LED Foldable Solar Wall Light with Radar Sensor
ESOL2.5W-WH/BL, ESOL3.5W-WH/BL, ESOL7.5W-WH/BL
This product is a rechargeable LED solar wall light with integrated radar sensor. Movement is recognized
by the sensor in the detection area. The integrated rechargeable batteries are charged by the solar
panel. Sunlight/daylight provides energy for rechargeable batteries during the day and the product lights
up automatically at dusk.
This pack contains:
1 * Solar wall light
2 * Screws
3 * Anchors
4 * User manual
Specification:
Product Code:
Wattage
Material
Solar Panel
Battery
IP Grade
Colour Temperature
Luminous Flux
LED Beam Angle
Charging time
Operating time
Housing Finish
Dimensions
1. Mark the hole for screws
Distance: 2.5w - 5cm, 3.5w -
6cm, 7.5w - 6cm
Installation Instructions
ESOL2.5W-WH/BL
2.5W
Poly-Silicon 6V 330mA
18650 Li-ion, 3.7V
1500mAh
Min 207Lm
Max 230Lm
6-8 hours (without direct sunlight the lighting time can be shorter)
130x190x105mm
Installation
Pencil
2pc
2pc
2. Mount the solar light using supplied
Screws
ESOL3.5W-WH/BL
3.5W
ABS
Poly-Silicon 6V 670mA
18650 Li-ion, 3.7V
1800mAh
IP44 Waterproof
4000k
Min 306Lm
Max 340Lm
120°
4-6 hours
Black or White
178x185x105mm
Drill
These are needed for installation
3. 4-6 hrs fully charge time
ESOL7.5W-WH/BL
7.5W
Mono-Silicon 6V 1A
18650 Li-ion, 3.7V
4800mAh
Min 630Lm
Max 700Lm
229x185x105mm
Screwdriver
