Summary of Contents for Schneider digital 3D Pluraview A14815
- Page 1 PluraView PluraView 27" / 28" USER MANUAL...
- Page 2 The new Schneider Digital 3D PluraView monitor with innovative beam splitter technology offers the highest quality for stereoscopic display on desktop monitors. FOR 3D-STEREO PROFESSIONALS...
-
Page 3: Table Of Contents
CONTENTS Advantages of stereoscopic visualization Stereo beam splitter Functionality Product description Scope of delivery Unpacking the monitor Mounting the monitor Installing the monitor on the workstation Adjusting the monitor Control elements on the displays Cleaning and care Safety instructions Troubleshooting Legend Optional accessories Technical data... -
Page 4: Advantages Of Stereoscopic Visualization
User manual ADVANTAGES OF STEREOSCOPIC VISUALIZATION For the highest demands in 3D stereo applications Nature has given humans the ability to see stereoscopically, i.e. spatially. This enables us to intuitively estimate our own position in the environment and the distance to any other points in our field of vision. -
Page 5: Stereo Beam Splitter Functionality
(half mirror) 135° polarized left eye image Copyright by Schneider Digital The 3D PluraView beamsplitter monitor consists of a precisely viewpoint) for the right eye. The different polarization of the crafted, sturdy metal housing in which two LCD monitors are displays allows polarization of the displays allows excellent installed at a specific angle to each other. -
Page 6: Product Description
User manual PRODUCT DESCRIPTION 27" and 28" 3D PluraView 2D mode 3D mode With the beamsplitter mirror folded up, the 3D PluraView can The Beamsplitter mirror can be easily released from its be used without restriction for all applications and screen locking mechanism and folded down with a flick of the content. -
Page 7: Scope Of Delivery
User manual SCOPE OF DELIVERY This is included in the package 1 x monitor stand with lower monitor, beamsplitter holder and pre-assembled Displayport connection cables (3m) to graphics card/workstation 1 x Upper monitor holder with pre-calibrated monitor 1 x Beamsplitter mirror with mirror holder and handle bar 2 x Plastic shims for the beamsplitter holder 2 x Knurled screws for mirror adjustment 3 x Allen key (2.5, 3 and 5 mm) -
Page 8: Unpacking The Monitor
User manual UNPACKING THE MONITOR It is recommended that two people unpack and set up the 3D PluraView monitor Open the box at the top and remove the molded parts that hold the monitor in place from above. On one side is the monitor stand with the lower monitor monitor on one side and the upper monitor on the other, with the beamsplitter mirror in between. - Page 9 User manual Works without special driverswith Microsoft / LINUX / macOS 3D PluraView Plug & Play...
-
Page 10: Mounting The Monitor
User manual MOUNTING THE MONITOR Adaptation of the 3D PluraView workstation to the floor space Check that the table is level. If the stand wobbles, you can adjust the rear feet using the 5 mm Allen key. By adjusting the rear monitor feet, the monitor can be tilted by a few degrees to suit your needs. - Page 11 User manual MOUNTING THE MONITOR Attaching the upper monitor and cable connection Hold the upper monitor holder so that the display is facing you. Insert the two hooks at the lower end of the upper monitor holder into the slots in the oval tube of the lower section.
- Page 12 User manual MOUNTING THE MONITOR Inserting and adjusting the mirror Remove the plastic shims, cables and the knurled screws for fine adjustment of the mirror from the accessory box. Place the washers on the rear bolts of the mirror arms. Carefully remove the Beamsplitter mirror from the bubble bag and store it with the rest of the packaging.
- Page 13 User manual MOUNTING THE MONITOR Change and possibilities of the mirror position Screw the two knurled screws for fine adjustment left and right into the mirror holder until the mirror lifts slightly. Please carry out the adjustment (see page 16) before using the mirror for the first time.
-
Page 14: Installing The Monitor On The Workstation
User manual INSTALLING THE MONITOR ON THE WORKSTATION Connect, switch on and get started 1 Illuminated on/off switch 2 Fuse link with spare 3A fuse 3 IEC plug (220V/110V) 4 Displayport cable - 'Bottom' and 'Top' 5 USB connection If you want to use the USB hub of the lower monitor, you can connect the monitor to the workstation via this USB-B interface. - Page 15 User manual The new 3D PluraView monitor with innovative beam splitter technology offers the highest quality for stereoscopic display at the workplace. 3D PluraView...
-
Page 16: Adjusting The Monitor
User manual ADJUSTING THE MONITORS Fine adjustment of the monitor a. The monitor has already been adjusted at the factory. However, it is necessary to set the correct mirror position using the two knurled screws on the left and right of the mirror arm. b. - Page 17 User manual For all 3D stereo applications in GEO/GIS, BIM, Medical, Bio-Tech & CAx Perfect for all 3D applications...
- Page 18 User manual CONTROLS ON THE DISPLAYS 27" Operating display and menu On/off display: Scroll down / brightness button (▶/ ) Blue: Normal operation Scroll up / ECO Mode button (▶/ ) Orange: Energy management Exit button (EXIT) On/off switch ( ) Input source button (INPUT) Menu / Select button (ENTER) ATTENTION!
- Page 19 User manual CONTROLS ON THE DISPLAYS 28" Views in detail prevent the user from being dazzled. On/off switch ( ) Blue: Normal operation Menu button (MENU) Orange: Energy management Scroll up / Volume button (▶/ ) Scroll down / ECO Mode button ( ‒ / ) On/off display: Input source / Auto / Exit button (AUTO) The LED is fitted with a sliding cover to...
- Page 20 The 3D PluraView is ideal for all stereo software applications in a wide range of industries. Unique 3D stereo experience...
-
Page 21: Cleaning And Care
User manual CLEANING AND CARE Disconnect the mains plug before cleaning the monitor. To clean the displays and the Beamsplitter mirror, use a clean, soft cloth and, if necessary, a mild cleaner that is suitable for plastic surfaces. Always spray this onto the cloth, never directly onto the display. - Page 22 If you notice any abnormal phenomena such as smoke, noise or odors, switch off the 3D PluraView stereo monitor immediately and disconnect the power plug from the device. Please then inform your specialist dealer or the Schneider Digital service team. Continued operation can be dangerous and lead to fire or electric shock.
- Page 23 For safety reasons, always disconnect the mains plug before cleaning the monitor. If liquid or solid materials get into the monitor during cleaning, please switch off your monitor immediately and disconnect the mains plug. In this case, please contact your specialist dealer or the Schneider Digital service team. NOTE Do not clean the screen surface with a rough object.
-
Page 24: Troubleshooting
User manual TROUBLESHOOTING The meaning of the mirror card LEDs BOTTOM MEANING Blue During start-up or during a firmware update Blue Ready but no signal from the graphics card Turquoise Blue -> Turquoise Regular operation - DP RX Link Rate 5.4 Gbps (4K60) Turquoise Blue Regular operation - DP RX Link Rate 2.7 Gbps (4K30) - Page 25 User manual Action: Bypass the integrated mirror card by connecting the display and graphics card directly using a DisplayPort cable. using a DisplayPort cable. Check: Power indicator on both displays lights up blue. Under Windows "Display settings/Advanced display settings Display settings", both displays are shown with the same name. 3.
-
Page 26: Legend
User manual LEGEND Monitor base Front monitor cover Lower display Upper monitor cover Adjustment screws for feet Rear monitor cover Mirror handle bar Lighted on/off switch Beamsplitter mirror Device socket Mirror arm Fuse box with 1 spare fuse (3A) Thumbscrews for mirror adjustment Displayport connection cable Upper display USB socket... -
Page 27: Optional Accessories
User manual Für ein noch realistischeres 3D-Erlebnis 1 Monat Akkulaufzeit – die SpaceMouse Wireless arbeitet mit einer Akkuladung bis zu einem Monat lang. Elegantes Design – kompakte Standfläche, Fundament aus gebürstetem Stahl, zwei Tasten. OPTIONAL kann ACCESSORIES Foot raiser 4cm, 2-piece Flightcase 3D glasses 3D PluraView mouse pad 3D controller (Stealth, 3D Connexion) - Page 28 3D PLURAVIEW MONITOR SPECIFICATIONS 27" 2,5K 28” 4K/UHD User manual Display 27” (686 mm) Screen Size 28” (711 mm) Screen Size 2x 2,560 x 1,440 Resolution (3.7 MP) 2x 3,840 x 2,160 Resolution (8.3 MP) 16.7 Million Colors (8-bit) 1,073 Billion Colors (10-bit*) 350 cd/m Brightness 300 cd/m...
-
Page 29: Ec Declarations Of Conformity
Directive in its design and construction and in the version placed on the market by us. If the product is modified without our agreement, this declaration will no longer be valid. The manufacturer bears sole responsibility for issuing this declaration of conformity. MANUFACTURER/AUTHORIZED REPRESENTATIVE Schneider Digital Josef J. Schneider e. K. Maxlrainer Str. 10 D-83714 Miesbach PRODUCT MODEL A14815 3D PluraView 27"... - Page 30 Directive in its design and construction and in the version placed on the market by us. If the product is modified without our agreement, this declaration will no longer be valid. The manufacturer bears sole responsibility for issuing this declaration of conformity. MANUFACTURER/AUTHORIZED REPRESENTATIVE Schneider Digital Josef J. Schneider e. K. Maxlrainer Str. 10 D-83714 Miesbach PRODUCT MODEL A16140 3D PluraView 28"...
- Page 31 User manual WARRANTY Schneider Digital grants a 12-month manufacturer's warranty on the 3D PluraView stereo monitor. The warranty can be extended for up to 5 years from the date of purchase. SERVICE ADDRESS IN THE EVENT OF A DEFECT IN YOUR 3D PLURAVIEW, PLEASE CONTACT Schneider Digital Josef J.
- Page 32 SCHNEIDER DIGITAL Josef J. Schneider e.K. Maxlrainer Straße 10 D-83714 Miesbach Tel.: +49 (8025) 9930-0 Fax: +49 (8025) 9930-299 www.schneider-digital.com info@schneider-digital.com Partner of: PluraView PluraView PluraView...
