SANDENVENDO AMERICA INC
HOT FOOD DISPLAY
Operation Manual
Models:
HFD000008
HFDM00002, 3
HFDC00005, 6
1188858W ECN 58848
Table of Contents
Commitment to Safety............................2
Safety Warnings....................................3, 4
Installation Requirements........................5
Operation................................................7
Troubleshooting.....................................8
Cleaning...............................................9
Pan Stops, Rear Door Lock, Included
accessories..........................................10
Instructions.....................................11, 12
HFDHC9, 10, 11, 12, 13, 14
1
Advertisement
Table of Contents
Related Manuals for Vendo HFD000008
Summary of Contents for Vendo HFD000008
-
Page 1: Table Of Contents
SANDENVENDO AMERICA INC HOT FOOD DISPLAY Operation Manual Models: Table of Contents HFD000008 Commitment to Safety…….….……………..2 Safety Warnings…….……..……....3, 4 Installation Requirements..…….….………..5 Product Summary, End of Life Disposal…6 Operation……………………...………....7 Troubleshooting……………..………..……...8 HFDM00002, 3 Cleaning………………………………….…….9 Pan Stops, Rear Door Lock, Included accessories………………..………………….10 Optional Accessories and Installation Instructions……………………………..11, 12... -
Page 2: Commitment To Safety
SANDENVENDO AMERICA INC A COMMITMENT TO SAFETY SandenVendo is committed to safety in every aspect of our product design. SandenVendo is committed to alerting every user to the possible dangers involved in improper handling or maintenance of our equipment. The servicing of any electrical or mechanical device involves potential hazards, both to those servicing the equipment and to users of the equipment. -
Page 3: Safety Warnings
SANDENVENDO AMERICA INC SAFETY WARNINGS The HFD is for indoor use only. Do not use When unplugging, first turn off the power switch. Then pull the plug at the end of the near water or in condensing humidity. power cord, not by pulling the power cord, since the cord can be damaged, overheat, and cause a fire. - Page 4 SANDENVENDO AMERICA INC SAFETY WARNINGS (continued) To prevent injuries due to falling objects, Keep HFD out of direct sunlight and away liquid spills, electric shock or fire, do not from heat sources. place heavy objects or liquid-filled objects on top of the HFD. To prevent electric shock or fire, do not use volatile or flammable products in or near the HFD.
-
Page 5: Installation Requirements
SANDENVENDO AMERICA INC The lamps are an integral part of the food heating system. If a lamp is not illuminated, the temperatures may not be maintained for food safety. Therefore, replace nonworking lamps. INSTALLATION REQUIREMENTS The HFD must be connected to a dedicated 115V 15A (or greater) grounded circuit. -
Page 6: Product Summary, End Of Life Disposal
Mini HFD Mini HFD w/LEDs HFD w/LEDs High Capacity HFD Name HFD w/LEDs HFDHC0009 HFDC00005 HFDHC0010 Model HFDM00002 HFDM00003 HFD000008 HFDC00006 HFDHC0011 HFDHC0012 Approximate Internal 4.1 ft 6 ft 14 ft Volume, ft (liters) (116 liter) (170 liter) (396 liter) External Dimensions 24.9 x 19.7 x 27.6... -
Page 7: Operation
SANDENVENDO AMERICA INC OPERATION Display and Keypad Time Use left or right buttons to adjust shelf I/O button button temperature and timers down or up Upper left shelf (except HFDM) Upper right shelf Middle left shelf (except HFDM) Middle right shelf USB port Lower right shelf Lower left shelf... -
Page 8: Troubleshooting
2. Turn on the controller. The configuration will load in less than 5 seconds. 3. The display will show the configuration code (example: 001h) from the vendo.cfg file. 4. Pull the flash drive out of the controller (controller may remain on). -
Page 9: Cleaning
SANDENVENDO AMERICA INC CLEANING Prior to cleaning, ensure the HFD is off and allow the HFD to cool. Keep HFD clean for optimal performance. Do not place dirty pans on hot plate surfaces. Clean pans thoroughly prior to placing food on pans or use paper liner on pans. Keep area around unit clean and clear. -
Page 10: Accessories
SANDENVENDO AMERICA INC Included Accessories Pan Stop Install Pan Stops: HFDHC units, place each pan stop (part # 1242342 included in packaging) as shown to help prevent pans from hitting the front glass. For HFDHC units where the rear doors won’t be used, install rear door keep- closed bracket (included accessory). -
Page 11: Optional Accessories And Installation Instructions
SANDENVENDO AMERICA INC Optional Accessories Bag & Tong Holders Top Mount Shelf HFDHC: 1256238: Right Side HFDHC: 1246267 1256238-1: Left Side HFD & HFDC: 1268465 HFD & HFDC: 1268619: Right Side 1268619-1: Left Side Step 1: Remove Step 1: Place tray top front plastic on the top front of side glass bolt. - Page 12 SANDENVENDO AMERICA INC HFDC POP Kit 00003,4 Part Number: 1260456 See kit instructions for installation detail HFDHC POP Kit XXXX Part Number: 1261266 See kit instructions for installation detail HFDM00002 POP Kit Part Number: 1261479 See kit instructions for installation detail 1188858W ECN 58848...
-
Page 13: Hfdhc9
SANDENVENDO AMERICA INC HFDM00003 POP Kit Part Number: 1279473 See kit instructions for installation detail Hot Food Display Media Topper Display still images or video content and audio at the Hot Food Display. The HFD Media Topper features a 24-inch-class Full HD Ultra HDMI Digital Media player for USB Drives and SD Cards, and includes a remote control.
