Whirlpool Gold GLT3057R Use & Care Manual page 5

Control Panel
C
B
A
A. Left front burner control knob
B. Surface burner locator
Cooktop
E
D
C
B
A
A. 12,500 Btu/h burner
B. Surface burner cap
C. Left surface burner grate
D. 6,000 Btu/h burner on 36" (91.4 cm) model
9,100 Btu/h burner on 30" (76.2 cm) model
Model GLT3657 (36" [91.4 cm] shown)
Model GLT3057 (30" [76.2 cm] not shown)
D
C. Left rear burner control knob
D. Center rear burner control knob
(on 36" [91.4 cm] models only)
F
G
K
E. Model and serial number plate
(under cooktop)
F. 9,100 Btu/h burner on 36" (91.4 cm)
models only
G. Center grate
E
F
G
E. Right rear burner control knob
F. Control knob off position
G. Right front burner control knob
H
I
J
H. 6,000 Btu/h burner
I. Right surface burner grate
J. 12,500 Btu/h burner
K. Control panel
5
