User Manual
R e ad t he S af et y I n s t ru ct io ns b ef o re us in g yo u r e yew ear!
Welcome to the world of 16:9 widescreen viewing on the go! Your Vuzix™
iWear ® AV310 Widescreen Video Eyewear delivers extraordinary high
quality 2D and 3D video in your own personal, widescreen portable movie
theater!
Package Contents:
1.
Video Eyewear
2.
Carry Pouch / Lens Cleaner
3.
Head Strap
4.
Composite AV Cable for iPod
5.
Composite Audio/Video Cable
© Copyright 2008, Vuzix Corporation
iWear®
AV310 Widescreen
6.
7.
• Alternate Nose Bridge
®
• User's Manual
User's Guide
Items may not be exactly as illustrated.
Battery / Controls Box
Foam Earphone Covers
(not shown)
(not shown)
Advertisement
Table of Contents
Related Manuals for Vuzix iWear AV310 Widescreen
Summary of Contents for Vuzix iWear AV310 Widescreen
-
Page 1: Package Contents
R e ad t he S af et y I n s t ru ct io ns b ef o re us in g yo u r e yew ear! Welcome to the world of 16:9 widescreen viewing on the go! Your Vuzix™... -
Page 2: Important Safety Instructions
6. Immersive video, whether viewed on a regular TV, a movie theater screen or a VUZIX video display, can potentially have adverse effects on the user, including: motion sickness, perceptual after effects, disorientation, decreased postural stability, and eye strain. - Page 3 Vuzix’s entire liability and Your exclusive remedy for any breach of warranty shall be, at Vuzix’s option, (1) to repair or replace all or part of the hardware, 2) exchange the hardware with a product that is new or which has been manufactured from new or serviceable used...
-
Page 4: Fcc Compliance
Vuzix can be found in the documentation accompanying Your product and on the web at our global site at www.vuzix.com, which will also identify any Vuzix subsidiary or branch serving Your country and its local address. You may also write to: Vuzix Sales Support, 75 Town Centre Drive, Rochester, NY 14623, USA. - Page 5 Before using your video eyewear for the first time, remove the clear protection film from the inside surface of the viewer lens. The iWear AV310 Widescreen video eyewear can be connected to any video device with compatible connectors. It comes with an iPod audio/video cable.
-
Page 6: Control Buttons
A series of four buttons on the battery pack allow you to adjust audio and video of your AV310 Widescreen. The top button, nearest the connector, is the Power/OSD button. It allows you to turn your Vuzix AV310 Widescreen on and off and access the On Screen Display (OSD) menu. •... - Page 7 On Screen Display (OSD) Menu With AV310 Widescreen turned on, press the Power/OSD button to access the OSD for adjusting display settings. Repeat presses Power/OSD button through each of the options, finally exiting the OSD. The first icon in each menu line is a label only and has no effect on the eyewear’s display settings.
- Page 8 3D or stereoscopic video can be composed using any several formats. The AV310 Widescreen supports the most common of these; used by most 3D video productions. If you know which format is appropriate for a video you wish to view, simply select that format.
- Page 9 ® AccuTilt Viewer Adjustment AccuTilt viewer adjustment is a Vuzix technology that allows you to adjust the angle of the display housing 15 degrees to ensure optimum angle and screen clarity. To adjust the viewing angle, grasp the viewer and tilt it up or down.
-
Page 10: Troubleshooting
Battery Replacement Your AV310 Widescreen is powered by a single AA battery. A high quality alkaline battery, such as the one pre-installed, will provide power for up to 7 hours of use. Alternate AA battery types can also be used. A 2500mAh NiMH battery will provide power for up to 8 hours and a lithium battery up to 17 hours of use. - Page 11 Vuzix website at www.vuzix.com. Contacting VUZIX In the United States or Canada, refer to the Vuzix website (www.vuzix.com) or call (800) 436-7838, 9 AM to 6 PM ET weekdays, excluding holidays. Be sure to have the following information available before you call: •...
- Page 12 Apple Inc., registered in the U.S. and other countries. Vuzix, The Vuzix Logo, View the Future, iWear, AccuTilt and AV310 are trademarks of Vuzix Corporation at least some of which are protected by the following registration(s): 3,245,574, 3,385,610.
