Summary of Contents for Apposite NETROPY 40G
- Page 1 ® ETROPY ARDWARE UIDE...
- Page 2 Marina Del Rey, CA 90292 USA 1.310.477.9955 info@apposite-tech.com www.apposite-tech.com Copyright ©2005-2024 Apposite Technologies LLC. All rights reserved. Apposite, Linktropy, and Netropy are registered trademarks of Apposite Technologies LLC. The Apposite logo and “WAN Emulation Made Easy” are trademarks of Apposite Technologies LLC. Part No. DOC-HG-40G-S14...
-
Page 3: Table Of Contents
8 Apposite Support ............................14 Appendix A: Specifications ..........................15 Appendix B: Regulatory ............................ 16 Federal Communications Commission Notice ..................16 Canadian Notice / Avis Canadien ......................16 CE Certification ............................16 Appendix C: Apposite End User License Agreement ..................17... -
Page 4: Overview
VERVIEW This Netropy 40G Hardware Guide describes the physical hardware of the Netropy 40G Network Emulator. The companion User’s Guide describes the installation, configuration, and operation of the Netropy network emulation functionality. A separate Quick Start Guide provides a walk- through for first time configuration. -
Page 5: Included Items
NCLUDED TEMS The Netropy 40G shipping carton contains the following items: Netropy 40G hardware unit Slide rail kit and rack ear brackets Netropy 40G Quick Start Guide AC power cord (U.S.) quantity 2 RS-232 DB9 serial cable... -
Page 6: Front And Rear Panels
RONT AND ANELS 3.1 Front Panel The front panel of the Netropy 40G contains: Power LED: Lit green when the unit is powered on. Power Button: Press the power button on the front panel to turn the device on or off. -
Page 7: Rear Panel
International customers may need to substitute a local power cord with a standard IEC C13 plug. The Netropy 40G handles AC power input from 100 to 240 V. If power is supplied to only one of the power inputs or if one of the power supplies fails, the system will sound an alarm. -
Page 8: Capacity Limitations
APACITY IMITATIONS The Netropy 40G can forward up to 40 Gbps of packets in each direction for an aggregate capacity of 80 Gbps. Each port can forward packets at a rate of 16 million packets per second (with 64 byte packets) and an aggregate limit of 32 million pps (with 64 byte packets). - Page 9 Frame Size (Jumbo Frames) Aggregate 1520 bytes 9220 bytes Throughput 1 Gbps >20 sec >20 sec 10 Gbps 5.3 sec >20 sec 40 Gbps 1.3 sec 8.1 sec Table 2: Maximum Round-Trip Latency for Jumbo Frames APACITY IMITATIONS...
-
Page 10: Slide Rail Installation
LIDE NSTALLATION 1. PREPARATION SLIDE RAIL COMPONENTS: 6mm Screws b. 6mm Flat Head Screws 1.2mm Flat Head Screws and Conical Washers d. Inner Fixed Chassis Rail (x2 pre-installed) e. Additional Chassis Rails with Locking Tab (x2) Outer Rail, Short Bracket (x2) g. - Page 11 2. Attach Additional Chassis Rails (Optional) For longer racks, attach an Additional Chassis Rail (E) to the left and right side of the unit using Flat Head Screws (B). For racks shorter than 31”, the Additional Chassis Rails if attached will extend out the back of the rack.
- Page 12 4. Installing the Unit into a Two Post Rack Attach a Short Bracket (H) to the middle of both Long Outer Rail Brackets (G) using 2 screws (A) on each. Secure the middle of the Outer Rail to your rack. Carefully slide the Inner Rails of the chassis all the way into the Outer Rails attached to the rack.
-
Page 13: Qsfp Interfaces
QSFP I NTERFACES The Netropy 40G has two QSFP 40 Gbps interfaces. The interfaces accept any standard 40 Gbps QSFP transceivers available from a variety of vendors or from Apposite. Through the use of a QSFP-to-SFP+ adapter (separately available from Apposite), the interfaces can also accept standard fiber and copper 10 Gbps SFP+ transceivers and 1 Gbps SFP transceivers. -
Page 14: Console Interface
ONSOLE NTERFACE Console access to the Netropy 40G is through the RS-232 interface on the rear panel labeled “ .” A DB9 cable is included with the unit to connect the device to a standard PC serial CONSOLE port. The pin-out for the DB9 connector is shown below:... -
Page 15: Apposite Support
Your e-mail address and phone number Installed firmware version A detailed description of the problem Do not attempt to fix any hardware problem yourself. The Netropy 40G contains no user serviceable parts. Opening the chassis voids the warranty. PPOSITE... -
Page 16: Appendix A: Specifications
A: S PPENDIX PECIFICATIONS Capacity Max. Emulation Rate 40 Gbps Max. Throughput 80 Gbps aggregate Max. Packet Rate 32 million packets per second aggregate (64 byte packets) 16 million packets per second in each direction (64 byte packets) Max. Frame Size 9 KB Interfaces Network... -
Page 17: Appendix B: Regulatory
B: R PPENDIX EGULATORY Federal Communications Commission Notice This equipment has been tested and verified to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 18: Appendix C: Apposite End User License Agreement
Apposite maintenance services, or (b) for any Product that is not a Legacy Product, the License Period, unless such Product has a perpetual license, in which case the Warranty Period shall be five (5) years from the date of purchase of the Product from Apposite unless extended by purchase of maintenance services. - Page 19 Customer Support Terms and Conditions, which is incorporated by reference into this Agreement. LIMITED WARRANTY. Apposite warrants that, for the duration of the Warranty Period, the Hardware will be free of any defects in materials and workmanship under normal use and the Software will perform substantially in accordance with the Documentation.
- Page 20 You may terminate it at any time by destroying all copies of the Software and Documentation in your possession. The licenses granted by Apposite herein will terminate immediately if you fail to comply with any term or condition of this Agreement. You agree on termination of the licenses to cease all use of the Software and Documentation.
- Page 21 ® Apposite Technologies LLC 4223 Glencoe Ave, Suite B121 Marina Del Rey, CA 90292 USA 1.310.477.9955 info@apposite-tech.com www.apposite-tech.com...
