Summary of Contents for GiBiDi DCF180DB

  • Page 1 DCF180DB - (AU02020) Fotocellule digitali ISTRUZIONI PER L’INSTALLAZIONE Digital photocells INSTRUCTIONS FOR INSTALLATIONS...
  • Page 2 DCF180DB 180° FIG. 1 12/24 NO/NC TEST NOT USED 12/24 Vac-dc DIP4 ON 12/24 Vac-dc 1 2 3 4 1 2 3 4 DIP1 OFF DIP2 OFF 1 2 3 4 1 2 3 4 L1 SIGNAL QUALITY pause pause...
  • Page 3 FIG. 2 Potenza segnale DIP4 ON Power signal 1 2 3 4 1 2 3 4 DIP1 OFF BATTERY DIP2 OFF BATTERY...
  • Page 4 TECHNICAL SPECIFICATIONS Model/Item DCF180DB / AU02020 Range 30 m (12 m, external) Signal Impulse signal, unmodulated Infrared frequency 100 Hz ÷ 1 Khz Relay power 0,5A 48Vac/dc TX: 2 x AAA 1,5V Power supply RX:12/24 V dc/ac RX: 35mA TX: 0,04mA÷ 0,12mA...
  • Page 5 FUNCTIONING The DCF180DB photocell has been designed mainly for use with sliding gates, which eliminates the need for a mobile frame. The device can also be used as a normal photocell in all cases where the transmitter cannot be wired. The receiver must be positioned so that it is not disturbed by other photocells.
  • Page 6 EN 301 489-1 V2.2.0; EN 301 489-3 V2.1.1; EN 300 220-2 V3.2.1; EN 62479:2010; EN 60950-1:2014; This declaration of conformity is issued under the sole responsibility of the manufacturer. Date: 03/04/20 The legal Representative Michele Prandi EU manufacturer declaration: The EU declaration is available at: http://conformity.gibidi.com...
  • Page 7 GI.BI.DI. S.r.l. Via Abetone Brennero, 177/B 46025 Poggio Rusco (MN) - ITALY Tel. +39.0386.52.20.11 Fax +39.0386.52.20.31 E-mail: info@gibidi.com Numero Verde: 800.290156...
