DT Home-Control
Operation Manual
Modes of Operation
• Timed Mode
MNL-00049 [1]
Proprietary and Confidential
Page 1 of 19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Daavlin 1 Series

Summary of Contents for Daavlin 1 Series

  • Page 1 DT Home-Control Operation Manual Modes of Operation • Timed Mode MNL-00049 [1] Proprietary and Confidential Page 1 of 19...

  • Page 2: Table Of Contents

    Table of Contents Control Type ......................3 Indications for Use ..................... 3 Delivery and Inspection ..................3 Site Selection ...................... 4 4.1 Electrical Requirements ........................4 Unpacking and Assembly .................. 4 5.1 Swivel Stand ............................ 4 Lamp Inspection ....................4 6.1 Lamp Specification Guide ........................

  • Page 3: Control Type

    Upon delivery, inspect the box and its contents. If damage is discovered, save all packing materials and call Daavlin immediately to begin the claims process. If it’s not possible to inspect the unit before the driver leaves, we recommend that you write “Concealed damage possible.

  • Page 4: Site Selection

    All 1 Series devices are equipped with an onboard fuse. The fuse holder is a part of the power cord receptacle that is located on the lower left-hand side of the device. If an onboard fuse fails, call Daavlin’s service department to determine an appropriate replacement.

  • Page 5: Precautions And Warnings

    To protect the eyes during operation, the operator and anyone in view of the device must wear the provided UV blocking glasses or goggles designed to block 100% of all UVA and UVB light from the eye area when worn. Always use Daavlin approved eyewear. •...
  • Page 6 16.0 Specifications . If the device continues to malfunction cease operation and contact the Daavlin Service Department. • If necessary, operation of equipment may be terminated by disconnecting unit from AC mains.

  • Page 7: Operating Specifications

    Device is not to be used in MR environments that may include MRI, diathermy, electrocautery, or other high frequency equipment. • Do not treat if the lamps fail to ignite. Consult with doctor and/or contact Daavlin customer service. (See page 21) •...
  • Page 8 A warning label (Figure 2 Warning Label) is affixed to your Daavlin phototherapy device in a prominent and easily readable position. Please read the label carefully as it contains important safety information. Figure 2 Warning Label Figure 3 Identification Label The following table lists all of the symbols appearing on the device along with their meaning.

  • Page 9: General Instructions

    Note: A free printable treatment log is available for download at www.Daavlin.com. You will need to purchase lip balm and sunscreen with an SPF (Sun Protective Factor) of at least 30.

  • Page 10: How To Position Yourself

    Larger Area Treatment: (Choose the 9 inches position when starting your therapy). Position the 1 Series so that the lamps are perpendicular to the surface on which the device is standing on. Position the part of your body that you wish to treat nine (9) inches away from the lamps.

  • Page 11: Viewing Device Code For Flex Rx

    The Flex Rx exposure limiting system uses a “call and response” method. The 3-digit Device Code (Cxyz) is randomly generated by the controller and is necessary to generate a 4-digit Treatment Code using an algorithm controlled by Daavlin. Proprietary and Confidential. Printed copies will not be updated.

  • Page 12: Refill Flexrx

    Flex Rx Treatment code soon. 5. Per the Daavlin Flex Rx Algorithm, there are 1000 Device Codes (C000-C999), each having five (5) four-digit Flex Rx Treatment Codes (0000-9999) that set a predetermined amount of exposures to be allowed by the controller.

  • Page 13: Cleaning/Disinfection

    3 min 70% Isopropyl Alcohol Table 2 Daavlin Tested Cleaners 1. Thoroughly wipe down the surfaces and allow contact time listed in Table 2 Daavlin Tested Cleaners. 2. Allow to air dry and inspect for visible contaminants. 3. If contaminants remain repeat until no visible containments remain repeat steps 0 and 2.

  • Page 14: Lamp Replacement

    Lamp Specification Guide installed. Consult the 6.1 on page 4 for replacement lamp guidance and contact the Daavlin service department for a lamp replacement quote. They can be reached by dialing 1-800-322-8546 or via email at service@daavlin.com. 15.3.1 Lamp Replacement 1.
  • Page 15 Emissions Test Conformity EMC Environment Guide The 1 Series device is suitable for RF Emission Following Class B healthcare environment operation in CISPR 11 (EN 55011) hospitals and clinics Limits for harmonic current The 1 Series device is suitable for...
  • Page 16 Emissions Test IEC 60601 Test Level Actual Level Power frequency magnetic field immunity test following 50 Hz, 30 A/m 50 Hz, 30 A/m IEC 61000-4-8 30% Reduction for 500 30% Reduction for 500 mS at mS at 0 degrees, 0 degrees, Voltage dips and interruptions 100% Interruption for 10 100% Interruption for 10 mS...
  • Page 17 The device is intended for use in the electromagnetic environment specified below. The customer or the user of the device should assure that it is used in such an environment. IEC 60601 Compliance Immunity test Electromagnetic environment - guidance test level level a.

  • Page 18: Warranty

    17.4 Warranty Service During the warranty period, Daavlin will, at Daavlin’s option, repair or replace any Equipment or components that appear to have been defective in material or workmanship, with new or remanufactured materials. Daavlin may require the return of merchandise claimed to be defective for its examination and shall be the sole judge as to whether material is in fact Proprietary and Confidential.

  • Page 19: Disposal

    Daavlin. Even with Daavlin’s authorization, Daavlin shall not be responsible or liable for any such work (in or out of warranty). Daavlin reserves the right to bill for labor, expenses, and services for requested "warranty" service trips which result in work not covered by this Limited Warranty.
