- Page 1 SPINNER I Product Manual Original instructions SmartLoad 25 kW with Outdoor Heat Exchanger BN 546435C0300 BN 546435C0301 products.spinner-group.com...
-
Page 2: Table Of Contents
Improper use ............................3 Qualifications of personnel ........................3 Safety signs and symbols ........................4 Signal words for hazard seriousness ....................... 4 Grouped safety messages for SPINNER broadcast products ..............5 Product identification ..........................7 Delivery content ............................7 Function ..............................8 General .............................. -
Page 3: Safety
1.1 About this product documentation The Spinner group makes every effort to keep the safety standard of our products up to date to be able to offer our customers the highest possible degree of safety. Our products are designed and tested in accordance with the relevant safety standards. -
Page 4: Safety Signs And Symbols
The use of signal words in connection with unrelated products or documentation can result in misinterpretation and thus contribute to personal injury or material damage. Data subject to change without notice │ 10086219│ Issue B│ 2023-09-28 4 / 27 www.spinner-group.com... -
Page 5: Grouped Safety Messages For Spinner Broadcast Products
(allergens) such as nickel cannot be generally excluded. If you develop an allergic reaction (such as a skin rash, frequent sneezing, red eyes or respiratory difficulties) when using a SPINNER product, consult a physician immediately to determine the cause and to prevent health problems or stress. - Page 6 Observe the section safety messages and in particular chapter 1 "Safety" of this product manual. Failure to comply could result in death or serious injury. • Do not modify the product and use only spare parts tested and approved by SPINNER. Failure to comply could result in death or serious injury. Disposal •...
-
Page 7: Product Identification
Product identification The SPINNER SmartLoad BN 546435C0300 or 546435C0301 have a type plate on the indoor unit containing the following information for product identification: Delivery content The scope of delivery includes the following items: SmartLoad indoor unit Radiator fan outdoor unit (external heat exchanger) 1”... -
Page 8: Function
For an updated copy of the material data sheet refer to the link or QR code below: https://products.spinner-group.com/AntifrogenN External heat exchanger A radiator fan is used for re-cooling of the heat sink in the external heat exchanger. -
Page 9: Interlock Loop
60 V DC. The power supply must be fully compliant with the ES1 type requirements. The circuit has to be limited externally to 1 A. Data subject to change without notice │ 10086219│ Issue B│ 2023-09-28 9 / 27 www.spinner-group.com... -
Page 10: Operating And Display Elements
Do not remove any connector protection cap until immediately prior to installation to avoid formation of dust and scratches on sensitive RF contact surfaces. Environmental conditions for storage refer to attached data sheet TD-00060 Data subject to change without notice │ 10086219│ Issue B│ 2023-09-28 10 / 27 www.spinner-group.com... -
Page 11: Transportation
1 "Safety" of this product manual. Only electrically skilled persons should install SPINNER SmartLoads in accordance with the national safety and accident prevention regulations. Failure to observe could result in death or serious injury. -
Page 12: Mechanical Installation
From the automatic vents install the hoses monotonously falling without any upturns to both units. (all dimensions in millimeter) Data subject to change without notice │ 10086219│ Issue B│ 2023-09-28 12 / 27 www.spinner-group.com... - Page 13 70 kg. NOTICE Ensure unobstructed air circulation to avoid overheating. Free space on the suction side is required. Data subject to change without notice │ 10086219│ Issue B│ 2023-09-28 13 / 27 www.spinner-group.com...
- Page 14 • The automatic vents must be mounted at the highest point of the cooling circuit, at least one each in flow and return. When laying hoses with several peaks, a valve must be fitted at each peak. Data subject to change without notice │ 10086219│ Issue B│ 2023-09-28 14 / 27 www.spinner-group.com...
-
Page 15: Electrical Installation
180 degrees to change the position of the cable inlet. The pin assignment is given in the circuit diagram 10085335 for BN 546435C0300 resp. 10085351 for BN 546435C0301. Data subject to change without notice │ 10086219│ Issue B│ 2023-09-28 15 / 27 www.spinner-group.com... - Page 16 • Check functioning of the interlock loop by turning the main switch (S1) into the off position. NOTICE We recommend placing lightning rods close to the external heat exchanger to ensure lightning protection. Data subject to change without notice │ 10086219│ Issue B│ 2023-09-28 16 / 27 www.spinner-group.com...
-
Page 17: Filling Of The Coolant Circuit
“Accessories”. If the filling pump set is not available, the included nozzle adaptor to 13 mm hose can be used to an existing filling set. NOTICE Use only the coolant ANTIFROGEN N, SPINNER BN 39463A (20 l canister), 2 pcs required. •... -
Page 18: Commissioning And Normal Operation
1 "Safety" of this product manual. Only electrically skilled persons may commission and operate SPINNER SmartLoads in accordance with the national safety and accident prevention regulations. Failure to observe could result in death or serious injury. -
Page 19: Maintenance
Check the coolant level in the collecting vessel, the coolant pressure and the coolant circuit for leakage daily, if the coolant gauge pressure is within the nominal range (0.75 to 1.1 bar) and no reason for the leakage can be found. Contact the SPINNER service in case of permanently increased coolant drain. -
Page 20: Plc Clock Time Setting
1 "Safety" of this product manual. Only electrically skilled persons may open the control box of SPINNER SmartLoads and set the PLC clock time in accordance with the national safety and accident prevention regulations. - Page 21 Press the pump and radiator fan button S2 on the back of the control cabinet for two minutes. • Wait for 3 minutes to allow air bubbles to collect. Data subject to change without notice │ 10086219│ Issue B│ 2023-09-28 21 / 27 www.spinner-group.com...
-
Page 22: Checking Glycol Concentration
1 "Safety" of this product manual. Observe the material data sheet of the coolant. Only qualified personnel may check the glycol concentration of SPINNER SmartLoads in accordance with the national safety and accident prevention regulations. Failure to observe could result in death or serious injury. -
Page 23: Coolant Exchange
1 "Safety" of this product manual. Observe the material data sheet of the coolant. Only qualified personnel may correct the coolant level of SPINNER SmartLoads in accordance with the national safety and accident prevention regulations. Failure to observe could result in death or serious injury. -
Page 24: Warranty
Open venting screw of the external heat exchanger. Residual quantities may remain in the cooling circuit. 2. Fill in new coolant. Required coolant: ANTIFROGEN N, SPINNER BN 39463A (20 l canister), 2 pcs required. • Close venting screw of the external heat exchanger. -
Page 25: Demounting
1 "Safety" of this product manual. Only electrically skilled persons may demount SPINNER SmartLoads in accordance with the national safety and accident prevention regulations. Failure to observe could result in death or serious injury. -
Page 26: Empty The Cooling Circuit
The user is responsible for disposing of the SmartLoad in accordance with the national waste disposal regulations. Improper disassembly or disposal may be hazardous. Observe the material data sheet of the coolant. Please contact SPINNER in advance, before returning the SmartLoad for disposal. Spare Parts Designation Order-No. -
Page 27: Contacts
Contacts SPINNER GmbH • Headquarters Erzgiessereistr. 33 80335 München Germany tel.: +49 89 12601-0 info@spinner-group.com www.spinner-group.com SPINNER Telecommunication Devices Co., Ltd. 351 Lian Yang Road Songjiang Industrial Zone Shanghai 201613 P.R. China tel.: +86 21 577 45377 info-china@spinner-group.com Data subject to change without notice │ 10086219│ Issue B│ 2023-09-28 27 / 27 www.spinner-group.com...
