SPECIFICATIONS

DCC-9-BOX is a splitter box specifically designed to make a building's
electrical infrastructures fully ready for electric vehicles at the lowest
possible price.
For bundled installations, taller versions (BOX3 and BOX6) can house 3
or 6 DCC PCBs in order to maximise space usage.
MODELS DIMENSIONS*
(H" x W" x D")
DCC-9-BOX 12" x 12" x 7.5"
DCC-9-BOX-3R 14" x 13" x 8"
45" x 14" x 9"
DCC-9-BOX3
DCC-9-BOX6 78" x 14" x 9"
240/208V AC single phase: L1, L2,
Voltage and wiring
Neutral, Ground.
Terminals size up to 2/0
L1, L2, Neutral: 120 in-lbf
Max torque
Ground: 50 in-lbf
Certifications
*Approximative and can change without notice.
TOTAL WEIGHT*
11 lb (4,99 kg)
12 lb (5,44 kg)
40.5 lb (18,37 kg)
81 lb (36,74 kg)
(CU/AL)
V6

CHARACTERISTICS

CONDITIONS FOR APPLICATION
The DCC-9 is an Energy Management System specially designed to allow
the connection of an EV Charger to be connected to a power source
without affecting load calculation.
INSTALLATIONS TYPES
- Group installation
- Wall installation
- Ceiling installation
The DCC-9-BOX6 and DCC-9-BOX3 can also be installed vertically
on the floor.
MAIN POWER SUPPLY (CB)
The DCC-9-BOX can be powered by a 240/208V AC single phase source,
max 125A. The following options are offered by each DCC model:
MODELS
60A 70A
DCC-9-BOX
DCC-9-BOX-3R
DCC-9-BOX3
DCC-9-BOX6
MAIN POWER SUPPLY
80A 90A 100A 125A 150A 200A
SEE
DCC-11
5
