- Page 1 Assembly Guide 48322-48422-48522 Holman Rancho Cordova, CA 95742 800-343-7486 InstallationSupport@Holman.com 20231013R4 DATE: ________________...
- Page 2 7/16” Socket and Wrench #2 Phillips Screwdriver Before You Begin • Read all instructions prior to assembling or installing any Holman product. • Instructions shown using a 27”H x 42”W Shelf. Instructions are the same for both 32”W and 52”W shelf units.
- Page 3 Instructions – 48322-48422-48522 Parts List Hardware For Technical Support Call: 800-343-7486, Monday-Friday, 7AM - 4 PM (PST). Page 2...
- Page 4 Instructions – 48322-48422-48522 Step 1 – Install Bottom Shelf • Shelves can be assembled with flanges pointing up to retain shelf contents, or flanges pointing down to allow the installation of drawer cabinets. The shelf side will have weld nuts on the rear of the shelf only.
- Page 5 Instructions – 48322-48422-48522 NOTE: The ProMaster requires the lowest shelf be raised by one set of lances to clear the wheelwell. Image on the left reflects most applications. The image on the right shows the bottom shelf for a Ram ProMaster.
- Page 6 Instructions – 48322-48422-48522 Step 3 – Install Left Side Panel • Place left side panel on top of shelf panels. • Press the shelf firmly against the lances in the shelf side as shown below. NOTE: Shelf must be properly squared or some holes may not align properly.
- Page 7 Instructions – 48322-48422-48522 Step 5 – Attach Back Panel • Attach back panel to shelf side panels using four 1/4” x 3/8” pan head screws in the orientation shown. Be sure to install back panel in the correct orientation, as shown.
