SPECIFICATIONS

DCC-11-BOX is a splitter box specifically designed to make a building's
electrical infrastructures fully ready for electric vehicles at the lowest
possible price.
MODEL
60A
DCC-11-BOX
240/208V AC single phase:
Voltage and wiring
L1, L2, Neutral, Ground.
Terminals size up to 300 MCM (CU/AL)
Frequency 50 to 60 Hz
Operation temperature -22°F to 113°F (-30°C to 45°C)
Max torque L1, L2, Neutral: 120 in-lbf / Ground: 50 in-lbf
Dimensions 16" x 16" x 8"
*
(H" x W" x D")
Total weight 20 lb (9,07 kg)
*
*Approximative and can change without notice.
MAIN POWER SUPPLY
70A 80A 90A 100A 125A 150A 200A

CHARACTERISTICS

CONDITIONS FOR APPLICATION
The DCC-11 is an Energy Management System specially designed to
allow the connection of an EV Charger to be connected to a power source
without affecting load calculation.
INSTALLATIONS TYPES
- Group installation
- Wall installation
- Ceiling installation
MAIN POWER SUPPLY (CB)
The DCC-11-BOX can be powered by a 240/208V AC single phase source,
max 200A. The following options are offered by each DCC model:
MODELS BREAKER
V5
EV charger
DCC-11-30A
DCC-11-40A
DCC-11-50A
DCC-11-60A
Voltage and wiring
Terminals size
Frequency
Operation temperature -22°F to 113°F (-30°C to 45°C)
Max torque
Dimensions
*
(H" x W" x D")
Total weight
*
*Approximative and can change without notice.
MAIN POWER SUPPLY
60A 70A 80A 90A
30A
40A
SEE
DCC-9
50A
60A
240/208V AC single phase:
L1, L2, Neutral, Ground.
up to 300 MCM (CU/AL)
50 to 60 Hz
L1, L2, Neutral: 120 in-lbf / Ground: 50 in-lbf
Breaker terminals: 45 in-lbf
16" x 16" x 8"
23 lb (10,43 kg)
5
100A 125A 150A 200A
V5
