Summary of Contents for Vuzix Wrap 1200DXAR
- Page 1 Wrap™ 1200DXAR User Guide ®...
-
Page 2: Table Of Contents
WRAP 1200DXAR INTRODUCTION Overview System Requirements Downloads & Updates INSTALLATION & SETUP Step 1: Charging the Controller Step 2: Install Software Digital Download Step 3: Connecting Accessories Earphones Wrap Tracker ... - Page 3 Wrap Noise-Isolating Earphones Wrap Tracker Tether Strap DEVELOPER TOOLS AND SUPPORT Vuzix AR/VR SDK Acquiring Vuzix VR/AR SDK CLEANING SUPPORT SERVICES WASTE ELECTRICAL & ELECTRONIC EQUIPMENT...
- Page 4 Read the Safety and Warranty information before proceeding.
-
Page 5: Wrap 1200Dxar Introduction
The WRAP 1200DXAR is a digital video eyewear product designed for use in augmented reality (AR) applications. It provides a video display, video capture, audio, head tracking, plus HMDI® and USB interfaces to a Windows computer for processing and providing AR content. - Page 6 HDMI-compliant source device. Stereo USB Camera The most visually striking feature of the Wrap 1200DXAR is its stereo camera pair mounted on the face of the eyewear. This stereo camera system enables 3D video capture of the user’s real-world view.
-
Page 7: System Requirements
HDMI compliant video source (audio/video playback only) 2, USB 2.0 ports providing 0.5A of power or greater • Vuzix provides online access to WRAP 1200DXAR software, documentation and updates. § To download the complete set of WRAP 1200DXAR software and documentation, go to: www.vuzix.com/DD... -
Page 8: Installation & Setup
Prior to First Use power. Prior to using the Wrap 1200DXAR its battery must charged for a minimum of four (4) hours, using a USB power source providing a minimum of 0.5 Amps. Most modern desktop and laptop computers provide sufficient power. Check your computer’s specifications if you are unsure of your USB port’s power output. -
Page 9: Step 3: Connecting Accessories
Using your web browser, go to http://www.vuzix.com/dd. § § Download the software and documentation package for the Wrap 1200DXAR. Decompress the .zip file and save its contents to a convenient location. § Review the documentation provided. § Open the “Camera_Drivers” folder and run the “drv_uvc_20100202_whql.exe”... -
Page 10: Step 4: Connecting To Your Computer
Cables not certified as Controller High Speed HDMI® The Wrap 1200DXAR Controller provides two ports, a HDMI port and a USB Cables and may not port. Cables are provided to connect both of these to an HDMI-compliant provide the same level of Windows based personal computer. -
Page 11: Step 5: Adjustment & Configuration
If you press the Power & menu button again, after it is turned on, the OSD (On Screen Display) screen will be displayed. Video Display The WRAP 1200DXAR does not require any configuration for displaying 2D or 3D video from HDMI-compliant devices. If connected to a computer that is not fully HDMI-compliant, some configuration may be required to enable the eyewear to function as an external monitor. -
Page 12: Audio
1920 x 1080 results, use one of these supported resolutions. Audio If an alternate audio The WRAP 1200DXAR is equipped with removable stereo earphones. Small, system is used, volume medium and large noise-isolation rings are included. controlled through that §... -
Page 13: Accutilt ® Display Angle Adjustment
Accutilt Display Angle Adjustment The angle of your displays can also impact their clarity. Vuzix eyewear is equipped with a patented Accutilt system that enables the display to be to be tilted up or down by up to 15 degrees. -
Page 14: Tether Strap
Tether Strap For active applications a tether strap can be used to provide a more secure fit. Attached each end of the tether strap to the eyelets on the eyewear stems. § Adjust the strap synch for a comfortable and secure fit. §... -
Page 15: Controller & Osd
The WRAP 1200DXAR Controller provides access to audio controls as well as the OSD, a menu system for controlling the eyewear’s On-Screen Display (OSD) options. Volume and the OSD options are managed through the four buttons on the Controller. Power & Menu Powers up the video eyewear and enable its on-screen display menu (OSD). -
Page 16: Osd Display Controls
With the device on, press the Power & Menu button to display the OSD. 720P 3D 2D S T/B The display resolution is displayed in the top left corner, along with the current display mode. The battery level is displayed in the top right corner. Display Mode The display mode menu options, titled “3D”... -
Page 17: Eyewear Reference
Most HDMI devices do not require display configuration adjustment when connected to a Wrap 1200DXAR. Some computer systems may require adjustments to their display settings to enable the Wrap 1200DXAR as second or external display. The computer must be configured to support the Wrap 1200DXAR as an external monitor, duplication its desktop or laptop monitor. -
Page 18: Stereo Camera Pair
The Wrap 1200DXAR provides two independent VGA (640x480) cameras with natural eye separation to provide realistic stereoscopic 3D image capture. The cameras provide full-frame, sub-sampled or windowed 8-bit images in a wide range of formats, controlled through the Serial Camera Control Bus (SCCB) interface. -
Page 19: Eye-Separation Adjustment
The wire nose pad arms are not designed for frequent bending or sharp angles as this may weaken and break them. Replacement nose pad assemblies are available for purchase from Vuzix (www.vuzix.com). IPD (InterPupillary Distance) is the distance separating your eyes - sometimes referred to simplify as “eye-separation”. -
Page 20: Accutilt Adjustment
Repeat the process to adjust the other display. § Your WRAP 1200DXAR is equipped with a patented view angle adjustment called “Accutilt”. The mechanism allows you to rotate and tilt the display module up and down approximately 15° to achieve the best quality display. -
Page 21: Wrap Tracker
Controller’s USB cable. Head tracking requires explicit support in software applications. This support is demonstrated in the Vuzix AR/VR SDK for Windows, available for free download from the Vuzix website. Go to the Vuzix website for more information on the Wrap Tracker. -
Page 22: Vuzix Ar/Vr Sdk
Vuzix video eyewear. It is available for download from the Vuzix website and can be used royalty-free in any non-competing application, including commercial software. - Page 23 The Vuzix AR/VR SDK is available for download and royalty free use in non- competing applications, including commercial products. It can be licensed and downloaded from the Vuzix website’s Support/Developer Program web page: www.vuzix.com/developer...
-
Page 24: Cleaning
Your eyewear is virtually maintenance free, requiring only occasional cleaning with a soft microfiber cloth. Do not spray cleaners onto the eyewear or any of its components or immerse them in water. If required, spray a small amount of optical lens cleaner on a microfiber cloth and use that to clean stubborn marks or oily film. -
Page 25: Support Services
United States: United States, Canada, Central & South America, Asia (other than Japan), Australia, and New Zealand Product originating from the United Kingdom, please contact: Corporate Website: www.vuzix.com/uksite Email Customer Support: vuzix@tmti.com Customer Helpline: 0044 844 477 2977 Customer Service Hours:... - Page 26 1. The equipment that you bought has required the extraction and use of natural resources for its production. It may contain hazardous substances that could impact health and the environment. 2. In order to avoid the dissemination of those substances in our environment and to diminish the pressure on the natural resources, we encourage you to use the appropriate take-back systems.
- Page 27 Vuzix, the Vuzix logo, View the Future, Wrap and STAR are trademarks of Vuzix Corporation registered in the U.S. and other countries. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. All other trademarks are the property of their respective owners.
