Summary of Contents for SAINT-GOBAIN NORTON clipper CDM 354
- Page 1 CDM 354 USER MANUAL Translation of the original instructions...
- Page 2 VERS.2023.03.09 CDM 354_MAN_EN...
- Page 3 EN 60745-1; EN 55014; EN 61000 Valid for machines with serial number from: 4503391636001 Storage location of technical documents: Saint-Gobain Abrasives 190, Bd. JF Kennedy 4930 BASCHARAGE, LUXEMBOURG This declaration of conformity loses its validity when the product is converted or modified without agreement.
- Page 4 Valid for machines with a serial number greater than: 4503391636001 Authorised Representative: SAINT-GOBAIN ABRASIVES Unicorn House • Unit 1, Amison Close Redhill Business Park • Stafford • England • ST16 1WB This declaration of conformity loses its validity when the product is converted or modified without agreement.
-
Page 5: Table Of Contents
VERS.2023.03.09 CDM 354_MAN_EN CDM 354 USER MANUAL CONTENTS 1 INTRODUCTION 2 BASIC SAFETY TIPS 2.1 Pictograms 2.2 Machine insert 2.3 Advice on prevention at certain operating phases Error! Bookmark not defined. 3 MACHINERY DESCRIPTION 3.1 Function 3.2 Mains voltage 3.3 Mounting on a drilling column 3.4 Gearbox 3.5 Training 3.6 Electronic protection... -
Page 6: Introduction
VERS.2023.03.09 CDM 354_MAN_EN 1 INTRODUCTION Foreword This manual is written for users of CDM354 core drilling motors . The manual contains information on the installation, use and maintenance of the CDM354 motor. This manual only applies to CDM354 coring motors. The type of motor is indicated on the nameplate placed on the machine. -
Page 7: Machine Insert
VERS.2023.03.09 CDM 354_MAN_EN Machine plate You can find important information on the following plate attached to your machine: Machine model Code of the machine Power Speed Acceptable current and frequency Max. diameter depending on the selected speed Serial number 2.3 Safety instructions for particular operating phases When using the machine, always respect the following safety instructions to avoid the risk of shock, injury and fire. - Page 8 VERS.2023.03.09 CDM 354_MAN_EN Wear appropriate work clothes Do not wear loose jewelry or clothing. They may get caught in moving parts. For outdoor work, rubber gloves and shoes with profiled soles are recommended. If you have long hair, wear a net. Use means of personal protection Use hard hat for protection against falling elements, gloves for protection against sharp elements, safety glasses for protection against stone chips and/or sparks.
-
Page 9: Machinery Description
VERS.2023.03.09 CDM 354_MAN_EN Make sure the work area is well lit. Pay attention to the location of cables, pipes and rebar in the work area. Do not use power tools in a humid environment (rain) or near flammable materials. Ensure the safety of the work area Secure tools and work pieces securely so they do not come loose. -
Page 10: Mounting On A Drilling Column
VERS.2023.03.09 CDM 354_MAN_EN The differential circuit breaker is a safety device which trips in the event of a leakage current of • maximum 10 mA. The under voltage release trips in the event of under voltage below 110 V • (So also when the plug is pulled out of the socket) •... -
Page 11: Overload Protection
VERS.2023.03.09 CDM 354_MAN_EN 3.8 Overload protection The CDM354 motor is equipped with 2 LEDs. When the motor is used overloaded, the orange LED lights up to warn the operator that the motor is overloaded. The operator must immediately lower the load. If the red LED lights up the motor stops immediately. -
Page 12: Noise Emission Statement
VERS.2023.03.09 CDM 354_MAN_EN In assessing the risks due to hand-arm vibrations, it is also necessary to take into • account, over a working day, the time of effective use of the machine at full speed; it is not uncommon to find that this effective use time is limited to 50% of the total working time, taking into account all the stops (breaks, fuel and water supplies, work preparation, movement of the machine , tool mounting, etc.). -
Page 13: Important Tips
The above-mentioned interventions, as well as all other electrotechnical repairs, are only reserved for a licensed professional (electrician). For repairs/replacements, only use original Saint-Gobain Abrasives SA parts. The electrical part must be checked regularly by a licensed professional electrician (about twice a year). -
Page 14: Guarantee
VERS.2023.03.09 CDM 354_MAN_EN 6 GUARANTEE The warranty period for the CDM354 core drilling machine is 24 months from the date of delivery, if no other conditions have been set at the time of purchase. The warranty rights must be established on presentation of the purchase invoice. The warranty includes the repair of defects, attributable to material or manufacturing defects. -
Page 15: After Sales Service
Spare parts for the engine can be ordered from the engine manufacturer or their dealer, which is often quicker and cheaper. This machine was manufactured by : Saint-Gobain Abrasives SA 190, boulevard JF Kennedy L-4930 BASCHARAGE Grand Duchy of Luxembourg. - Page 16 VERS.2023.03.09 CDM 354_MAN_EN...
