Kiloview CUBE X1 Quick Start Manual

Ndi high bandwidth+ndi, hx distribution system
Hide thumbs Also See for CUBE X1:
Table of Contents

Advertisement

Quick Links

Download this manual
CUBE X1
NDI High Bandwidth+NDI|HX
Distribution System
(V3.0)
Through this manual, you can learn:
Packing list
Device interfaces and functions
Device connections, login, and basic applications
Device upgrades and restore the factory settings
Before using this product, it is recommended that you read the guide carefully. To ensure your personal safety and avoid physical or
electrical damage to the device, please strictly follow the instructions of this guide to install and use it under the guidance of
professionals. Incorrect electrical connections or physical installation may cause permanent damage to the device and even threaten
personal safety.
As the product is continuously upgraded and updated, the product you purchased may have some changes compared to the content in
this manual. Please refer to the actual product inside the packaging box for the most accurate information.
Leading solution provider of IP-Based video transmission
Quick Start Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CUBE X1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kiloview CUBE X1

Summary of Contents for Kiloview CUBE X1

  • Page 1 Leading solution provider of IP-Based video transmission Quick Start Guide CUBE X1 NDI High Bandwidth+NDI|HX Distribution System (V3.0) Through this manual, you can learn: Packing list  Device interfaces and functions  Device connections, login, and basic applications  Device upgrades and restore the factory settings ...

  • Page 2: Packing List

    1 Packing List (1) Host Machine×1 (2) Power Adapter×2 (3) Warranty Card×1 (4) Quick Start Manual×1...

  • Page 3: Device Interfaces

    (12) 2*10G SFP+ Notes: The number keys correspond to the 16 signal sources input into CUBE X1. Select any NDI output channel on the touch  screen, and then press any number key to switch the NDI output to the NDI source corresponding to the number key.
  • Page 4 Notes: CUBE X1 primarily solves the problem that the NDI sources cannot be pulled by the devices at the same time, and the video source can be virtually output through CUBE X1. Cube X1 supports NDI High Bandwidth and NDI|HX input, compatible with any NDI output, either from any other software/hardware.

  • Page 5: Touch Screen - Settings

    5 Touch Screen - Settings After pressing the power button on the right side of the CUBE X1 panel, the device will enter the power-on status and the KILOVIEW logo will be displayed on the screen. Please wait patiently for the startup process...

  • Page 6: System Overview

    5.1 System Overview The first part on the touch screen is Dashboard. Click “Dashboard” to enter the system information page, which includes network status, system status, and other information.

  • Page 7: System Control

    5.2 System Control The second module of the touch screen is system control. Click “Control” to configure. This interface allows users to view the video of the current NDI input source, set playlist, preset templates, view, and switch the corresponding relationship between NDI input and output. Meanwhile, it also supports turning on/off the VU meter of all NDI input sources.
  • Page 8 Double-click the NDI video source to enter the window to preview this video and click the "Back " icon to return to the interface of multiple NDI input videos, click the screen video, the name and channel number of the NDI input source will be displayed above the video. Clicking again will hide this information. Up to 16 playlists and preset templates can be created, which can be switched by pressing the numeric buttons.

  • Page 9: System Settings

    5.3 System Settings The third part on the touch screen is System Settings. Clicking on "Settings" to enter the panel. You will need to enter the password to access (default password: 123456). Configurations such as power off, reboot, and restoring to factory settings can be done here. After accessing to the System Settings, you can set the network, SSH, HTTP port, system password and screen function.
  • Page 10  6 IP Address By clicking the touch screen of the CUBE X1, System Setting>Network setting, users can view the IP address obtained by DHCP or set the IP address manually. On this page, you can configure the IP address, Subnet, and Gateway for the network. The IP address will be used for WEB management after saving the settings.
  • Page 11 Method 1: Log in with Browser To log in, you need to input http://ServerIP:Port number/ in your browser and get access to the CUBE X1 management page. The default username and password for the device are both "admin," and the default login port number is 80.
  • Page 12 NDI resources, logs, etc. Notes: Network Status： Fiber: The name of the NIC (Network Interface Card) on the CUBE X1 server, different information will be displayed  based on different NIC. 65.81G /2.05T: Total upstream and downstream traffic of the current NIC.

  • Page 13: Control Panel

    8.2 Control Panel On the left side of the management page, click "Control Panels" to enter the Panel Settings, users can add and manage NDI input and NDI output. Step 1：Adding NDI Video Sources After clicking the "Panel" button for NDI inputs in the panel, a dialogue box for adding NDI sources will be prompted.
  • Page 14 Step 2：Creating NDI Outputs Users can create NDI virtual outputs and select the output NDI video sources by selecting the NDI input sources or playlist, and CUBE X1 also supports a single NDI source input, then output with multiple channels.
  • Page 15 Step 3: Creating Input-Output Matrix Use the "Cross-point" mode on the panel to create the matrix between NDI inputs and outputs. The blue block indicates that the corresponding NDI input is outputting from the corresponding NDI output channel. The "IO Panel" is a different display mode, and all operations have the same effect as the "Cross-point". e.g.: If you click Output1, you will see the first NDI source being highlighted in green, which indicating that this NDI video source is being output from Output1.
  • Page 16 8.3 Playlist On the left side of the management page, by clicking Playlist > Add playlist, you can customize the content of playlist and set the NDI source of playlist, duration, and other information. Meanwhile, NDI input and NDI output matrix can be configured in the panel, the panel provides the option to switch between the Cross-point and IO panels for configuration.
  • Page 17 Open the Multiview settings page and find the NDI output channels from CUBE X1 in the discovery list. Note: NDI stream name rule of CUBE X1 Output: CUBE X1 (dst-channel name), the channel name refers to the NDI channel name when the user "Create NDI output".

  • Page 18: Firmware Upgrade

    10 Firmware Upgrade 10.1 Download the Upgrade Firmware Kiloview will continuously provide firmware updates for CUBE X1 to add new features, fix bugs, and improve performance. Please visit： https://www.kiloview.com/en/support/download/ In the filter list，select “NDI” > “CUBE X1”and find the latest firmware download under the "Software" tab.

  • Page 19: Restore Factory Settings

    If the device cannot work due to incorrect parameter configuration, you can try to restore the factory setting. This can be done via the touch screen on the front panel of the CUBE X1, System Settings>Restore. Note: After a factory reset, the following parameters will be changed to the default values: The login user "admin"...
