XRLED 700-W BWS
PR-8173
The user manual contains important information about the safe installation and use of a projector. Please read
and follow these instructions carefully and keep the manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XRLED 700-WBWS and is the answer not in the manual?

Questions and answers

Related Manuals for PR XRLED 700-WBWS

Summary of Contents for PR XRLED 700-WBWS

  • Page 1 XRLED 700-W BWS PR-8173 The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-lighting.com...

  • Page 2: Table Of Contents

    INDEX 1. SAFETYAND WARNINGS ………………………………………………………………………………………… 2. INSTRUCTIONS …………………………………………………………………………………………………… 3. APPEARANCE ………………………………………………………………………………………………… …… 4. INSTALLATION …………………………………………………………………………………………………… 5. SETUPAND CONFIGURATION …………………………………………………………………………………… 6. OPERATION MENU ……………………………………………………………………………………………… 7. DMX PROTOCOL ………………………………………………………………………………………………… 8. ERROR MESSAGES…………………………………………………………………………………………… 9. TECHNICAL DATA ………………………………………………………………………………………………… 10. CIRCUIT DIAGRAM ……………………………………………………………………………………………… 11. COMPONENT ORDER CODES ……………………………………………………………………………………...

  • Page 3: Safetyand Warnings

    Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty. 1. SAFETYAND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual.

  • Page 4: Instructions

    Any electrical connection must be carried out by a qualified person . ● Before installation, please confirm the voltage supplied matches what is required for the projector. ● Each projector must be properly earthed and installed as per related electrical standards. ●...

  • Page 5: Appearance

    To avoid sunlight or other light penetrating into the head via the front lens, resulting in high ● temperature internally causing damages to the projector. Before power-off, please use Tilt channel to move the head and make it facing downward. Do not use alcohol or other organic solvent to clean the housing to avoid damage.
  • Page 6 Warning Please run the safety cord through its 2 holes for Note: safety 1. the distance between the foot of the base and the front lens cover(the head facing downward) 2. the distance between mounting truss and the front lens cover( the head facing downward) 3.
  • Page 7 DMX CONTROLCONNECTION: ● Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the projector) or 5 pin XLR plugs and sockets.

  • Page 8: Setupand Configuration

    Open the head cover after locking the Tilt and loosening 6 fast-fit screws of the cover and the structures as illustrated by the above figures will be seen. For the rotating gobos: Take out the rotators by hand and remove the spring and gobo. Place a new gobo into the rotator and put back the spring.
  • Page 9 DMX STARTADDRESS ● Each projector must be given a DMX start address so that the correct projector responds to the correct control signals. This DMX start address is the channel number from which the projector starts to “listen” to the digital control information being sent out from the controller.

  • Page 10: Operation Menu

    Really Reset? Colour System Reset Confirm or Cancel Really Reset? Gobo Reset Confirm or Cancel Really Reset? Fo. Zo. Fr. Pr. Reset Confirm or Cancel Really Reset? Other Reset Confirm or Cancel Short Mode 25CH Standard Mode 30CH DMX Channel Mode Extended Mode 35CH .
  • Page 11 Config for the projector with XLR First Settings wireless receiver) Wireless Only Wireless First Wireless In/XLR Out ARTNET Only ARTNET In/XLR Out sACN Only sACN In /XLR Out Normal time out Loss of DMX Hold Last Value OffAfter Delay Display Mode OnAlways Invert OFF Display Config...
  • Page 12 "Speed Mode" means Pan and Tilt will move from Point A to Point B at their respective maximum speeds."Time Mode" means both Pan and Tilt Pan/Tilt mode Speed/Time will arrive at designated point at the same time. It's advised Time Mode be used if the projector runs circles or in oblique lines.
  • Page 13 Display Board= ×××C Pan & Tilt Board ×××C Temperature DriverBoard1 ×××C DriverBoard2 ×××C LED Sensor =XXXC Sys Boot Display Board xxx xxx xxx xxx Pan & Tilt board Software Version xxx xxx Driver Board1 xxx xxx Driver Board 2 Electronic SN XXXXXX XXXXXXX RDM Device Label...
  • Page 14 Change Operation Mode? User Memory 1 Confirm or Cancel Operation Change Operation Mode? User Memory 2 Mode Confirm or Cancel Change Operation Mode? Preset Memory Confirm or Cancel Change Operation Mode? Stand-Alone Mode User Memory 1 Confirm or Cancel Change Operation Mode? User Memory 2 Confirm or Cancel Change Operation Mode?

  • Page 15: Dmx Protocol

    Channel Value Strobe Dimmer Dimmer Fine CYM Macro Cyan Cyan Fine Yellow Yellow Fine Magenta Magenta Fine CTO Fine Color Wheel Color Wheel Fine XXX Iris Iris Fine Iris Macro Fix Gobo Wheel XXX Edit Static Scene Paste? Rot. Gobo Wheel Confirm/Cancel Rot.
  • Page 16 16-17 Color Temperature 4500K 18-19 Color Temperature 5000K 20-21 Color Temperature 5700K 22-23 Color Macro 1 24-25 Color Macro 2 26-27 Color Macro 3 28-29 Color Macro 4 30-31 Color Macro 5 32-33 Color Macro 6 34-35 Color Macro 7 36-37 Color Macro 8 38-39...
  • Page 17 104-105 LEE 115 (Peacock Blue) 106-107 LEE 116 (Medium Blue-Green) 108-109 LEE 117 (Steel Blue) 110-111 LEE 118 (Light Blue) 112-113 LEE 119(Deep Blue) 114-115 LEE 120 (Dark Blue) 116-117 LEE 121 (LEE Green) 118-119 LEE 128 (Bright Pink) 120-121 LEE 131 (Marine Blue) 122-123 LEE 132 (Medium Blue)
  • Page 18 192-193 LEE 353 (Lighter Blue) 194-195 LEE 715 (Cabana Blue) 196-197 LEE 778 (Millennium Gold) 198-199 LEE 793 (Vanity Fair) 200-255 CYM 混色变换效果速度由慢到快 Cyan 000-255 Cyan (linear 0~100%) Cyan Fine 000-255 Cyan in 16 Bit Yellow Yellow (linear 0~100%) 000-255 Yellow Fine Yellow in 16 Bit 000-255...
  • Page 19 Iris 000-255 Linear Iris from small to big 0-100% Iris Fine 000-255 Iris in 16 bit precision 000-010 Iris Macro disabled Iris Macro1: from big to small with speed from 011-074 slow to fast Iris Macro2: from small to big with speed from 075-138 slow to fast 139-202...
  • Page 20 196-205 Shake of Gobo 2 from slow to fast 206-215 Shake of Gobo 3 from slow to fast 216-225 Shake of Gobo 4 from slow to fast 226-235 Shake of Gobo 5 from slow to fast 236-245 Shake of Gobo 6 from slow to fast 246-255 Shake of Gobo 7 from slow to fast 000-128...

  • Page 21: Error Messages

    057-058 Slow dimmer 059-060 Gamma curve 2.0 061-062 Gamma curve 2.2 063-064 Gamma curve 2.4 065-066 Gamma curve 2.6 067-068 LED refresh rate 1200Hz 069-070 LED refresh rate 2400Hz LED refresh rate 4800Hz 071-072 LED refresh rate 10000Hz 073-074 LED refresh rate 12000Hz 075-076 LED refresh rate 15000Hz 077-078...

  • Page 22: Technicaldata

    Timeout Check if wiring, positioning parts and motors are normal Rot. Gobo Wheel Timeout Check if wiring, positioning parts and motors are normal Rot. Gobo Rotation Timeout Check if wiring, positioning parts and motors are normal Prism Timeout Check if wiring, positioning parts and motors are normal Prism Rotation Timeout Check if wiring, positioning parts and motors are normal...
  • Page 23 Gobo1 Gobo 2 Gobo 3 Gobo 4 Gobo 5 Gobo 6 Gobo 7 PRISM 1pc, 3-facet circular prism, bi-directional rotation at variable speeds, indexble. Other optional prisms are available. FROST 0-100% linear FOCUS DMX linear focus ZOOM DMX linear focus DIMMER dimming 0-100% linear with...
  • Page 24 Master mode OTHER FUNCTIONS Adjustable Pan & Tilt speeds Pan and Tilt invertible and swappable Lamp’s and fixture’s hours displayed Color touch Chinese/English screen, display invertible and touch keys Intelligently controllable fans Sensor diagnostic system Input signal isolated, modular construction for easy maintenance, DMX channel voltages monitoring Non-touchable magnetic sensor for positioning, signal feedback, absolute position memory, auto-positioning after power-off or DMX signal disrtuption Firmware upgrade via DMX cable...

  • Page 25: Circuit Diagram

    LIGHT OUTPUT 10. CIRCUIT DIAGRAM...

  • Page 27: Component Order Codes

    11.COMPONENT ORDER CODES NAME CODE NUMBER REMARK Switching power supply 6190000017 Light source 150020344 Base fan 1 030060118 Base fan 2 030060122 LED fan 1 030060121 LED fan 2 030060122 LED fan 3 030060122 Pan motor 030040276 Tilt motor 030040276 Focus motor 030040213B...
  • Page 28 1582 XingyeAvenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. CounterfeitingWill be Prosecuted! P/N:320021553...
