Smartbox Touch Pad Manual

Hide thumbs Also See for Touch Pad:

Advertisement

Quick Links

Download this manual
Manual
Created by

Advertisement

loading
Need help?

Need help?

Do you have a question about the Touch Pad and is the answer not in the manual?

Questions and answers

Related Manuals for Smartbox Touch Pad

Summary of Contents for Smartbox Touch Pad

  • Page 1 Manual Created by...
  • Page 2 This guide provides the basics for getting started with your Touch Pad. hub.thinksmartbox.com/TouchPad Document: Touch Pad - Manual - UK - K Language: English Date of issue: Decmeber 2023 Copyright © 2023 Smartbox Assistive Technology...

  • Page 3: Table Of Contents

    Manual Starting Grid 3 Power Device guide Charging Mounting Shoulder strap...

  • Page 4: Starting Grid

    Starting Grid 3 Grid 3 will automatically start when the device is switched on by default. However, you can start Grid 3 from icon on the desktop. Grid 3...
  • Page 5 For more resources and guides on how to get started with Grid visit the Smartbox Hub. • Get started with Grid • Access methods and setup • Troubleshooting guides • Videos and webinars • Resources for grid sets • ...and much more.

  • Page 6: Power

    Power Before switching on your Touch Pad for the first time, it is best to plug in the power lead and charge the battery fully. Press the power button to turn the device on. Power The device will boot into Windows, and Grid 3 will automatically start.
  • Page 7 Force shut down If you press and hold the power button for ten seconds, your Touch Pad will shut down. Please note that this is only recommended when the Touch Pad is non- responsive. Any unsaved work will be lost.

  • Page 8: Device Guide

    Device guide Volume up and down Power Front camera Handle Touch screen...
  • Page 9 Headphone port USB C Charging port Rear camera Speaker charging port Speaker power button Stand Speaker Strap rings...

  • Page 10: Charging

    Charging To charge your Touch Pad, plug the power lead into the charging port on the left side of the device. To charge both the Touch Pad and the speaker at the same time use the provided charging lead with USB C.

  • Page 11: Mounting

    You will need the supplied Allen key, mounting plate and the three screws. Remove the stickers covering the three screw holes. Use the supplied Allen key to remove the three screws located on the back of the Touch pad, as shown below.
  • Page 12 Touch Pad to your wheelchair mount, floor stand or desk stand. As you attach the device to the stand, be sure to hold the Touch Pad securely until the head of the stand is firmly docked with the mounting plate.

  • Page 13: Shoulder Strap

    First loop the clips to the case of the Touch Pad. Then you can attach the longer strap. The strap can be adjusted to a suitable length.
  • Page 14 Touch Pad - Manual - UK - K...
