Summary of Contents for SWARDMAN EDWIN 2.0
- Page 1 USER MANUAL - Cylinder Lawn Mower...
- Page 2 Lawn care should primarily be fun. I am delighted that you have chosen our Swardman mower. We developed it with love to beautiful, healthy and precisely cut lawns. I believe that Swardman cylinder mower will signifi cantly contribute to making your lawn your pride and to bringing joy for everyone around you.
-
Page 3: Table Of Contents
Table of Contents Table of Contents Safety Instructions Basic Information Contents of Package General Safety Instructions for Hand-Held Cylinder Lawn Mower Technical Data Product Description / Explanations Commissioning Maintenance Acknowledgements Troubleshooting Warranty Information Declaration of Conformity Accessories and Manufacturer Information User Manual | Eff... -
Page 4: Safety Instructions
Safety Instructions Please read the User Manual from the first to the last page. Warnings placed on the machine: WARNING! READ THE USER DANGER - FLYING KEEP YOUR ARMS MANUAL! OBJECTS! AND FEET AWAY FROM THE BLADES DO NOT LIFT LOCKING SCREW KEEP BYSTANDERS MAGNET... -
Page 5: Basic Information
The Swardman E 45S and E 55S model cylinder lawn mowers are exclusively designed for mowing lawns in private gardens and gardens around the house having the area less than 2,000 m2 or for their being in operation for 100 running hours per year. -
Page 6: Contents Of Package
Contents of Package Contents of Package 1. Lawn mower 2. Grass box 3. Tools 4. Oil (2 x 0.4 l) 5. Oil aspirator 6. User Manual 7. Kawasaki engine user manual 8. Quick Start Instructions User Manual... -
Page 7: General Safety Instructions For Hand-Held Cylinder Lawn Mower
• The lawn mower is designed for mowing lawns in private gardens and gardens around houses having the area less than 2,000 m2 or for its being in operation for 100 running hours per year. • The machine must not be equipped with any additional accessories not authorised by Swardman. Failure to observe this instruction may void the warranty. -
Page 8: Maintenance And Storage
• Do not clean the mower with running water or a pressure washer. • In case you need to drain the fuel tank, always do it outdoor and use a suitable container. • For safety and reliability reasons, use only original Swardman parts. User Manual... -
Page 9: Technical Data
Technical Data Cylinder lawn mower Edwin 45 Edwin 55 Order number E45S E55S Cylinder displacement (cm3) Fuel tank capacity (l) Fuel Unleaded petrol w. octane rating 98 or higher Oil tank capacity (l) 0.46 0.46 Oil type SAE 30 SAE 30 Rated power 1.9 kW (2.6 HP) 1.9 kW (2.6 HP) -
Page 10: Product Description / Explanations
Product Description Figure 1 Grass box Safety lock of cylinder Handlebar height Engine Handlebar body Setting control lever Fuel tank cap (B) Drive control lever for mowing height Engine exhaust Control lever for mowing blades Quick-acting bolt Throttle lever Handlebar body position adjusting Mowing height indicator Figure 2 Oil tank cap (A+B) - Page 11 Product Description Figure 3 Fuel inlet closure (C) Air fi lter Choke control lever (E) Spark-plug connector Starter cord (F) Throttle on engine Engine start/stop button (D) Mowing height locking screw Figure 4 Cylinder cable screw counternut Cylinder cable screw Drive cable screw counternut Drive cable screw Cylinder belt...
-
Page 12: Commissioning
Commissioning Assembling the Lawn Mower Take the mower out of the box. The best way is to carefully cut the box from its front face and push the mower out. Do not ever use the handle on the mowing cartridge for lifting the mower or its transport. 1. -
Page 13: Emptying The Grass Box
Commissioning Starting the Engine (For more detail information follow engine manual) 1. Before starting the engine for the very first time, pour oil, which is included in the package (oil SAE 30 - can No. 1), into the yellow plug hole (front and rear holes are identical) (A or B). -
Page 14: Maintenance
You can change the filter by unscrewing the air filter cover , opening it and removing the filter and pre-filter. You can order the original filter and pre-filter in the Swardman e-shop in the Service Section. User Manual... -
Page 15: Acknowledgements
6. Drain all the petrol from the carburettor, start the engine and let it run until all the fuel is consumed. Acknowledgements Thank you for choosing the Swardman cylinder lawn mower. We believe that with proper care it will serve you for a long time and your lawn will be your pride and joy. -
Page 16: Troubleshooting
Uneven tension of the transmission belt engine not running, the forward for longer distances, start the rear roller jams engine. If the above troubleshooting procedures fail to solve problems, contact Swardman at www.swardman.com in „contact“ section. User Manual... -
Page 17: Warranty Information
To ensure proper functioning, it is recommended to have the cylinder sharpened at the authorised Swardman service department at least once a year. If necessary, always use the Swardman original spare parts. The warranty does not cover a damage resulting from using spare parts not manufactured or approved by Swardman. -
Page 18: Declaration Of Conformity
Declaration of Conformity User Manual... -
Page 19: Accessories And Manufacturer Information
Wheels for taller grass LED spotlights removal Colours and materials ANTRACIT RAL 3011 RAL 3020 RAL 5015 RAL 6018 Optional Manufacturer Information Swardman, s.r.o. Pod Svahem 1582/12 CZ14700 Praha 4 Czech Republic www.swardman.com E: info@swardman.com Service T: +420 774 365 599 User Manual... - Page 20 +420 608 272 722 Swardman, s.r.o. Pod Svahem 1582/12 info@swardman.com 147 00 Praha Czech Republic www.swardman.com...
