Introduction

Sticker Speaker is an accessorized Bluetooth speaker launched by MUZEN, adhering to the company's design philosophy of "Aesthetically pleasing, Great sound, User-friendly and Entertaining". We hope to bring you multiple, better and more interesting music applications.

Muzen Sticker Speaker produces different sound quality by combining the Bluetooth speaker with the contact surface, and the vibration of the speaker drives the contact surface (such as refrigerator/coffee machine/cabinet, etc.) to vibrate together. Therefore, after vibration with the contact surface, the sound quality of the speaker is related to the size and parts of the surface in contact. If the contact surface is not solid, or there are other moving vibrating parts, it is very likely to bring the noise that should not appear, then you need to make appropriate adjustments to ensure the best sound quality.

A Gentle Reminder:
Please read this product manual carefully before use if for better experience while using the product.

Packing List

S/N	Packing List
1	Speaker x 1
2	Product User Manual x 1

Device Operation Instruction

Power Button / Volume Control / Bluetooth Reset
Switch on / off: long press 3s
Volume up: rotate clockwise
Volume down: rotate counterclockwise
Play / Pause: short press once
Bluetooth reset: short press three times
(* *Note: Bluetooth is not connected or Bluetooth connection after 3 minutes of no play, the product automatically shut down.)
Bluetooth indicator
Blinking: Bluetooth is not connected
Steady on: Bluetooth is connected
Speaker: for music play
(* * Note: This part is a fragile part, please do not press this position hard)
Rubber pad
Charging indicator
Red light: charging
Green light: fully charged
TYPE-C charging port: Used to charge the device

Hardware Parameters

Product Model: MW-Q1
Product Size: 74mm x 53mm x 21.7mm
Product Net Weight: 45 ± 9g
Bluetooth: 5.3 version
Bluetooth connection distance: ≤ 10m
Speaker: 4Q 2W
Amplifier power: 2W
Battery: 3.7V/300mAh
Charging Port: TYPE-C
Charging Voltage: DC 5V 1A

Important Notes

For your safety, please read the following instructions carefully and comply with them:

The manufacturer reserves the right to modify or adjust the specifications and details of the product without notifying users.
Please use the product in a dry environment wherever possible.
The product should not be placed near or in contact with exposed sources of fire.
This product can be used normally with the ambient temperature of 0-45°C. Do not use it outside of this range.
Do not modify, repair or dismantle this product without authorization, otherwise, no after sales services available.
Note that if the battery is not replaced properly, it may explode. If necessary, please visit a professional service center. After replacing the battery, the product will not be covered by the warranty.

Warranty

For maintenance details, please visit www.muzenaudio.com or contact our local distributors.

Email: info@muzenaudio.com
Manufacturer: Shenzhen Airsmart Technology Co., Ltd.
Address: Unit 616,Ant's Union Start-up Accelerator, No.9 Keji Road, Science and Technology Park, Nanshan District, Shenzhen, China
