National Public Seating 84 Series Assembly Instructions

PARTS
"T" Bars x2
A
Crossbeams w/chair hangers x2
B
Base Crossbeam x1
C
ASSEMBLY TIPS
All assembly should be done on a clean surface, such as carpet
or the like. Assembly is easy and should take no more than 10 minutes.
ASSEMBLING THE UNIT
Make sure that there are NO missing or
1
damaged parts.
While holding up one of the side
2
"T" Bars , bolt Crossbeam
A
middle set of holes.
NOTE: This set of holes has three holes.
Use the two lower holes.
Take the other side "T" Bar
3
to Crossbeam
NOTE: This set of holes has three holes.
Use the two lower holes.
Take the Crossbeam
4
top sets of holes on both side "T" Bars
Finally, bolt Crossbeam
5
bottom sets of holes on both side
"T" Bars .
A
Ensure that all Bolts are fastened tightly.
Dolly 84 is compatible with the following NPS chairs: 50 Series, 200 Series, 300 Series, 800 Series, 1200 Series, 1300 Series,
2200 Series, 2300 Series.
Double check all Bolts to be tightened securely before use. Check all Bolts periodically.
Failure to completely tighten the Bolts may result in tipping and possible injury!
Dear Customer, Thank you for your purchase. Although extreme care goes into manufacturing & packaging of this product, mistakes are possible.
If you encounter any missing parts or di culty in assembly, please contact our customer service Toll Free at 1-800-261-4112 or
info@nationalpublicseating.com for courteous & immediate resolution to your problem.
Page 1 of 2
ASSEMBLY INSTRUCTIONS
84 SERIES DOLLY
into the
B
, and bolt it
A
in the middle set of holes.
B
, and bolt it to the
B
, into the
C
Congratulations, your Dolly is now assembled and ready to be used!
www.nationalpublicseating.com
HARDWARE INCLUDED
Bolts Nuts x12
x12
4
A
2
5
.
A
RECOMMENDED TOOLS
Drill Socket Open End
Driver
OPTIONAL EXT-8
See Page 2 for assembling unit
with Extender Bars.
B
B
C
Wrench
4
A
3
5
1-800-261-4112
