- Page 1 USER MANUAL - Reel Mower...
-
Page 3: Table Of Contents
Table of Contents Table of Contents Safety Instructions Basic Information Contents of Package General Safety Instructions for Walk-behind Reel Mower Technical Data Product Description / Explanations Commissioning Maintenance Acknowledgements Troubleshooting Warranty Information Accessories and Manufacturer Information Declaration of Conformity Product description and use Technical specifications Explanations to Figures 1 and 2 Installation of regenerative cartridges... -
Page 4: Safety Instructions
Safety Instructions Please read this Original User Manual from the first to the last page. Warnings placed on the machine: WARNING! READ THE USER DANGER - FLYING KEEP YOUR ARMS MANUAL! OBJECTS! AND FEET AWAY FROM THE BLADES DO NOT LIFT LOCKING SCREW KEEP BYSTANDERS MAGNET... -
Page 5: Basic Information
The Swardman A 45S and A 55S reel mowers are exclusively designed for mowing lawns in private gardens and gardens around the house that have an area less than 1,400 m2 or where usage does not exceed 100 running hours per year. -
Page 6: Contents Of Package
Contents of Package Contents of Package 1. Lawn mower 2. Grass box 3. Tools 4. Charger 5. User manual 6. Quick start instructions Kreslil Materiál Polotovar SWARDMAN INDEX ZMĚNA DATUM PODPI Hmotnost Vytvořeno Měřítko 07.12.2017 Swardman vykres.idw User Manual... -
Page 7: General Safety Instructions For Walk-Behind Reel Mower
• The lawn mower is designed for mowing lawns in private gardens and gardens around houses that have an area less than 1,400 m2 or where usage does not exceed 100 running hours per year. • The machine must not be equipped with any additional accessories not authorised by Swardman. Failure to observe this instruction may void the warranty. - Page 8 • Do not clean the mower with running water or a pressure washer. • For safety and reliability reasons, use only original Swardman parts. • Make sure that the ambient temperature of the storage area will not drop below 10°C (50°F) and will not exceed 50°C (125°F).
-
Page 9: Technical Data
Technical Data Reel mower Electra 45 Electra 55 Order number A45 S A55 S Maximum operating speed (kmph Cutting width (cm/inch) 44.5 (18”) 54.5 (22”) Mowing height (mm/inch) 4 – 45 (0.15“-1.8“) 4 – 45 (0.15“-1.8“) Number of cuts per meter (6 blade reel) -
Page 10: Product Description / Explanations
Control lever for mowing height adjusting Side cover of timing gears Figure 2 Handlebar position adjusting Power connector Main switch Mowing height locking screw Rear roller with differential Kreslil Materiál Polotovar SWARDMAN INDEX ZMĚNA DATUM PODPIS Hmotnost Vytvořeno Měřítko 07.12.2017 Swardman vykres.idw User Manual... - Page 11 LED 3 LED 2 LED 1 SPEED MENU Designed by Checked by Approved by Date Date SWARDMAN 09.01.2018 Edition Sheet 1 / 1 Speed decreasing button Data cable Speed increasing button Data cable socket Indication of battery charging condition and adjustment of advanced functions “OK”...
-
Page 12: Commissioning
Hmotnost Vytvořeno Měřítko 07.12.2017 Edition Sheet Swardman vykres.idw 1 / 1 1. Insert the handlebar profile into the 2. Connect the data cable , Fig. 6, protruding mower bracket, adjust to the required from the handlebar bracket, to the socket position and fix the position with screws. - Page 13 Commissioning Starting the Machine 1. Turn on the main safety switch by pulling it out 2. Push the OK button 3. LEDs on handlebar come on. 4. Push the LOCK button , the fifth LED flashes. While LED is flashing, lift the right lever within 1.5 seconds. The reel starts turning.
-
Page 14: Maintenance
Maintenance Advanced Functions of Keyboard Control Cruise Control Regeneration Mode • Lets you control the mower with only one lever • Can be used when working with regenerative • If the machine is travelling and the reel is rotating, cartridges push the R button to turn on the cruise control •... -
Page 15: Acknowledgements
6. Make sure that the ambient temperature of the storage area will not drop below 10°C (50°F). Acknowledgements Thank you for choosing the Swardman reel mower. We believe that with proper care it will serve you for a long time and your lawn will be your pride and joy. -
Page 16: Troubleshooting
Connection between the mower Make sure that the data cable is connected correctly. sound comes from the and handlebars is lost If the problem persists, contact your Swardman dealer. –body of the mower) The mower switches off and beeps (the Critical battery condition Charge the battery. -
Page 17: Warranty Information
To ensure proper functioning, it is recommended to have the reel sharpened at the authorised Swardman service department at least once a year. If necessary, always use the Swardman original spare parts. The warranty does not cover a damage resulting from using spare parts not manufactured or approved by Swardman. -
Page 18: Accessories And Manufacturer Information
ANTRACIT RAL 9016 RAL 3011 RAL 2009 RAL 3020 RAL 5015 RAL 6018 Optional Manufacturer Information Swardman, s.r.o. Šardice 862 696 13 Šardice Czech Republic www.swardman.com E: info@swardman.com Service T: (+1) 754-213-2821 Service T2: +420 774 365 599 User Manual... -
Page 19: Declaration Of Conformity
Declaration of Conformity User Manual... - Page 20 Declaration of Conformity User Manual...
- Page 21 USER MANUAL regenerative cartridges verticutter scarifier rotary cartridge cartridge brush...
-
Page 22: Product Description And Use
The stainless steel springs of the scarifier are subject to normal wear and should be replaced with new ones when worn and not functioning. Spare parts are available in the e-shop at www.swardman.com. Astroturf cleaner will clean your artifical grass from leaves, needles, little rocks and other small objects. It is used the same way as scarifier cartridge. -
Page 23: Technical Specifications
Regenerative cartridges - Product description and use Rotary brush The rotary brush is used for the application of sand and material, which usually follows the aeration. The sand can also be incorporated into a lawn that has not been aerated, although the resulting effect is poorer than on a previously aerated lawn. -
Page 24: Explanations To Figures 1 And 2
Explanations to Figures 1 and 2 Fig. No. 1 - Swardman Edwin Designed by Checked by Approved by Date Date Designed by Checked by Approved by Date Date Swardman 15.11.2018 Swardman 15.11.2018 Edition Sheet Edition Sheet 1 / 1 1 / 1 Fig. -
Page 25: Installation Of Regenerative Cartridges
Installation of regenerative cartridges 1. Loosen the mowing height lock screw on the right side of the machine 2. Use the height setting lever to set the mowing height to maximum 3. Unscrew the bolts securing the side cover and remove the side cover of the machine. 4. -
Page 26: Maintenance
Acknowledgements Thank you for purchasing a Swardman product. We believe that with proper care it will serve you for a long time and your lawn will be your pride and joy. Our team is always ready to advise you on how to correctly use this machine. If you have any questions, please do not hesitate to contact us. - Page 28 Swardman, s.r.o. Šardice 862 696 13 Šardice www.swardman.com Czech Republic...
