Bullitt Advanced Lightbars are manufactured to operate within the voltage range of 10-30v DC negative ground . This will require setting upon installation to ensure correct functionality. Supply Voltage 11-30v DC full brightness Possible (begins to reduce below 11v for green, blue and white LED’s) -
Page 5: Lbar Main Controller
LBAR Main Controller (F1-F9) There are nine programmable inputs available to programme a variety of 23 optional features. Input / Output functions Standby Mode Wiring & Connectivity PCB IDENTS M003 Issue: 1.6 Created by: Technical Dept. January 2024... -
Page 6: Setting The Flash Pattern
Setting the Flash Pattern 360 Output 1 & 2 (Standard Flash Patterns) The Bullitt Advanced Lightbar has 16 x ECE R65 approved flash patterns available that can be programmed to the outputs FLASH PATTERN LED FUNCTION FLASH PATTERN LED FUNCTION... -
Page 7: Alley Lights
Alley Lights – ‘Permanent on’ or ‘Flash’ Ensure the Lightbar is in ‘Standby’ mode by connecting Black Apply the Alley Left & Alley Right input wires to +ve permanently (Pattern Select) Apply the brown wire to +ve momentarily The Alley Lights will now flash in an alternating pattern (Pattern Select) To Revert to ‘Permanent on’... -
Page 8: Ece R65 Monitor Output
(Dim) Apply the blue wire to +ve permanently (Config) Apply the grey wire to +ve permanently (Pattern Select) Apply the brown wire to +ve momentarily Lamps will reduce in brightness Release the grey wire To revert back to default setting simply repeat the process Note 25% Dim mode does not meet the requirements of the R65 candela (brightness) specification ECE R65 Monitor Output The monitor output activates when the Lightbar is flashing with R65 compliance. -
Page 9: Reset Input
(Pattern Select) Apply the brown wire to +ve permanently for 5 seconds, diagnostic LED will display 4 short flashes – do not proceed to next stage without this ‘pause’ F1-F9 Apply the required input wire individually ( ) to +ve permanently (Config) Apply the grey wire momentarily to +ve to cycle through to the required function. -
Page 10: Traffic Director
11.0 Traffic Director By default, the three main Traffic Director (TDIR) inputs are setup to operate on the Rear Only. However, the inputs can also be programmed to operate as Front Only, Front & Rear or Front & Rear opposite. Additionally, the colour can be set individually to (refer to 9.0 Setting the Colour) each input You can also setup the length of the TDIR and select optional ‘chase’... -
Page 11: Additional Programmable Inputs
12.0 Additional Programmable Inputs (F1-F9). These are functions that may be set to any of the inputs The user can assign the function if it has not been set in the factory, however this will mean replacing an already programmed input if there are no spare function wires available. Pattern and Colour (Dual and Multi-Colour only) are selectable. -
Page 12: Left Indicator
sets the REAR INDICATOR positions 12.7 Left Indicator – You must utilise 2 x BL.ADSTI or 2 x BL.ADIND for this function to work as expected – setting this feature on a standard lightbar lamp does not meet UNECER6 & UNECER7 homologation requirements unless the specified lamps are utilised. This setup procedure sets up the REAR POSITION of the Indicators in the lightbar. -
Page 13: Rear Worklamp
Set selected modules to permanent on Rear Worklamp - 12.9 Follow section 10.1, selecting feature code 22 for Rear Worklamp (sync) Apply the yellow wire to -ve permanently (Config) Apply the grey wire to +ve permanently Apply the brown wire to +ve momentarily until the required modules are lit – you can cycle through various lamp positions at this stage, with each cycle it will ‘add’... -
Page 14: Setting Flexi-Flash Modules
Flexi-Flash Sequence Rear Only Front Right only Front Only Front Left only Front & Rear Front & Rear Right only Rear Right only Front & Rear Left only Rear Left only Sync -ve Permanent On To ‘alternate’ the flash mode against 360/1, 360/2, another flexi-flash or other mode (if not restricted) – (Pattern Select) simple apply the brown... - Page 15 Fig. 1 Fig. 2 M003 Issue: 1.6 Created by: Technical Dept. January 2024...
-
Page 16: Inclusion / Exclusion Flag
12.15 Inclusion / Exclusion flag Within the lightbar, there are various features, mainly on ‘single colour modules’ that may ‘clash’ with another feature setup on the lightbar. For example : Below the lightbar is set up as Blue 360/2 (Blue lights) – but you wouldn’t want the traffic director to flash in Amber when the Blues are flashing as standard –... -
Page 17: Upgrades
13.0 Lightbar Upgrades The unique design of the Bullitt Advanced permits certain user upgrades to be carried out giving improved visibility or additional functionality, such as Traffic Director, Stop/Tail/Indicator or Alley Lights. Some programming will be required dependant on the type of upgrade (refer to 10.0... - Page 18 d) Connect the module to the existing string via the 4-way connector e) If the string contains four (4) or more LED modules the return connector loom on the LBAR Main Controller must be used Rear Left Rear Right Front Left Front Right M003 Issue: 1.6 Created by: Technical Dept.
-
Page 19: Alley Lights
With the new LED modules in position, carefully replace the top lenses and secure using the M4 and M6 socket All fixings must be inserted with a torque setting of 1.8Nm (18.4Kg/cm, 15.9in/lbs, cap screws and washers - 1.33ft/lbs) g) Reconnect to the vehicle battery h) Refer to 10.0 Programming the Lightbar For Dual and Multi-Colour Lightbars refer to 9.0 Setting the Colour 13.2 Adding Alley Light modules (EM315WC/BL (internal stock code S.EM315WC/BL)) -
Page 20: Fuse Requirements
Fig. 2 Reconnect to the vehicle battery (white/yellow) (white/orange) g) Alley Lights are normally connected to F7 and F8 , therefore there is no requirement to programme the input as this is the default wiring h) Should any other input wire be used refer to 10.0 Programming the Lightbar Refer to 5.2 to set the required operation of each Alley Light 14.0 Fuse Requirements... -
Page 21: Synchronisation
15.0 Synchronisation (yellow) The Sync input/output is used to synchronise flashing with other Redtronic products. The Sync wire should be connected to all other products that require synchronising with the Lightbar. DO NOT APPLY THE YELLOW WIRE TO +VE SUPPLY IN ANY CIRCUMSTANCE. -
Page 22: Cleaning The Lightbar
No car washes No brush washes Microfibre cloths When pressure washing a vehicle fitted with a Bullitt Advanced lightbar, adhere to the following guidelines: Keep the pressure washer nozzle a minimum distance of 15cm from the lightbar • Use clean water free of detergents •... -
Page 23: Troubleshooting
(see 14.0 for fuse requirements) Input function will not programme Poor connection Check connection to +ve when programming. If problem persists contact Redtronic Not all LED’s are working Configuration Apply Yellow to -ve and grey wire to +ve momentarily. If that does not resolve the issue, follow section 10.0 to reset... - Page 24 APPENDIX 1 – Dipswitch settings Dipswitch For use on single & dual colour lightbars - offers only 3 10 colour options 3 colour options (100% colour settings (not all 10) brightness) Enable airport flash mode within standard pattern No airport mode selectable within Introduce 4 x cap168 patterns to selection mode patterns –...
- Page 25 Lightbar is connected to a power source & fused correctly S/T/I Stop/Tail/Indicator Sync The matching of Redtronic products to enable them to flash together Traffic Director TDIR Application of force acting at a radial distance and tending to cause rotation...
