  • Page 1 Gruvlok Roll Groover ® 1007 & 3007 Manual...
  • Page 2 - pipe to pipe and people to people. We've always been dedicated to building connections that last. As ASC Engineered Solutions, we are ready to make those connections stronger than ever by focusing as much on how we serve our customers as on the products we provide.
  • Page 3: Important Safety Notice

    Troubleshooting 22 Important Safety Notice Carefully read and understand instructions before assembling and operating the Groover(s). Become thoroughly familiar with the Groover operation, usage and possible hazards specific to the Groover(s). Gruvlok Roll Groover 1007 & 3007 Manual | asc-es.com ®...
  • Page 4: Safety Instructions

    9. Tool and Ridgid 300 Power Drive must be mounted to the floor for proper operation. 100' Extension cord length greater than 100 Feet is not recommended. *“RIDGID” is a registered trade mark of Emerson Electric Company. Gruvlok Roll Groover 1007 & 3007 Manual | asc-es.com ®...
  • Page 5 Model 1007/3007 Steel Pipe Grooving Times (Minutes: Seconds) Pipe Size (In./DN(mm))/Max Steel Pipe Wall Thickness ⁄ 0:20 0:20 0:25 0:30 1:00 1:20 1:35 1:50 2:20 2:40 3:00 Gruvlok Roll Groover 1007 & 3007 Manual | asc-es.com ®...
  • Page 6 (¼" shank padlock). comfortable position during groover operation ( " wrench). Gruvlok Roll Groover 1007 & 3007 Manual | asc-es.com ®...
  • Page 7 " wrench). receiving socket. Tighten the retaining bolt on the groover base. Repeat for the other leg ( " wrench). *“RIDGID” is a registered trade mark of Emerson Electric Company. Gruvlok Roll Groover 1007 & 3007 Manual | asc-es.com ®...
  • Page 8 Groover. Looking at the front of the Groover, the pipe stand should be positioned to angle the tube approximately 0° to ¼° downward, away from the front of the groover and ¼° to the left side at the Groover. See figures above. Gruvlok Roll Groover 1007 & 3007 Manual | asc-es.com ®...
  • Page 9 0° to ¼° downward, away from the front of the groover and ¼° to the left side at the Groover. See figures above. Gruvlok Roll Groover 1007 & 3007 Manual | asc-es.com ®...
  • Page 10 Turn the Knurled Stop to snug against the surface of the groove diameter gauge. Release the pump pressure by turning the 8" K, L, M, DWV pump release valve counterclockwise and remove the groove diameter gauge. Gruvlok Roll Groover 1007 & 3007 Manual | asc-es.com ®...
  • Page 11 If the groove diameter is small (i.e. deep groove depth), put an unfinished end into the Groover and complete the groove. Recheck the groove diameter for conformance to grooving specifications *“RIDGID” is a registered trade mark of Emerson Electric Company. Gruvlok Roll Groover 1007 & 3007 Manual | asc-es.com ®...
  • Page 12 Groover and complete the groove. 6" 1,500 1,100 Recheck the groove diameter for conformance to grooving specifications. 8" 2,000 1,600 1,000 *“RIDGID” is a registered trade mark of Emerson Electric Company. Gruvlok Roll Groover 1007 & 3007 Manual | asc-es.com ®...
  • Page 13 14"-16" roll removal), raise the roll out of the grooving head. Release the foot switch to allow the pipe to stop rotation. *“RIDGID” is a registered trade mark of Emerson Electric Company. Gruvlok Roll Groover 1007 & 3007 Manual | asc-es.com ®...
  • Page 14 DO NOT FORCE TOP SHAFT. When properly aligned, the top shaft will slide in with little effort. *“RIDGID” is a registered trade mark of Emerson Electric Company. Gruvlok Roll Groover 1007 & 3007 Manual | asc-es.com ®...
  • Page 15: Replacement Parts

    The fluid level should come to the bottom edge of the filler hole when the pump is level and resting horizontally on its base. Mobil DTE 24 hydraulic oil or its ISO 32 equivalent should be used. Gruvlok Roll Groover 1007 & 3007 Manual | asc-es.com ®...
  • Page 16 7 Cap Screw, ¼"-20, L= 3⁄8" GL11767 8"-12" Steel GL11117 8 Safety Mesh GL11313 14"-16" Steel (OPT) GL11335 9 Stop Plate Assembly GL11467 2"- 8" CTS Copper System (OPT) GL13799 Gruvlok Roll Groover 1007 & 3007 Manual | asc-es.com ®...
  • Page 17 10 Lockwasher, ½" ID GL11197 2 Hex Bolt, ⁄ "-11, L= 1½" GL11091 11 Hex Nut, ½"-13 GL11198 3 Hex Nut, ⁄ "-11 GL11313 12 Shaft Safety Cover GL11200 4 Leg Weldment GL11161 Gruvlok Roll Groover 1007 & 3007 Manual | asc-es.com ®...
  • Page 18 GL11074 1C Cap Screw, "-20, L= " GL11230 1D Cap Screw, "-20, L= ⁄ " GL11093 6 Upper Leg Weldment GL11145 1E Hydraulic Pressure Gauge GL11084 7 Foot-Leg Sub-Assembly GL11147 Gruvlok Roll Groover 1007 & 3007 Manual | asc-es.com ®...
  • Page 19 1C Shoulder Bolt, " GL11107 1D Guide Roll Guard GL11304 1E Cap Screw, "-20, L= " GL 11230 1F Flat Head Screw, "-20, L= " GL11108 1G Hex Nut, " GL11198 Gruvlok Roll Groover 1007 & 3007 Manual | asc-es.com ®...
  • Page 20: Roll Groove Specifications

    ID prior to roll grooving. Failure to do so may Notes: result in damage to the roll grooving machine and VdS - Roll Grooving Approval Specifications, see the Technical Data/Install Instructions section on ASC Engineered Solutions' web unacceptable roll grooves may be produced. site - www.asc-es.com “A”...
  • Page 21 202.16 -0.51 208.8 COLUMN 7 - DWV (Drain, Waste and Vent Piping) per ASTM B306. COLUMN 8 - Maximum flare diameter is the OD at the most extreme tubing diameter. Gruvlok Roll Groover 1007 & 3007 Manual | asc-es.com ®...
  • Page 22 ® ® With headquarters in Oak Brook, IL, ASC also has ISO 9001:2015 certified production With headquarters in Oak Brook, IL, ASC also has ISO 9001:2015 certified production With headquarters in Oak Brook, IL, ASC also has ISO 9001:2015 certified production With headquarters in Oak Brook, IL, ASC also has ISO 9001:2015 certified production facilities in PA, TN, IL, TX, AL, LA, KS, and RI.
