Stand and Fill Feeder Adder Bin Assembly Manual
Thank you for purchasing a new Orion Hunting Products Stand
and Fill Feeder.
It is our Overwhelming desire to ensure that you are satisfied with
this product.
We have taken great pride in every aspect of its design and
manufacturing right here in the U.S.A. and it is our hope that you
can take pride in owning it.
If it does not meet your expectations for any reason please give us
a call or text at (906)-767-0270 and may it truly Elevate your
Pursuit.
1) 9/16" Open End/Box End Combination Wrench
2) 9/16" Socket with Ratchet or Cordless Impact
drill preferred
Hunt safely without limits. Hunt Orion!
Tools Required
Page - 1 MSC00510
Advertisement
Related Manuals for Orion FDR1000300
Summary of Contents for Orion FDR1000300
- Page 1 Stand and Fill Feeder Adder Bin Assembly Manual Thank you for purchasing a new Orion Hunting Products Stand and Fill Feeder. It is our Overwhelming desire to ensure that you are satisfied with this product. We have taken great pride in every aspect of its design and manufacturing right here in the U.S.A.
- Page 2 300lb Stand and Fill Feeder Adder Bin Overview Feeder Adder Bin– FDR1000300 Please read through entire assembly instructions before beginning ⬣ Feeder Adder [FDR1000300] Page - 2 MSC00510...
- Page 3 Contents Feeder Adder FDR1000300 ⬣ [1X] Bin with Window – FDR1000110 ⬣[3X] Feeder Side – FDR1000102 Page - 3 MSC00510...
- Page 4 Elevated Hunting Stand Assembly **Finger tighten hardware initially** Parts 1x 150lb Feeder Base 1x Adder Bin with window 2x 3/8-16 x ¾ Flange Bolts Process Align the holes on the feeder base and adder bin and attach using the bolts Page - 4 MSC00510...
- Page 5 Parts 1x Adder Bin 3x 3/8-16 x ¾ Flange head bolts 1x 3/8-16 Flange head nuts Process Align the next adder bin with the base and attach using 2 bolts. Use the bolt and nut to attach the bin sections together Page - 5 MSC00510...
- Page 6 Parts 2x Base Plate Assm 7x 3/8-16 x ¾ Flange head bolts 3x 3/8-16 Flange head nuts Process Repeat step 2 with the remaining bins Page - 6 MSC00510...
- Page 7 Parts 1x Feeder Assm with Bins Process Ensure all parts line up and tighten all hardware Page - 7 MSC00510...
- Page 8 Parts 1x Feeder Top 4x 3/8-16 Flange nuts 4x 3/8-16 x 1-1/4 Thumb Screw Process Place the bin top on top of the feeder base assembly and line up the holes. Use the thumb screws and nuts to attach the top Page - 8 MSC00510...
